- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
0001110007Associated Numbers
0001110007 0001110008 0001317007 068911023L 068911023LX 068911023PX 0986015320 0986015328 10185 10606 110994 11122 113888 20401242RC 22.0606 22.0606M 22821N 25-3357 3409 436017 6010242 8015320 8212660 8EA730176-001 AES4119 CS606 CST10242RS DRS5320 EAA-121282 LRS00419 RNL1532 S0038 SS261 STR50065 VS175
0001110007 Bosch show
0001110008 Bosch show
0001314014 Bosch show
0001314015 Bosch
0009710107
0009710197
068911023L VW show
068911023LX VW show
068911024 VW
0986010837 Bosch ruil
0986015320 Bosch ruil
0986015328 Bosch ruil
11010910 EuroTec
11015320 EuroTec
110994 Cargo
11122 Motorola
1153SP Spidan
120113D PIC
200507093 PSH
253357 Elstock
30010 Lester
8015320F Friesen
9000693004 Bosch
915320 EDR
A10910 ATL
A15320 ATL
BBS911023
CS606 HC
DRS5320 Remy
HCS606 HC
LRS02184 Lucas
LRS419 Lucas
SR96X Bosch (USA)
STR1154sa Electrolog
STR1210sa Electrolog
0001110007, 0001110008, 0986015320, 0986015328
Magneti Marelli 943251324010
msr957
Specifications
| Kilowatt | 1.70 kW |
| Length (L.1) | 267 mm |
| Mount Hole Center - Center (O.1) | 74 mm |
| Mount Hole Center - Center (O.2) | 74 mm |
| Mount Hole Center - Center (O.3) | 106 mm |
| Mount Hole Diameter (C.1) | M8x1.25 mm |
| Mount Hole Diameter (C.2) | 9 mm |
| Mount Hole Diameter (C.3) | 9 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 9 qty |
| No./Teeth (Replaces) | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 15 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 82 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | 80 1.6 Diesel | [CR] | 08.1980-08.1986 |
| AUDI | 80 1.6 Diesel | [JK] | 08.1980-08.1986 |
| AUDI | 80 1.6 TD | [CY] | 08.1981-05.1986 |
| AUDI | 90 1.6 TD | [CY] | 10.1984-01.1987 |
| VW | Passat 1.6 Diesel | [CR] | 08.1980-07.1982 |
| VW | Passat 1.6 Diesel | [JK] | 08.1982-03.1988 |
| VW | Passat 1.6 TD | [CY] | 04.1982-03.1988 |
| VW | Santana 1.6 Diesel | [CR] | 08.1981-07.1982 |
| VW | Santana 1.6 Diesel | [JK] | 08.1982-12.1984 |
| VW | Santana 1.6 TD | [CY] | 04.1982-12.1984 |
Reference Information
| 0001110007 | BOSCH |
| 0001110008 | BOSCH |
| 0001317007 | BOSCH |
| 0009710107 | LINDE |
| 0009710197 | LINDE |
| 068911023 | VW |
| 068911023C | VW |
| 068911023CX | VW |
| 068911023L | VW |
| 068911023LX | VW |
| 068911068C | VW |
| 0986015320 | BOSCH |
| 0986015328 | BOSCH |
| 10185 | KUHNER |
| 10606 | KUHNER |
| 110994 | CARGO |
| 11122 | EAI |
| 113888 | CARGO |
| 200.507.093.010 | PSH |
| 200.507.093.018 | PSH |
| 20401242RC | REAL |
| 22.0606 | LAUBER |
| 22.0606M | LAUBER |
| 22821N | WAI / TRANSPO |
| 25-3357 | ELSTOCK |
| 330337 | LOGISTIK |
| 330758 | LOGISTIK |
| 3409 | CEVAM |
| 436017 | VALEO |
| 5010374 | MEAT & DORIA |
| 6010242.2 | SANDO |
| 8015320 | FRIESEN |
| 8212660 | POWERMAX |
| 8EA730176-001 | HELLA |
| AES4119 | AUTOELECTRO |
| ANM17540X | ANDEL |
| CS606 | HC PARTS |
| CST10242RS | CASCO |
| DRS5320 | DELCO |
| F032110994 | CARGO |
| F032113888 | CARGO |
| LRS00419 | LUCAS |
| LRS419 | LUCAS |
| MAV122420 | SIOM |
| MAV123160 | SIOM |
| PRSS241 | 3EFFE |
| RNL1532 | RNL |
| S0038 | AS-PL |
| S12BH0230A2 | SIDAT |
| SS261 | SOVEREIGN |
| STR10277 | ELECTROLOG |
| STR50065 | WOODAUTO |
| STRS241 | 3EFFE |
| STX200174 | STARDAX |
| STX200174R | STARDAX |
| STX200310 | STARDAX |
| VS175 | VALEO |
Video/Publications
