Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 279.94 including GST
NZ$ 243.43 excluding GST
or four payments of $69.99
with
Learn More
each
S0229(SEG)
S0229
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
0001123020Associated Numbers
0001123020 0001123021 0AH911023B 0AH911023BX 101397 101397B 114173 12220 20401544 25-4145 300.587.103 32688N 32688R 6010445 88213300 8EA012528-051 8EA738258-721 944280203200 CS1397 CST10445 CST10445AS CST10445ES CST10445GS CST10445OS CST10445RS DRT0320 DT1430 EAA-121267 MRS20320 RAS41431 S0229 SG0691 STB1397 STR50512Specifications
| Kilowatt | 1.70 kW |
| Length (L.1) | 244 mm |
| Mount Hole Center - Center (O.1) | 127.50 mm |
| Mount Hole Center - Center (O.2) | 18 mm |
| Mount Hole Center - Center (O.3) | 112 mm |
| Mount Hole Diameter (C.1) | 12.50 mm |
| Mount Hole Diameter (C.2) | 12.50 mm |
| Mount Hole Diameter (C.3) | 12.50 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| No./Teeth (Replaces) | 10 qty |
| OEM Product | No |
| Pinion at Rest (B) | 57 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | ACW |
| Spigot Diameter (A) | 76 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| VW | Caddy 2.0 SDi | [BDJ] | 03.2004-08.2010 |
| VW | Caddy 2.0 SDi | [BST] | 03.2004-08.2010 |
Reference Information
| 0001123020 | BOSCH |
| 0001123020-R | SEG |
| 0001123021 | BOSCH |
| 063721397010 | MAGNETI MARELLI |
| 0986020320 | BOSCH |
| 0AH911023B | VW |
| 0AH911023BX | VW |
| 10010445OV | ITAB AUTOMOTIVE |
| 101397 | KUHNER |
| 101397B | KUHNER |
| 10439666 | ALANKO |
| 105510 | FARCOM |
| 11020320 | EUROTEC |
| 114173 | CARGO |
| 12220 | EAI |
| 1638131880 | EUROREPAR |
| 193197 | FEBI BILSTEIN |
| 1986S00800 | BOSCH |
| 20401544OE | REAL |
| 220ST21 | STARTCAR |
| 221065A | ERA |
| 25-4145 | ELSTOCK |
| 2S0234 | RIDEX |
| 300.587.103.010 | PSH |
| 300.587.103.210 | PSH |
| 300.587.103.211 | PSH |
| 300.587.103.280 | PSH |
| 300.587.103.461 | PSH |
| 3043 | CEVAM |
| 311264102 | DRI |
| 3116947 | HENKEL PARTS |
| 3116948 | HENKEL PARTS |
| 32688N | WAI / TRANSPO |
| 32688R | WAI / TRANSPO |
| 331409 | LOGISTIK |
| 42000027 | HERTH+BUSS |
| 458875 | VALEO |
| 4720350 | NK |
| 5010983 | MEAT & DORIA |
| 5010983G | MEAT & DORIA |
| 6010445.1 | SANDO |
| 8020320 | FRIESEN |
| 88213300 | POWERMAX |
| 8EA012528-051 | HELLA |
| 943213971010 | MAGNETI MARELLI |
| 944280203200 | MAGNETI MARELLI |
| A20320 | ATL AUTOTECHNIK |
| AC-CBS1397 | ACAUTO |
| AI-80055 | AINDE |
| AZMT-53-010-1040 | A.Z. MEISTERTEILE |
| BST2591 | BORG & BECK |
| CMA-621267 | COMLINE |
| CS1397 | HC PARTS |
| CST10445GS | CASCO |
| DRT0320 | DELCO |
| DRT0320X | DELCO |
| EZ0128 | ELTA AUTOMOTIVE |
| F032114173 | CARGO |
| LRS02473 | LUCAS |
| LRS2473 | LUCAS |
| MRS20320 | MAGNETI MARELLI |
| QRS1845 | QUINTON HAZELL |
| RE83659N | THE NEW LINE |
| S0229 | AS-PL |
| S12BH0951 | SIDAT |
| S132.069 | PSH |
| S143.978 | PSH |
| S-50512 | DTS |
| SBO445 | AUTOTEAM |
| SEG0001123020 | WOODAUTO |
| SG0691 | GHIBAUDI |
| SKSTR-0330233 | STARK |
| ST01658 | TMI |
| STB1397 | KRAUF |
| STM1237 | ROLLCO |
| STR1561 | ELECTROLOG |
| STR50512 | WOODAUTO |
| STRS880 | 3EFFE |
| STX200188R | STARDAX |
| TT15339 | TESLA |
| TT15339 PRO | TESLA |
| VW9093 | SNRA |
| WG2378129 | WILMINK GROUP |
| WOOSTR50512 | WOODAUTO |
