Associated Numbers
0001109018 0001110092 0001110102 0001110124 0986016870 101037 10286 111619 11682 20401841BN 20401841OE 20401841RC 20401941BN 20401941OE 20401941RC 22.1037 25-2166 254858 26943 26945 26946 30665N 31199N 35258840 3647 42014701 42016870 438053 455873 46430721 46439700 46554407 6010148 6010149 63112003 7692102 7770210 8016870 8213247 88213247 8EA012526-641 8EA737254-001 AES1250 AES6165 CS1037 CST10148AS CST10148GS CST10148RS CST10149AS CST10149GS CST10149RS DRS6870 EAA-121143 GS109018-A GS109018B-R LRT00150 S0105 SS268 SS291 SS434 STR50113Specifications
Kilowatt | 1.7 kW |
Length (L.1) | 240 mm |
Mount Hole Center - Center (O.1) | 114 mm |
Mount Hole Center - Center (O.2) | 75.5 mm |
Mount Hole Center - Center (O.3) | 79 mm |
Mount Hole Diameter (C.1) | M8x1.25 mm |
Mount Hole Diameter (C.2) | M8x1.25 mm |
Mount Hole Diameter (C.3) | M8x1.25 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 3 qty |
No./Teeth | 9 qty |
No./Teeth (Replaces) | 9. 10. 11 qty |
Pinion at Rest (B) | 23 mm |
Rotation | CW |
Spigot Diameter (A) | 82 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
FIAT | Fiorino 1.7 TD | [146D7.000] | 06.1999-12.2001 |
FIAT | Palio 1.7 TD | [176A3.000] | 04.1996-03.2001 |
FIAT | Punto 1.7 Diesel | [176B3.000] | 08.1993-08.1999 |
FIAT | Punto 1.7 TD | [176A3.000] | 01.1994- |
FIAT | Punto 1.7 TD | [176A5.000] | 01.1994-08.1999 |
FIAT | Punto 1.7 TD | [176B7.000] | 09.1996- |
FIAT | Strada 1.7 TD | [176A3.000] | 06.1999- |
Reference Information
8EA012526-641 CST10149RS 20401941BN 20401841BN SS434 8EA737254-001 7716766 986016870 7609068 30665N 20401841OE LRT00150 MAV175000 CST10149AS 7770210 S12BH0029A2 46440079 63112003 000986016870 20401941OE 71723359 0001109018 1110102 46446291 42014701 SS268 EAA-121143 0001110124 20401841RC CST10149GS GS109018-A 0001110092 438053 S0105 CS374 AES6165 7597118 101037 MAV6340 3647 6010148 20401941RC 254858 6010149 CST10148RS MAV6700 8016870 113752 SE138908000A 111619 ANM19090X 220216 CS1037 SS291 46439669 CST10148AS STM529 220185 220460 STR00256 22.1037 11682 GS109018B-R 88213247 STR50113 1110092 STRL007 8213247 DRS6870 STR1367 1109018 1110124 46554407 46430721 31199N RNL1687 7692102 46439700 26943 26946 CST10148GS 0001110102 26945 STR1328 4643970 7696102 42016870 25-2166 AES1250 10286 7716192 71782403 35258840 455873Video/Publications
0001109018 0001110092 0001110102 0001110124 0986016870 101037 10286 111619 113752 11682 20401841BN 20401841OE 20401841RC 20401941BN 20401941OE 20401941RC 22.1037 25-2166 254858 26943 26945 26946 30665N 31199N 35258840 3647 42014701 42016870 438053 455873 46430721 46439700 46554407 6010148 6010149 63112003 7692102 7770210 8016870 8213247 88213247 8EA012526-641 8EA737254-001 AES1250 AES6165 CS1037 CS374 CST10148AS CST10148GS CST10148RS CST10149AS CST10149GS CST10149RS DRS6870 EAA-121143 GS109018-A GS109018B-R LRT00150 MAV175000 MAV6340 MAV6700 RNL1687 S0105 SS268 SS291 SS434 STR50113 STRL007 220185 220216 220460Add Your Number
Contact Details
Request More Information
Add your number to the message box below and we will add it to our system
View your shopping basket or Browse other items in Starter Motors.
