Associated Numbers
0001106012 0001106017 0001106022 0986018360 0986018770 0986021030 101179 101179B 11914 20401952BN 20401952OE 22.1179 25-2493 25-3161 3000 458189 458263 6010259 7700115294 7700875450 8018770 8200050150 8200186144 8212553 8253505 88212553 8EA737763-001 AES2235 B001109104 CS1179 CST10259AS CST10259GS DRS8770 LRS01632 LRT00235 S0225 SS608 STR50213 31235N 31235RSpecifications
Kilowatt | 0.9 kW |
Length (L.1) | 207 mm |
Mount Hole Center - Center (O.1) | 93 mm |
Mount Hole Center - Center (O.2) | 22 mm |
Mount Hole Center - Center (O.3) | 64 mm |
Mount Hole Center - Center (O.4) | 105 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
Mount Hole Diameter (C.3) | M10x1.5 mm |
Mount Hole Diameter (C.4) | M10x1.5 mm |
No./Mount holes | 4 qty |
No./Mount holes with thread | 4 qty |
No./Teeth | 9 qty |
No./Teeth (Replaces) | 9 qty |
Pinion at Rest (B) | 0 mm |
Rotation | CW |
Spigot Diameter (A) | 66 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
RENAULT | Clio 2.0 16V | [F4736] | 06.2001- |
RENAULT | Clio 2.0 16V Sport | [F4730] | 02.2000- |
RENAULT | Clio 2.0 16V Sport | [F4738] | 01.2004-10.2007 |
RENAULT | Espace 2.0 | [F4700] | 09.2001-10.2002 |
RENAULT | Espace 2.0 | [F4701] | 09.2001-10.2002 |
RENAULT | Espace 2.0 16V | [F4700] | 10.1998-10.2002 |
RENAULT | Espace 2.0 16V | [F4701] | 07.2000-10.2002 |
RENAULT | Laguna 1.8 16V | [F4P760] | 04.1998-03.2001 |
RENAULT | Laguna 1.8 16V | [F4P770] | 03.2001- |
RENAULT | Laguna 1.8 16V | [F4P771] | 03.2001- |
RENAULT | Laguna 1.8 16V | [F4P773] | 03.2001- |
RENAULT | Laguna 1.8 16V | [F4P774] | 03.2001- |
RENAULT | Laguna 1.8 16V | [F4P775] | 03.2001- |
RENAULT | Laguna 2.0 | [F4780] | 09.1999-02.2001 |
RENAULT | Laguna 2.0 16V | [F4715] | 09.2001- |
RENAULT | Laguna 2.0 16V | [F4780] | 09.1999-03.2001 |
RENAULT | Megane 1.8 16V | [F4P720] | 03.1999-09.2003 |
RENAULT | Megane 1.8 16V | [F4P722] | 03.1999-09.2003 |
RENAULT | Megane 2.0 16V | [F4746] | 09.2001-10.2002 |
RENAULT | Megane 2.0 16V | [F4770] | 10.2003- |
RENAULT | Megane 2.0 16V | [F7714] | 03.1999-10.2002 |
RENAULT | Megane 2.0 IDE 16V | [F5740] | 11.1999- |
RENAULT | Scenic 1.8 16V | [F4P720] | 11.2000-04.2003 |
RENAULT | Scenic 1.8 16V | [F4P722] | 09.2000-04.2003 |
RENAULT | Scenic 1.8 4x4 | [F4P722] | 07.2000-04.2001 |
RENAULT | Scenic 2.0 16V | [F4740] | 03.1999- |
RENAULT | Scenic 2.0 16V | [F4741] | 03.1999-04.2003 |
RENAULT | Scenic 2.0 16V RX4 | [F4744] | 06.1999-04.2003 |
RENAULT | Scenic 2.0 IDE 16V | [F4740] | 03.2000-08.2003 |
RENAULT | Scenic 2.0 IDE 16V | [F4741] | 03.2000-08.2003 |
RENAULT | Scenic 2.0 IDE 16V | [F4744] | 03.2000-08.2003 |
Reference Information
8200186144 CST10259GS 000986021030 101179B STA0293R 0001106012 1106012 3000 331331 AES2235 CS1179 STR50213 8200724786 986018770 8200466761 22.1179 25-3161 000986018770 1106017 6010259 STR1221 STR1706 S0225 7700872450 11914 986021030 LRS1632 7700115294 ANM10990X B001109104 8018770 000986018360 STRS154 7711134301 31235N 5010452 31235R 8253505 S12BH0475A2 7700875450 8EA737763-001 88212553 25-2493 DRS8770 8200466744 8200050150 8212553 220923 0001106022 20401952BN 1106022 SS608 986018360 LRT00235 LRS01632 000B001109104 MAV122590 101179 458263 458189 8200724817 20401952OE CST10259AS 0001106017Video/Publications
0001106012 0001106017 0001106022 0986018360 0986018770 0986021030 101179 101179B 11914 20401952BN 20401952OE 22.1179 25-2493 25-3161 3000 31235N 31235R 458189 458263 6010259 7700115294 7700875450 8018770 8200050150 8200186144 8212553 8253505 88212553 8EA737763-001 AES2235 B001109104 CS1179 CST10259AS CST10259GS DRS8770 LRS01632 LRS1632 LRT00235 MAV122590 S0225 SS608 STR50213 STRS154 220923Add Your Number
