Associated Numbers
0001109008 0001109043 101340 101340M 114106 20401542BN 20401542OE 25-2124 50353510 50353511 6010245 CST10245AS CST10245GS DRS3974 EAA-121427 LRS01330 RNL109043 S0211 STR22083`Specifications
Kilowatt | 1.6 kW |
Length (L.1) | 265 mm |
Mount Hole Center - Center (O.1) | 102 mm |
Mount Hole Diameter (C.1) | 12.5 mm |
Mount Hole Diameter (C.2) | 12.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
No./Teeth (Replaces) | 9 qty |
Pinion at Rest (B) | 40 mm |
Rotation | CW |
Spigot Diameter (A) | 82 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HATZ | 1D20 Industrial Engine | 01.1991- | |
HATZ | 1D30 Industrial Engine | 01.1991- | |
HATZ | 1D40 Industrial Engine | 01.1991- | |
HATZ | 1D40 LWA Industrial Engine | 01.1991- |
Reference Information
STR1513 1109008 20401542OE 114106 1109043 MAV122450 ANM16194X CST10245AS 20401542BN S0211 STR22083` STRS717 05726003R CST10245GS LRS1330 101340 50353511 50353510 25-2124 101340M EAA-121427 DRS3974 0001109043 LRS01330 6010245 RNL109043 0001109008Video/Publications
0001109008 0001109043 101340 101340M 114106 20401542BN 20401542OE 25-2124 50353510 50353511 6010245 CST10245AS CST10245GS DRS3974 EAA-121427 LRS01330 LRS1330 MAV122450 RNL109043 S0211 STR22083` STRS717Add Your Number
