Associated Numbers
A4047 63321165Specifications
| Depth (D.1) | 10 mm |
| Inside Diameter (I.D.1) | 32.80 mm |
| Inside Diameter (I.D.2) | 17 mm |
| Length 3 (L.3) | 2.30 mm |
| Length (L.1) | 17.60 mm |
| Length (L.2) | 9.20 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 39 mm |
| Outside Diameter (O.D.2) | 68 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 1 qty |
| Unit Type | MAGNETI MARELLI |
| Width (W.1) | 10 mm |
Reference Information
| UD03315AP | AS-PL |
