Associated Numbers
0001110039 0001110053 0001110113 0031517901 0041513701 0041517801 0986014940 10583 112820 11285 17150N 17227N 20401245BN 22.0583 22.0583M 25-2019 458488 6010542 8014940 88212384 8EA726207-001 A0031517901 A0041513701 AEU0583 B001117050 B001117148 B001117149 CS583 CST10542AS DRS4940 EAA-121593 LRS01291 S1053B S1056B SS460 STR50064Specifications
Kilowatt | 1.7 kW |
Length (L.1) | 269 mm |
Mount Hole Center - Center (O.1) | 72 mm |
Mount Hole Center - Center (O.2) | 105 mm |
Mount Hole Center - Center (O.3) | 72 mm |
Mount Hole Diameter (C.1) | 5 mm |
Mount Hole Diameter (C.2) | M12x1.75 mm |
Mount Hole Diameter (C.3) | M12x1.75 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 10 qty |
No./Teeth (Replaces) | 10 qty |
Pinion at Rest (B) | 11 mm |
Rotation | CW |
Spigot Diameter (A) | 78 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
MERCEDES BENZ | 400 E 4.2 | (124)[M119.975] | 10.1992-06.1993 |
MERCEDES BENZ | 400 SE 4.2 | (140)[M119.971] | 02.1991-05.1993 |
MERCEDES BENZ | 400 SEL 4.2 | (140)[M119.971] | 06.1993-09.1995 |
MERCEDES BENZ | 420 SE 4.2 | (126)[M116.965] | 09.1987-06.1991 |
MERCEDES BENZ | 420 SEC 4.2 | (126)[M116.965] | 09.1987-06.1991 |
MERCEDES BENZ | 420 SEL 4.2 | (126)[M116.965] | 09.1987-06.1991 |
MERCEDES BENZ | 420 SL 4.1 | (107)[M116.964] | 09.1987-08.1989 |
MERCEDES BENZ | 420 SL 4.2 | (107)[M116.964] | 09.1987-08.1989 |
MERCEDES BENZ | 500 E 5.0 | (124)[M119.974] | 01.1991-06.1993 |
MERCEDES BENZ | 500 E AMG 6.0 | -124 | 01.1992-06.1993 |
MERCEDES BENZ | 500 E AMG 6.0 | (124) | 01.1992-06.1993 |
MERCEDES BENZ | 500 SE 4.9 | (126)[M117.965] | 09.1987-06.1991 |
MERCEDES BENZ | 500 SE 5.0 | (126)[M117.965] | 09.1987-06.1991 |
MERCEDES BENZ | 500 SE 5.0 | (140)[M119.970] | 02.1991-05.1993 |
MERCEDES BENZ | 500 SE 5.5 | (126)[M117.968] | 09.1987-06.1991 |
MERCEDES BENZ | 500 SEC 4.9 | (126)[M117.963] | 09.1987-06.1991 |
MERCEDES BENZ | 500 SEC 4.9 | (126)[M117.965] | 09.1987-06.1991 |
MERCEDES BENZ | 500 SEC 5.0 | (126)[M117.965] | 09.1987-06.1991 |
MERCEDES BENZ | 500 SEL 5.0 | (126)[M117.965] | 09.1987-06.1991 |
MERCEDES BENZ | 500 SEL 5.0 | (140)[M119.970] | 02.1991-05.1993 |
MERCEDES BENZ | 500 SL 5.0 | (129)[M119.960] | 03.1989-08.1992 |
MERCEDES BENZ | 500 SL 5.0 | (129)[M119.972] | 09.1989-06.1993 |
MERCEDES BENZ | 560 SE 5.5 | (126)[M117.968] | 09.1987-06.1991 |
MERCEDES BENZ | 560 SEC 5.5 | (126)[M117.968] | 09.1987-06.1991 |
MERCEDES BENZ | 560 SEL 5.5 | (126)[M117.968] | 09.1987-06.1991 |
MERCEDES BENZ | E 420 4.2 | (124)[M119.975] | 06.1993-06.1995 |
MERCEDES BENZ | E 420 4.2 | (210)[M119.985] | 06.1996-08.1997 |
MERCEDES BENZ | E 420 E 4.2 | (210)[M119.985] | 01.1996-06.1997 |
MERCEDES BENZ | E 500 5.0 | (124)[M119.974] | 06.1993-06.1995 |
MERCEDES BENZ | E 50 AMG 5.0 | (210)[M119.985] | 02.1996-08.1997 |
MERCEDES BENZ | E 60 AMG 6.0 | (124)[M119.974] | 07.1993-06.1995 |
MERCEDES BENZ | G 500 E 5.0 | (463)[M117.965] | 03.1993-09.2001 |
MERCEDES BENZ | S 420 4.2 | (140)[M119.971] | 01.1993-08.1999 |
MERCEDES BENZ | S 420 4.2 | (140)[M119.981] | 03.1994-08.1999 |
MERCEDES BENZ | S 500 5.0 | (140)[M119.970] | 01.1993-09.1995 |
MERCEDES BENZ | S 500 5.0 | (140)[M119.980] | 01.1993-09.1995 |
MERCEDES BENZ | SL 500 5.0 | (129)[M119.972] | 09.1992-09.1995 |
MERCEDES BENZ | SL 500 5.0 | (129)[M119.982] | 09.1992-09.1995 |
Reference Information
1110039 5010513 1110113 ANM17160X AEU0583 88212384 4151780180 A0041513701 CST10542AS A0031517901 0001110039 0001110113 B001117149 S1053B B001117148 STR10131 STR10174 S1056B 000B001117148 A003151790180 000B001117149 B001117050 0001110053 SS460 11517801 41513701 10583 6010542 A004151370180 986014940 458488 EAA-121593 112820 22.0583 11285 S0051 LRS01291 25-2019 000B001117050 A0041517801 A0011517801 17150N STRL882 CS583 1110053 A004151780180 17227N 20401245BN PRSL882 330735 LRS1291 8014940 8EA726207-001 3151790180 4151370180 41517801 22.0583M 000986014940 S12BH0674A2 31517901 DRS4940 STR50064Video/Publications
S0051 0001110039 0001110053 0001110113 0031517901 0041513701 0041517801 0986014940 10583 112820 11285 17150N 17227N 20401245BN 22.0583 22.0583M 25-2019 458488 6010542 8014940 88212384 8EA726207-001 A0031517901 A0041513701 AEU0583 B001117050 B001117148 B001117149 CS583 CST10542AS DRS4940 EAA-121593 LRS01291 LRS1291 S1053B S1056B SS460 STR50064 STRL882Add Your Number
