Associated Numbers
0001208425 0001208426 0001208428 0001208429 0001211251 0001211252 0001211253 0001211254 025911023 025911023A 025911023AX 091911023A 091911023B 091911023BX 0986010470 0986014830 10298 10683 111061 11397 16722R 17066N 20401145BN 22.0298 22.0298M 22.0683 22.0683M 25-0385 25-0457 3639 42014830 433335 455625 6010541 8010470 8014830 8212233 8212385 88212233 88212385 8EA726057-001 8EA730199-001 AES5159 AES7190 B001208256 CS298 CS683 CST10541AS DRS0470 DRS4830 EAA-121398 LRS00559 LRS00790 S0077 SS819 STR50039Specifications
Kilowatt | 0.96 kW |
Length (L.1) | 240 mm |
Mount Hole Center - Center (O.1) | 105 mm |
Mount Hole Diameter (C.1) | 12 mm |
Mount Hole Diameter (C.2) | 10.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 44 mm |
Rotation | ACW |
Spigot Diameter (A) | 76 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
VW | Transporter 1.6 | [CT] | 01.1981-12.1982 |
VW | Transporter 1.9 | [DF] | 08.1982-11.1986 |
VW | Transporter 1.9 | [DF] | 12.1986-07.1992 |
VW | Transporter 1.9 | [DG] | 08.1982-11.1986 |
VW | Transporter 1.9 | [DG] | 09.1982-07.1992 |
VW | Transporter 1.9 | [DH] | 01.1983-07.1985 |
VW | Transporter 1.9 | [GW] | 08.1983-02.1989 |
VW | Transporter 1.9 Syncro | [DG] | 11.1984-11.1986 |
VW | Transporter 1.9 Syncro | [DG] | 12.1986-07.1992 |
VW | Transporter 2.0 | [CU] | 01.1981-12.1982 |
VW | Transporter 2.0 | [CV] | 02.1982-12.1982 |
VW | Transporter 2.1 | [DJ] | 06.1986-07.1992 |
VW | Transporter 2.1 | [DJ] | 07.1985-04.1986 |
VW | Transporter 2.1 | [MV] | 05.1986-07.1992 |
VW | Transporter 2.1 | [MV] | 08.1985-04.1986 |
VW | Transporter 2.1 | [SR] | 10.1986-07.1992 |
VW | Transporter 2.1 | [SS] | 08.1989-07.1992 |
VW | Transporter 2.1 i | [SS] | 08.1989-07.1992 |
VW | Transporter 2.1 Syncro | [DJ] | 01.1986-04.1986 |
VW | Transporter 2.1 Syncro | [DJ] | 05.1986-07.1992 |
VW | Transporter 2.1 Syncro | [MV] | 05.1986-07.1992 |
VW | Transporter 2.1 Syncro | [MV] | 08.1985-04.1986 |
VW | Transporter 2.1 Syncro | [SR] | 10.1986-07.1992 |
Reference Information
1211251 0001211253 STR10288 0001211252 1211253 0001211251 1211252 091911023A 88212385 91911023AX 22.0683 091911023B 42014830 25911023 25-0457 8014830 220357 8212385 220356 025911023AX 16722R 3639 22.0683M 330450 8EA726057-001 CS683 8010470 000B001208256 455625 20401145BN 10298 S0077 1211254 78AB11000AA ANM17050X 91911023BX 5010481 AES5159 22.0298M ESA154 091911023BX 0001208428 LRS559 0001208429 CS298 STRS883 11397 SS819 8EA730199-001 6010541 LRS790 STRS928 17066N STA0337R CST10541AS 0001208425 0001208426 1208425 1208426 EAA-121398 1208429 STR50039 000986014830 1208428 000986010470 LRS00790 986010470 1516725R 091911023AX B001208256 ALT136080 DRS4830 LRS00559 986014830 111061 025911023A DRS0470 S12BH0619A2 433335 88212233 22.0298 8212233 RNL1483 91911023A 91911023B 25-0385 10683 AES7190 0001211254Video/Publications
0001208425 0001208426 0001208428 0001208429 0001211251 0001211252 0001211253 0001211254 025911023 025911023A 025911023AX 091911023A 091911023B 091911023BX 0986010470 0986014830 10298 10683 111061 11397 16722R 17066N 20401145BN 22.0298 22.0298M 22.0683 22.0683M 25-0385 25-0457 3639 42014830 433335 455625 6010541 8010470 8014830 8212233 8212385 88212233 88212385 8EA726057-001 8EA730199-001 AES5159 AES7190 ALT136080 B001208256 CS298 CS683 CST10541AS DRS0470 DRS4830 EAA-121398 LRS00559 LRS00790 LRS559 LRS790 RNL1483 S0077 SS819 STR50039 STRS883 STRS928 220356 220357Add Your Number
