Associated Numbers
0001223006 0051512501 0986020360 20401303BN 20401303OE 20401303RC 25-3255 254377 6010303 AEY1705 CST10303AS CST10303GS CST10303RS EAA-121368 LRS01705 S0203 STR22126Specifications
| Kilowatt | 2.3 kW |
| Length (L.1) | 272 mm |
| Mount Hole Center - Center (O.1) | 89 mm |
| Mount Hole Diameter (C.1) | M10x1.5 mm |
| Mount Hole Diameter (C.2) | M10x1.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 10 qty |
| No./Teeth (Replaces) | 10 qty |
| Pinion at Rest (B) | 26 mm |
| Rotation | CW |
| Spigot Diameter (A) | 60 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| MERCEDES BENZ | E 400 4.0 CDi | -211 | 01.2003-12.2005 |
| MERCEDES BENZ | E 400 4.0 CDi | (211) | 01.2003-12.2005 |
| MERCEDES BENZ | G 400 4.0 CDi | (463)[OM628.962] | 12.2000- |
| MERCEDES BENZ | ML 400 4.0 CDi | (163)[OM628.963] | 09.2001-06.2005 |
| MERCEDES BENZ | S 400 4.0 CDi | (220)[OM628.960] | 06.2000-08.2005 |
Reference Information
000986020360 20401303RC AEY1705 MAV123030 CST10303GS 51512501 STR22126 LRS1705 LRS01705 20401303OE 5151250180 1223006 EAA-121368 A0051512501 0001223006 S12BH0469A2 STR1668 CST10303AS S0203 25-3255 STRS887 A005151250180 254377 986020360 20401303BN CST10303RS 6010303Video/Publications
0001223006 0051512501 0986020360 20401303BN 20401303OE 20401303RC 25-3255 254377 6010303 AEY1705 CST10303AS CST10303GS CST10303RS EAA-121368 LRS01705 LRS1705 MAV123030 S0203 STR22126 STRS887Add Your Number
