Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 771.96 including GST
NZ$ 671.27 excluding GST
or four payments of $192.99
with
Learn More
each
S0023
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
0001416062Associated Numbers
0001416062 0001416067 0986014560 10617 11.139.025 110981 19024049 20401736BN 20401736EL 28.0617 30087N 33533 365211 45-1297 455542 6010637 81366062 81466062 860509 860509GB 8744 8814560 8EA730187-001 AZK5184 CS617 CST10637AS CST10637ES DRS4560 EAA-121536 IM562 LRS00766 STR22033Specifications
| Kilowatt | 5.40 kW |
| Length (L.1) | 386 mm |
| Mount Hole Center - Center (O.1) | 127 mm |
| Mount Hole Center - Center (O.2) | 127 mm |
| Mount Hole Center - Center (O.3) | 127 mm |
| Mount Hole Diameter (C.1) | 13.50 mm |
| Mount Hole Diameter (C.2) | 13.50 mm |
| Mount Hole Diameter (C.3) | 13.50 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 11 qty |
| No./Teeth (Replaces) | 11 qty |
| OEM Product | No |
| Oil Sealed | Yes |
| Pinion at Rest (B) | 47 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 110 mm |
| Unit Type | BOSCH |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| DAF | 95.310 11.6 | [WS225] | 09.1987- |
| DAF | 95.330 11.6 | [WS242] | 08.1990- |
| DAF | 95.330 11.6 | [WS242][WS259] | 08.1990- |
| DAF | 95.330 11.6 | [WS259] | 08.1990- |
| DAF | 95.330 11.6 | [WS259] | 09.1987-09.1990 |
| DAF | 95.350 11.6 | [WS259] | 09.1987-04.1997 |
| DAF | 95.360 11.6 | [WS268] | 09.1987-04.1997 |
| DAF | 95.360 11.6 | [WS268G] | 09.1987-04.1997 |
| DAF | 95.360 11.6 | [WS268L] | 09.1987-04.1997 |
| DAF | 95.360 11.6 | [WS268M] | 03.1993-04.1997 |
| DAF | 95.360 11.6 | [WS268M] | 09.1987-04.1997 |
| DAF | 95.360 11.6 | [WS268][WS268G][WS268L][WS268M] | 09.1987-04.1997 |
| DAF | 95.380 11.6 | [WS282] | 09.1987- |
| DAF | 95.400 11.6 | [WS295] | 08.1990- |
| DAF | 95.400 11.6 | [WS295G] | 08.1990- |
| DAF | 95.400 11.6 | [WS295L] | 08.1990- |
| DAF | 95.400 11.6 | [WS295M] | 08.1990- |
| DAF | 95.400 11.6 | [WS295][WS295G][WS295L] | 08.1990- |
| DAF | 95.400 11.6 | [WS295][WS295G][WS295L][WS295M] | 08.1990- |
| DAF | 95.430 11.6 | [WS315] | 02.1992- |
| DAF | 95.430 11.6 | [WS315L] | 02.1992- |
| DAF | 95.430 11.6 | [WS315M] | 02.1992- |
| DAF | 95.430 11.6 | [WS315][WS315L][WS315M] | 02.1992- |
Reference Information
| 0001416062 | BOSCH |
| 0001416067 | BOSCH |
| 0090690 | DAF |
| 0365211R | DAF |
| 090671 | DAF |
| 090690 | DAF |
| 0986014560 | BOSCH |
| 10617 | KUHNER |
| 110981 | CARGO |
| 11.139.025 | ISKRA / LETRIKA |
| 19024049 | DELCO |
| 20401736BN | REAL |
| 20401736EL | REAL |
| 220289 | ERA |
| 28.0617 | LAUBER |
| 30087N | WAI / TRANSPO |
| 330769 | LOGISTIK |
| 33533 | EAI |
| 365211 | DAF |
| 45-1297 | ELSTOCK |
| 455542 | VALEO |
| 6010637.0 | SANDO |
| 6010637.3 | SANDO |
| 72741796 | MAHLE |
| 81366062 | MONARK |
| 81466062 | MONARK |
| 860509 | PRESTOLITE |
| 860509GB | PRESTOLITE |
| 8744 | CEVAM |
| 8814560 | FRIESEN |
| 8EA730187-001 | HELLA |
| ANM16780X | ANDEL |
| AZK5184 | ISKRA / LETRIKA |
| CGB-11562 | AINDE |
| CS617 | HC PARTS |
| CST10637AS | CASCO |
| CST10637ES | CASCO |
| DRS4560 | DELCO |
| F032110981 | CARGO |
| IM562 | AVF |
| IS9025 | ISKRA / LETRIKA |
| LRS00766 | LUCAS |
| LRS766 | LUCAS |
| MAV126370 | SIOM |
| MS497 | MAHLE |
| PRSS710 | 3EFFE |
| STM1246 | ROLLCO |
| STR1460 | ELECTROLOG |
| STR22033 | WOODAUTO |
| STR79463 | ELECTROLOG |
| STRS710 | 3EFFE |
Video/Publications
