Associated Numbers
0001417064 043.000.0 0986017850 101163 101163P 112117 20401946BN 20401946EL 28.1163 30085N 33946 45-2237 4839041 6010649 77712318 8118 860513 860513GB 8EA737676-001 CS1163 CST10649AS CST10649ES CST10649RS DRS7850 LRS01906 R22-43 STR22043Specifications
Kilowatt | 6.6 kW |
Length (L.1) | 407 mm |
Mount Hole Center - Center (O.1) | 126.5 mm |
Mount Hole Center - Center (O.2) | 126.5 mm |
Mount Hole Center - Center (O.3) | 126.5 mm |
Mount Hole Diameter (C.1) | 15.5 mm |
Mount Hole Diameter (C.2) | 15.5 mm |
Mount Hole Diameter (C.3) | 15.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
No./Teeth (Replaces) | 11 qty |
Oil Sealed | Yes |
Pinion at Rest (B) | 21 mm |
Rotation | CW |
Spigot Diameter (A) | 115 mm |
Unit Type | BOSCH |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
IVECO | 180 E 42 14.0 | [8210.42L.400] | 04.1992-12.1993 |
IVECO | 190 E 37 14.0 | [8210.42K] | 04.1993-11.2000 |
IVECO | 190 E 42 14.0 | [8210.42L] | 01.1995-07.2000 |
IVECO | 190 E 42 14.0 | [8210.42L.400] | 01.1993-07.2000 |
IVECO | 190 E 42 14.0 | [8210.42L.400] | 01.1995-07.2000 |
IVECO | 240 E 42 14.0 | [8210.42L.400] | 01.1993-02.2002 |
IVECO | 240 E 42 14.0 | [8210.42L.400] | 04.1992-12.2000 |
IVECO | 260 E 37 14.0 | [8210.42K] | 01.1993-12.2001 |
IVECO | 260 E 42 14.0 | [8210.42L] | 01.1993-12.2000 |
IVECO | 260 E 42 14.0 | [8210.42L] | 01.1994-12.2000 |
IVECO | 260 E 42 14.0 | [8210.42L.400] | 01.1994-12.2000 |
IVECO | 340 E 37 14.0 | [8210.42K] | 03.1995-12.2002 |
IVECO | 380 E 37 14.0 | [8210.42K] | 01.1993-12.2002 |
IVECO | 400 E 37 14.0 | [8210.42K] | 07.1994-12.2000 |
IVECO | 400 E 42 14.0 | [8210.42L] | 01.1994-12.2000 |
IVECO | 400 E 42 14.0 | [8210.42L.400] | 04.1992-12.2000 |
IVECO | 410 E 42 14.0 | [8210.42L] | 04.1992-11.2000 |
IVECO | 440 E 37 14.0 | [8210.42K] | 01.1993-11.2000 |
IVECO | 440 E 42 14.0 | [8210.42L] | 01.1993-12.2000 |
IVECO | 440 E 42 14.0 | [8210.42L] | 01.1997-12.2000 |
IVECO | 440 E 42 14.0 | [8210.42L.400] | 01.1993-12.2000 |
IVECO | 720 E 37 14.0 | [8210.42K] | 09.1993-12.1995 |
IVECO | 720 E 42 14.0 | [8210.42L] | 09.1993-12.1995 |
IVECO | 720 E 47 17.2 | [8210.42M.TCA] | 04.1992-12.2000 |
Reference Information
6010649 DRS7850 LRS01906 PRSL234 8EA737676-001 CST10649RS CST10649ES 2997385 220283 LRS1906 101163P MAV1202 77712318 043.000.0 ANM10070X 1417064 30085N CST10649AS S0012 20401946BN R22-43 112117 28.1163 101163 20401946EL STR10115 STR22043 CGB-11664 CS1163 S24BH0043A2 6010649.3 6010649.2 45-2237 986017850 0001417064 8118 860513 STRL234 20401946RC 860513GB 33946 000986017850 4839041Video/Publications
0001417064 043.000.0 0986017850 101163 101163P 112117 20401946BN 20401946EL 28.1163 30085N 33946 45-2237 4839041 6010649 77712318 8118 860513 860513GB 8EA737676-001 CGB-11664 CS1163 CST10649AS CST10649ES CST10649RS DRS7850 LRS01906 LRS1906 MAV1202 R22-43 STR22043 STRL234 S0012 220283Add Your Number
Contact Details
Request More Information
Add your number to the message box below and we will add it to our system
