A9234 - Brand new AS-PL Alternator

Associated Numbers

0120489170 0120489541 0120489542 0120489641 0120489642 0120489742 0120489743 0986030980 0986030981 11.201.306 112768 14057 14064 14293 14293R 20100190 20130207 20598 20601 30129RI 30129RIM 30316RI 30316RIL 30316RIM 30680350 32033890 433059 436111 4382200 4386883 4392831 4424346 4447411 4478678 46231723 46231725 46231751 46231755 5920974 5943452 5960292 5962647 5970230 5972197 5976915 63305020 63305150 63305310 63305406 63305426 63305450 63305520 63305621 63307150 63307160 63307420 63307429 63321071 7575998 77211411 77323410 77338410 77340410 77340411 77510410 77510411 77612410 8EL725718-001 AAK4140 CA316IR CAL30116GS DRA0970 DRA0980 GA321042-A IA0306 LRA00190 LRA00307 LRA00456 LRA190 LRA307 LRA456 MAHMG150 MG150 VA301 A9234

Specifications

Amp	55 A
Bottom Mounting Foot Width (B)	17 mm
Diameter (D.1)	11.50 mm
Diameter (D.2)	11.50 mm
Diameter (D.3)	11.50 mm
Length (L.1)	177 mm
Mount Inside Length or Pad Mount C-C (C)	71.50 mm
OEM Product	No
Plug Code	PL_9104
Product Line	Standard Line
Product Type	Brand new
Pulley Grooves	1 qty
Pulley Groove Width (W.1)	12.50 mm
Pulley Outside Diameter (O.D.1)	49 mm
Pulley Outside Diameter (O.D.2)	75 mm
Pulley to Mount Distance (A)	50 mm
Pulley Type	Solid
Unit Type	ISKRA / LETRIKA
Voltage	12 V

Vehicle Applications

Make	Model	Type	Year
ABARTH	Ritmo 125 TC 2.0	[138AR1.000]	11.1981-12.1987
ABARTH	Ritmo 130 TC 2.0	[138AR2.000]	04.1983-12.1987
ALFA ROMEO	6 2.5 TD	[VM-HR588HT]	07.1981-05.1986
ALFA ROMEO	75 2.0 TD	[VM80A]	05.1985-09.1992
ALFA ROMEO	75 2.4 TD	[VM81A]	01.1989-02.1992
ALFA ROMEO	90 2.4 TD	[VM81A]	10.1984-07.1987
ALFA ROMEO	Alfetta 2.0 TD	[VM4HT/2]	10.1979-03.1983
ALFA ROMEO	Alfetta 2.4 TD	[VM4HT2.4]	04.1983-12.1984
ALFA ROMEO	AR 6 2.4 D	[8144.61.200]	04.1985-02.1986
ALFA ROMEO	AR 6 2.4 TD	[8144.21.220]	09.1986-12.1989
ALFA ROMEO	AR 6 2.5 D	[8144.67.220]	09.1986-12.1989
ALFA ROMEO	AR 8 2.4 D	[8140.61.200]	04.1978-08.1986
ALFA ROMEO	AR 8 2.4 TD	[8140.21.200D.I.]	04.1985-12.1989
ALFA ROMEO	Arna 1.2	[AR30500]	01.1985-12.1986
ALFA ROMEO	Arna 1.3 Ti	[AR30168]	03.1983-12.1986
ALFA ROMEO	Arna 1.3 Ti	[AR31010]	03.1983-12.1986
ALFA ROMEO	Arna 1.5	[AR30182]	01.1985-12.1986
ALFA ROMEO	Giulietta 2.0 TD	[VM4HT]	01.1983-12.1985
CITROEN	C25 1.9 TD	[M705]	04.1992-02.1994
FERRARI	400 i 4.8	[F101..]	05.1979-02.1982
FERRARI	400 i 4.8	[F101..]	05.1979-03.1985
FERRARI	512 BB 4.9	[F102B]	08.1976-06.1981
FERRARI	512 BB i 4.9	[F110A]	07.1981-08.1984
FERRARI	BB 512 i 4.9	[F110A]	07.1981-02.1982
FIAT	124 1.2	[124A.000]	04.1967-05.1973
FIAT	124 1.2	[124A.000]	05.1973-03.1975
FIAT	124 1.2	[124A.000]	07.1966-10.1973
FIAT	124 1.2	[124A.000]	08.1971-07.1975
FIAT	124 1.2	[124A.000]	09.1967-07.1975
FIAT	124 1.4	[124B2.000]	08.1971-07.1975
FIAT	124 1.5	[124AC.000]	01.1966-12.1972
FIAT	124 1.6	[125B.000]	01.1969-12.1974
FIAT	124 1.6	[125B.000]	04.1970-10.1973
FIAT	124 1.6	[125B.000]	11.1969-08.1973
FIAT	124 1.6	[125B.000]	11.1971-10.1973
FIAT	124 1.6	[125BC.000]	01.1969-12.1974
FIAT	124 1.6	[125BC.000]	04.1970-10.1973
FIAT	124 1.6	[125BC.000]	11.1969-08.1973
FIAT	124 1.6	[125BC.000]	11.1971-10.1973
FIAT	124 1.6	[132AC.000]	08.1972-02.1976
FIAT	124 1.6	[132AC.000]	11.1969-08.1973
FIAT	124 1.8	[132A2100]	01.1973-07.1975
FIAT	124 1.8	[132AC1.000]	01.1972-12.1977
FIAT	124 2.0		08.1984-04.1985
FIAT	125 1.6	[125A.000]	07.1967-03.1974
FIAT	125 1.6	[125B.000]	10.1968-10.1973
FIAT	131 1.3	[131A.000]	10.1974-12.1980
FIAT	131 1.6	[131..]	03.1978-12.1980
FIAT	131 1.6	[131A1.000]	10.1974-12.1980
FIAT	131 2.0	[131..]	06.1978-12.1980
FIAT	131 2.0 D	[8144.65]	07.1978-08.1984
FIAT	131 2.5 D	[8144.61]	03.1979-12.1984
FIAT	132 1.6	[132BBOAO]	04.1972-01.1976
FIAT	132 1.6	[132C.000]	01.1976-12.1982
FIAT	132 1.6	[132C.000]	05.1972-05.1981
FIAT	132 1.6	[132C.000]	05.1977-09.1982
FIAT	132 1.6	[132C6.000]	03.1977-12.1981
FIAT	132 1.7	[132B1.000]	04.1972-01.1974
FIAT	132 1.7 GLS	[132B1.000]	04.1974-12.1975
FIAT	132 1.7 GLS	[132B1.000]	11.1975-01.1977
FIAT	132 1.8		05.1972-02.1977
FIAT	132 2.0		09.1979-05.1981
FIAT	132 2.0 D	[8144.65]	07.1978-07.1982
FIAT	132 2.5 D	[8144.61]	07.1978-07.1982
FIAT	133 2.0 D	[8144.61]	07.1978-07.1983
FIAT	Argenta 1.6	[132D.000]	04.1981-12.1985
FIAT	Argenta 2.0	[132C2.000]	06.1978-12.1985
FIAT	Argenta 2.0	[132D1.000]	06.1978-12.1985
FIAT	Argenta 2.0 i.e.	[132C3.000]	06.1981-07.1986
FIAT	Argenta 2.5 D 2500	[8144.61]	06.1981-11.1985
FIAT	Argenta 2.5 TD	[8144.61.500.81]	07.1983-08.1985
FIAT	Campagnola 2.0	[6132AZ2.000]	06.1974-10.1989
FIAT	Campagnola 2.4 D	[8144.61.200]	06.1974-10.1989
FIAT	Ducato 1.9 D Panorama	[149B1.000]	02.1987-08.1990
FIAT	Ducato 1.9 TD	[280A1.000]	03.1989-08.1990
FIAT	Ducato 1.9 TD Panorama	[280A1.000]	07.1990-03.1994
FIAT	Ducato 2.4 D Panorama	[8144.61]	07.1982-12.1985
FIAT	Ducato 2.4 TD 4x4	[8144.21]	01.1986-08.1990
FIAT	Ducato 2.5 D	[8144.67]	07.1990-03.1994
FIAT	Ducato 2.5 D	[CRD93L]	01.1986-08.1990
FIAT	Ducato 2.5 D 4x4	[8144.67]	03.1989-08.1990
FIAT	Ducato 2.5 D Panorama	[8144.67]	07.1990-03.1994
FIAT	Ducato 2.5 D Panorama 4x4	[8144.67]	07.1990-03.1994
FIAT	Ducato 2.5 TD	[8140.27]	07.1990-03.1994
FIAT	Ducato 2.5 TD	[8144.21]	01.1986-08.1990
FIAT	Ducato 2.5 TD 4x4	[8140.27]	07.1990-03.1994
FIAT	Ducato 2.5 TD Panorama	[8140.27]	08.1990-03.1994
FIAT	Ducato 2.5 TD Panorama	[8144.21]	01.1987-08.1990
FIAT	Ducato 2.5 TD Panorama 4x4	[8140.27]	01.1991-03.1994
FIAT	Ducato 2.5 TD Panorama 4x4	[8144.21]	01.1986-08.1990
FIAT	Ritmo 1.0	[127A6.000]	09.1978-09.1982
FIAT	Ritmo 1.1	[138B.000]	10.1982-12.1987
FIAT	Ritmo 1.1	[138B1.000]	10.1982-12.1987
FIAT	Ritmo 1.1	[138C1.000]	10.1982-12.1987
FIAT	Ritmo 1.3	[138A1.000]	01.1978-08.1985
FIAT	Ritmo 1.3	[138A3.000]	01.1981-09.1982
FIAT	Ritmo 1.3	[138B2.000]	01.1983-04.1985
FIAT	Ritmo 1.3	[149A3.000]	01.1978-08.1985
FIAT	Ritmo 1.3	[149A7.000]	01.1978-08.1985
FIAT	Ritmo 1.5	[138A4.000]	01.1981-05.1987
FIAT	Ritmo 1.6	[138AR.000]	05.1981-12.1987
FIAT	Ritmo 2.0	[138AR..]	09.1980-07.1981
FIAT	Ritmo 2.0	[138AR1..]	11.1981-09.1982
FIAT	Uno 1.7 D	[146B2.000]	02.1988-02.1992
FIAT	Uno 1.7 D	[149B4.046]	02.1988-02.1992
IVECO	12997 2.4 D	[8140.61.200]	01.1978-12.1989
IVECO	13119 2.5 D	[8140.47.2700]	01.1990-04.1996
IVECO	14824 2.4 D	[8140.61.200]	01.1983-06.1989
IVECO	14885 2.4 D	[8140.27S]	01.1985-12.1989
IVECO	16711 2.4 D	[8140.21.200]	01.1985-12.1989
IVECO	30-8	[8140.61.200]	01.1978-12.1989
IVECO	30-Aug	[8140.61.200]	01.1978-12.1989
IVECO	35-12	[8140.47.2700]	01.1990-04.1996
IVECO	35-8 2.4 D	[8140.61.200]	01.1978-12.1989
IVECO	40-8 2.4 D	[8140.61.200]	01.1983-06.1989
IVECO	42977 2.4 D	[8140.61.200]	01.1978-12.1989
IVECO	49-10 2.4 D	[8140.21.200]	01.1985-12.1989
LANCIA	Beta 1.3	[828D3.000]	12.1981-12.1984
LANCIA	Beta 1400 1.4	[828A2.000]	01.1973-12.1975
LANCIA	Beta 1.6	[828B.000]	04.1976-12.1984
LANCIA	Beta 1.6	[828B.000]	08.1973-07.1982
LANCIA	Beta 1600 1.6	[828A.000]	01.1973-12.1975
LANCIA	Beta 1.8	[828A1.000]	08.1973-07.1976
LANCIA	Beta 1800 1.8	[828A1.000]	01.1973-12.1975
LANCIA	Beta 2.0	[828B1.000]	04.1976-07.1978
LANCIA	Beta 2.0	[828B1.000]	04.1976-12.1984
LANCIA	Beta 2.0	[828B1.000]	04.1979-10.1986
LANCIA	Beta 2.0	[828B1.000]	05.1976-11.1979
LANCIA	Beta 2.0	[828B1.000]	07.1978-07.1982
LANCIA	Beta 2.0	[828B7.000]	07.1983-12.1984
LANCIA	Beta 2.0 i.e.	[828B4.000]	12.1981-12.1984
LANCIA	Beta Berlina 1600 1.6		01.1976-04.1978
LANCIA	Beta Berlina 2000 2.0		01.1976-04.1978
LANCIA	Beta Coupe 1600 1.6		06.1973-04.1978
LANCIA	Beta Coupe 1800 1.8	[828AC100]	06.1973-12.1975
LANCIA	Beta Coupe 2000 2.0	[828CB1A..]	06.1973-04.1978
LANCIA	Beta HPE 1600 1.6	[828CB.A..]	04.1975-04.1978
LANCIA	Beta H.P.E. 2.0	[828B1.000]	04.1979-09.1984
LANCIA	Beta H.P.E. 2.0	[828B1.000]	05.1976-05.1978
LANCIA	Beta H.P.E. 2.0	[828B7.000]	07.1983-09.1984
LANCIA	Beta HPE 2000 2.0	[828CB1A..]	04.1975-04.1978
LANCIA	Beta H.P.E. 2.0 i.e.	[828B4.000]	05.1981-09.1984
LANCIA	Beta Spider 1600 1.6		01.1975-04.1978
LANCIA	Beta Spider 2000 2.0		01.1975-04.1978
LANCIA	Delta 1.6 GT	[831A4.000]	11.1982-04.1986
LANCIA	Delta 1.6 GT i.e.	[831B7.000]	08.1986-08.1988
LANCIA	Delta 1.6 HF Turbo	[831A7.000]	10.1983-12.1986
LANCIA	Delta 1.6 HF Turbo	[831B7.046]	04.1987-03.1989
LANCIA	Trevi 2.0 i.e.	[828B4.000]	05.1980-01.1987
SAME	Centauro 70 D		12.1981-10.1987
SAME	Centurion 75 D		11.1978-05.1988
SEAT	131 1.6	[GA]	03.1975-10.1981
SEAT	131 1.6		01.1978-09.1978
SEAT	132 1.6	[GA]	09.1978-05.1979
SEAT	132 1.8	[GE]	03.1973-05.1979
SEAT	Ibiza 1.2	[021A]	11.1984-12.1993
SEAT	Ibiza 1.5	[021A]	11.1984-05.1993
VOLVO	P8720B

Reference Information

0005927867	VW
0120489743	BOSCH
0986030980	BOSCH
0986030981	BOSCH
10441591	ALANKO
110890	CARGO
11.201.306	ISKRA / LETRIKA
20100190	PRESTOLITE
3119027	HENKEL PARTS
433059	VALEO
436111	VALEO
505.010.055.090	PSH
72735149	MAHLE
90156103	WILSON
AC-CBA0631	ACAUTO
ALT20729	WOODAUTO
ALT79062	ELECTROLOG
ANM36110X	ANDEL
F032110890	CARGO
IA0306	ISKRA / LETRIKA
LRA00456	LUCAS
LRA456	LUCAS
MAHMG150	WOODAUTO
MG150	MAHLE
UD13072A	AS-PL
WOOALT20729	WOODAUTO
ANM36110	ANDEL
