Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 870.00 including GST
NZ$ 756.52 excluding GST
or four payments of $217.50
with
Learn More
each
S0011
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
0001416036Associated Numbers
0001410111 0001416036 01174645 0986012730 10384 11.139.013 110535 16372N 20401826BN 20401826EL 22.0384 28.0384 33631 45-1370 455616 6010628 621.000.0 81466036 860655GB 860656GB 8694 8812730 8EA726132-001 AZK5173 CS384 CST10628AS CST10628ES DRS2730 IM536 LRS00748 R23-21 STR22018Specifications
| Kilowatt | 5.5 kW |
| Length (L.1) | 386 mm |
| Mount Hole Center - Center (O.1) | 127 mm |
| Mount Hole Center - Center (O.2) | 89 mm |
| Mount Hole Center - Center (O.3) | 89 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| Mount Hole Diameter (C.3) | 11 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 11 qty |
| OEM Product | No |
| Oil Sealed | Yes |
| Pinion at Rest (B) | 47 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Unit Type | BOSCH |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| IVECO | P/PA 160-23 12.8 | [F8L413F] | 06.1986-05.1989 |
| IVECO | P/PA 160-30 12.8 | [BF8L513] | 06.1986-05.1989 |
| IVECO | P/PA 170-23 13.4 | [F8L513] | 04.1988-07.1991 |
| IVECO | P/PA 170-25 13.4 | [F8L513] | 03.1989-07.1991 |
| IVECO | P/PA 170-34 12.8 | [BF8L513] | 04.1989-07.1991 |
| IVECO | P/PA 180-23 13.4 | [F8L513] | 07.1991-07.2000 |
| IVECO | P/PA 180-25 13.4 | [F8L513] | 07.1991-07.2000 |
| IVECO | P/PA 180-34 12.8 | [BF8L513] | 07.1991-07.2000 |
| IVECO | P/PA 190-25 12.8 | [F8L413F] | 07.1983-09.1990 |
| IVECO | P/PA 260-25 12.8 | [F8L413F] | 07.1983-06.1986 |
| IVECO | P/PA 260-25 13.4 | [F8L513] | 04.1989-12.1999 |
| IVECO | P/PA 260-30 12.8 | [BF8L513] | 06.1986-05.1990 |
| IVECO | P/PA 260-34 12.8 | [BF8L513] | 04.1989-12.1999 |
| IVECO | P/PA 300-30 12.8 | [BF8L513] | 04.1987-05.1989 |
| IVECO | P/PA 330-30 12.8 | [BF8L513] | 05.1986-09.1990 |
| IVECO | P/PA 340-34 12.8 | [BF8L513] | 03.1989-12.1998 |
Reference Information
| 0001410111 | BOSCH |
| 0001416036 | BOSCH |
| 01171955 | KHD |
| 01174639 | KHD |
| 01174645 | KHD |
| 0986012730 | BOSCH |
| 10384 | KUHNER |
| 110535 | CARGO |
| 11.139.013 | ISKRA / LETRIKA |
| 1171955 | KHD |
| 1171955 | IVECO |
| 1516756R | DAF |
| 16372N | WAI / TRANSPO |
| 1701063 | FAUN |
| 20401826BN | REAL |
| 20401826EL | REAL |
| 220322 | ERA |
| 22.0384 | LAUBER |
| 22620 | EFEL |
| 28.0384 | LAUBER |
| 3040680 | KHD |
| 330536 | LOGISTIK |
| 33631 | EAI |
| 42498250 | IVECO |
| 42522680 | IVECO |
| 42526680 | IVECO |
| 45-1370 | ELSTOCK |
| 455616 | VALEO |
| 6010628.0 | SANDO |
| 6010628.3 | SANDO |
| 621.000.0 | ELMOT |
| 72736194 | MAHLE |
| 8121335 | IVECO |
| 81466036 | MONARK |
| 860655GB | PRESTOLITE |
| 860656GB | PRESTOLITE |
| 8694 | CEVAM |
| 8812730 | FRIESEN |
| 8EA726132-001 | HELLA |
| AZK5173 | ISKRA / LETRIKA |
| C9JF11350A | FORD |
| CGB-11536 | AINDE |
| CS384 | HC PARTS |
| CST10628AS | CASCO |
| CST10628ES | CASCO |
| D6PZ11350C | FORD |
| DRS2730 | DELCO |
| F032110535 | CARGO |
| IM536 | AVF |
| IS9013 | ISKRA / LETRIKA |
| LRS00748 | LUCAS |
| LRS748 | LUCAS |
| MAV126260 | SIOM |
| MAV126280 | SIOM |
| MS566 | MAHLE |
| PRSS903 | 3EFFE |
| R23-21 | ELMOT |
| STR1648 | ELECTROLOG |
| STR22018 | WOODAUTO |
| STR79443 | ELECTROLOG |
| STRS903 | 3EFFE |
Video/Publications
