Associated Numbers
0001109413 0001218152 0001218168 0001218768 0001218814 0986016210 101201 10543 10590 112439 11264 20401411BN 22.0997 22.1201 22.1201M 25-0080 25-3117 254093B 33091N 35259400 35259480 3677 436052 450.501.093 6010114 8212758 8816210 88212758 8EA011610-101 8EA737859-001 AES7128 B001233216 BOS0001109413 CS1201 CST10114AS DRS3084 EAA-121087 ERR5009 IS9437 LRS00728 NAD100390 NAD500210 S0042 SS689 STR54006 UD12023S VS104Specifications
Kilowatt | 2.2 kW |
Length (L.1) | 272 mm |
Mount Hole Center - Center (O.1) | 103 mm |
Mount Hole Center - Center (O.2) | 146 mm |
Mount Hole Center - Center (O.3) | 103 mm |
Mount Hole Diameter (C.1) | 12 mm |
Mount Hole Diameter (C.2) | 12 mm |
Mount Hole Diameter (C.3) | 12 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
No./Teeth (Replaces) | 9 qty |
Pinion at Rest (B) | 21 mm |
Rotation | CW |
Spigot Diameter (A) | 92 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
LAND ROVER | Defender 2.5 TD5 4WD | 06.1998- | |
LAND ROVER | Defender 2.5 TDi 90 | [23L] | 09.1990-12.2001 |
LAND ROVER | Defender 2.5 TDi 90, 110 | [23L] | 09.1990-12.2001 |
LAND ROVER | Discovery 2.5 TDi | [12L] | 09.1989-12.1998 |
LAND ROVER | Discovery 2.5 TDi | [19L] | 10.1995- |
LAND ROVER | Discovery 2.5 TDi | [21L] | 09.1989-12.1998 |
LAND ROVER | Land Rover 2.5 TD | 09.1986-07.1990 | |
LAND ROVER | Range Rover 2.5 Diesel | [14L] | 08.1994-04.1996 |
Reference Information
RTC5249E 1218768 0001218768 8EA011610-101 BF5T11001AA NNN500210 PRC5109 AES7128 STM904 220362 STRS013 3H705 PRC5109N 0001109413 12 0001218814 NAD10039 35259480 PRC5109E 000B001233216 CST10114AS 112439 8816210 8EA737859-001 22.1201 10543 22.0997 ERR5009 450.501.093.500 10590 S12BH0795A2 450.501.093.108 22.1201M CGB-23084 LRS728 331353 450.501.093.100 72735640 254093B 0001218152 LR005962 6010114 000986016210 1218814 MS12 110354 220883 PRC4425 450.501.093.211 20401411BN MAV121140 436052 6010114.1 S12BH0788A2 0001218168 RTC5249 450.501.093 MTH705 BOS0001109413 003-H705 33091N UD12023S 11264 3677 1218168 MAV3760 STR1091 DRS3084 LRS00728 MS PRSS013 STRS042 RNL1621 NAD100390 494285R CS1201 B001233216 25-3117 NAD500210 450.501.093.390 1218152 51511501 25-0080 STR54006 330742 A0051511501 986016210 CS543 CST10114GS IS9437 101201 PRC3032 STRF341 88212758 35259400 1109413 EAA-121087 ERR5009E 8212758 ERR5009A 450.501.093.018 450.501.093.019 330695 450.501.093.010 SS689 450.501.093.011 ALT3800 20401411OE S0042 VS104Video/Publications
0001109413 0001218152 0001218168 0001218768 0001218814 003-H705 0986016210 101201 10543 10590 110354 112439 11264 20401411BN 22.0997 22.1201 22.1201M 25-0080 25-3117 254093B 33091N 35259400 35259480 3677 3H705 436052 450.501.093 6010114 8212758 8816210 88212758 8EA011610-101 8EA737859-001 AES7128 ALT3800 B001233216 BOS0001109413 CGB-23084 CS1201 CS543 CST10114AS DRS3084 EAA-121087 ERR5009 IS9437 LRS00728 LRS728 MAV121140 MAV3760 MS 12 MTH705 NAD100390 NAD500210 RNL1621 S0042 SS689 STR54006 STRF341 STRS013 STRS042 UD12023S VS104 220362 220883Add Your Number
