Associated Numbers
0001218116 0001218117 02B911023A 02B911023AX 0986016340 10599 112052 11719 17234N 17234R 20401753BN 22.0599 25-1361 300.522.103 35259480 3812 42016340 455629 6010357 8016340 88213086 8EA726223-001 AES8193 CS599 CST10357AS DRS6340 EAA-121331 LRS00893 S0142 SS348 STR50145Specifications
Kilowatt | 2.2 kW |
Length (L.1) | 294 mm |
Mount Hole Center - Center (O.1) | 102 mm |
Mount Hole Center - Center (O.2) | 102 mm |
Mount Hole Center - Center (O.3) | 107 mm |
Mount Hole Diameter (C.1) | 9 mm |
Mount Hole Diameter (C.2) | 9 mm |
Mount Hole Diameter (C.3) | 9 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
No./Teeth (Replaces) | 10 qty |
Pinion at Rest (B) | 52 mm |
Rotation | ACW |
Spigot Diameter (A) | 76 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
VW | Transporter 2.4 Diesel | [AAB] | 09.1990-11.1994 |
VW | Transporter 2.4 Diesel Syncro | [AAB] | 11.1992-04.2003 |
Reference Information
02B911023AX STR1991 CST10357AS S12BH0624A2 220035 EAA-121331 LRS00893 42016340 02B911023A 20401753BN 112052 STA0069R 0001218116 028911023A AES8193 1516783R 0001218117 3812 6010357 25-1361 2180 88213086 8016340 SX 35259480 STRS183 5010484 330751 SS348 02B911023LX 986016340 CS599 11719 220054 ANM18560X 000986016340 17234R S0142 22.0599 17234N STR50145 1218116 8EA726223-001 DRS6340 1218117 LRS893Video/Publications
0001218116 0001218117 02B911023A 02B911023AX 0986016340 112052 11719 17234N 17234R 20401753BN 22.0599 25-1361 35259480 3812 42016340 6010357 8016340 88213086 8EA726223-001 AES8193 CS599 CST10357AS DRS6340 EAA-121331 LRS00893 LRS893 S0142 SS348 STR50145 STRS183 SX 2180 220035 220054Add Your Number
