Associated Numbers
235.3771 UD10974ASpecifications
Amp | 140 A |
Bottom Mounting Foot Width (B) | 14 mm |
Diameter (D.1) | 7/16" UNC 14 mm |
Diameter (D.2) | 7/16" UNF 20 mm |
Diameter (D.3) | 12 mm |
Length (L.1) | 250 mm |
Mount Inside Length or Pad Mount C-C (C) | 98 mm |
OEM Product | No |
Plug Code | PL_9105 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley Grooves | 2 qty |
Pulley Groove Width (W.1) | 13 mm |
Pulley Outside Diameter (O.D.1) | 55 mm |
Pulley Outside Diameter (O.D.2) | 87 mm |
Pulley to Mount Distance (A) | 46.50 mm |
Pulley Type | Solid |
Unit Type | UNIVERSAL |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
LIAZ | 5256.25 | [3116] | |
LIAZ | 5256.26 | [3116] | |
LIAZ | 6212 | [3126E] |
Reference Information
1A00075 | RUSSIA |
23513771155 | RUSSIA |
235.3771 | RUSSIA |
ALR2351 | KRAUF |
UD10974A | AS-PL |
Video/Publications
A9208View your shopping basket or Browse other items in Alternators.
