Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 388.87 including GST
NZ$ 338.15 excluding GST
or four payments of $97.22
with
Learn More
UOM:
each
Product Code:
S0236
Quantity In Stock Nationally
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
0001218003Associated Numbers
0001218003 0001218020 0001218620 0986010600 0986010601 10155 10361 111115 11165 11534 20401681BN 20401681RC 20479741RC 22.0361 25-1065 30650R 3433 42001195 433215 433326 580285 6010186 6015147 8010600 8EA726109-001 9558385480 95619197 AES6150 CS361 CST10186AS CST10186RS CST15147RS D9R90 DRS3078 EAA-121397 LRS00650 ND055 S0236 SS117 SS306 STR50108 VS281Specifications
| Kilowatt | 2.20 kW |
| Length (L.1) | 283 mm |
| Mount Hole Center - Center (O.1) | 81 mm |
| Mount Hole Center - Center (O.2) | 115 mm |
| Mount Hole Center - Center (O.3) | 81 mm |
| Mount Hole Diameter (C.1) | M7x1.0 mm |
| Mount Hole Diameter (C.2) | M7x1.0 mm |
| Mount Hole Diameter (C.3) | M7x1.0 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 3 qty |
| No./Teeth | 12 qty |
| No./Teeth (Replaces) | 11. 12 qty |
| OEM Product | No |
| Pinion at Rest (B) | 28 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 82 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CITROEN | C25 2.5 Diesel | [CRD93L] | 07.1981-02.1994 |
| CITROEN | C25 2.5 Diesel | 11.1981-01.1994 | |
| CITROEN | C25 2.5 Diesel 4x4 | [CRD93L] | 01.1987-02.1994 |
| CITROEN | C25 2.5 TD | [CRD93LS] | 08.1987-02.1994 |
| CITROEN | C25 2.5 TD 4x4 | [CRD93LS] | 08.1987-02.1994 |
| CITROEN | CX 2500 2.5 Diesel | [M25-629] | 02.1978-08.1985 |
| CITROEN | CX 25 2.5 Diesel | [M25-660] | 08.1985-12.1992 |
| CITROEN | CX 25 2.5 TD | [M25-648] | 04.1983-12.1986 |
| CITROEN | CX 25 2.5 TD | [M25-669] | 01.1987-12.1992 |
| CITROËN | C25 Bus (280_, 290_) 2.5 D | CRD93L(U25/661) | 10.1985-02.1994 |
| CITROËN | C25 Bus (280_, 290_) 2.5 D | CRD93L(U25/661) | 11.1981-01.1994 |
| CITROËN | C25 Bus (280_, 290_) 2.5 D 4x4 | CRD93L(U25/661) | 01.1987-02.1994 |
| CITROËN | C25 Bus (280_, 290_) 2.5 D Turbo | CRD93LS(U25/673) | 08.1987-02.1994 |
| CITROËN | C25 Bus (280_, 290_) 2.5 D Turbo 4x4 | CRD93LS(U25/673) | 08.1987-02.1994 |
| CITROËN | C25 Platform/Chassis (280_, 290_) 2.5 D | CRD93L(U25/661) | 11.1983-01.1994 |
| CITROËN | C25 Platform/Chassis (280_, 290_) 2.5 DT | CRD93LS(U25/673) | 01.1987-01.1994 |
| CITROËN | C25 Van (280_, 290_) 2.5 D | CRD93L(U25/661) | 02.1985-07.1994 |
| CITROËN | C25 Van (280_, 290_) 2.5 D | CRD93L(U25/661) | 11.1981-01.1994 |
| CITROËN | C25 Van (280_, 290_) 2.5 D 4x4 | CRD93L(U25/661) | 11.1983-12.1986 |
| CITROËN | C25 Van (280_, 290_) 2.5 DT | CRD93LS(U25/673) | 08.1991-01.1994 |
| CITROËN | C25 Van (280_, 290_) 2.5 DT 4x4 | CRD93LS(U25/673) | 08.1991-01.1994 |
| CITROËN | CX I Break (MA) 2500 D | M25/629 | 02.1978-08.1985 |
| CITROËN | CX I Break (MA) 2500 D Turbo | M25/648 | 04.1983-08.1985 |
| CITROËN | CX II 25 D | M25/660 | 08.1985-12.1992 |
| CITROËN | CX II 25 D Turbo | M25/648 | 08.1985-12.1986 |
| CITROËN | CX II 25 D Turbo | M25/669 | 01.1987-12.1992 |
| CITROËN | CX II Break 2500 D Turbo | M25/648 | 08.1985-12.1986 |
| CITROËN | CX II Break 25 D | M25/660 | 05.1986-12.1992 |
| CITROËN | CX II Break 25 D Turbo 2 | M25/669 | 01.1987-12.1992 |
| CITROËN | CX I (MA) 2500 D | M25/629 | 02.1978-06.1982 |
| CITROËN | CX I (MA) 25 D Turbo | M25/648 | 04.1983-08.1985 |
| PEUGEOT | J5 2.5 Diesel | [CRD93] | 07.1987-12.1993 |
| PEUGEOT | J5 2.5 TD | [CRD93LS] | 10.1990-12.1993 |
| PEUGEOT | J5 2.5 TD 4x4 | [CRD93LS] | 10.1990-12.1993 |
| PEUGEOT | J5 Bus (280P) 2.5 D | CRD93(PSA) | 09.1981-09.1990 |
| PEUGEOT | J5 Bus (280P) 2.5 DT | CRD93L | 01.1986-08.1990 |
| PEUGEOT | J5 Bus (290P) 2.5 D | CRD93(PSA) | 10.1990-02.1994 |
| PEUGEOT | J5 Bus (290P) 2.5 D 4x4 | CRD93(PSA) | 10.1990-02.1994 |
| PEUGEOT | J5 Bus (290P) 2.5 TD | CRD93LS(U25/673) | 10.1990-02.1994 |
| PEUGEOT | J5 Bus (290P) 2.5 TD 4x4 | CRD93LS(U25/673) | 10.1990-02.1994 |
| PEUGEOT | J5 Platform/Chassis (280L) 2.5 D | CRD93(PSA) | 09.1981-09.1990 |
| PEUGEOT | J5 Platform/Chassis (280L) 2.5 DT | CRD93L | 09.1981-08.1990 |
| PEUGEOT | J5 Platform/Chassis (290L) 2.5 D | CRD93(PSA) | 10.1990-02.1994 |
| PEUGEOT | J5 Platform/Chassis (290L) 2.5 D 4x4 | CRD93(PSA) | 10.1990-02.1994 |
| PEUGEOT | J5 Platform/Chassis (290L) 2.5 TD | CRD93LS(U25/673) | 10.1990-02.1994 |
| PEUGEOT | J5 Platform/Chassis (290L) 2.5 TD 4x4 | CRD93LS(U25/673) | 10.1990-02.1994 |
| PEUGEOT | J5 Van (280L) 2.5 D | CRD93 | 09.1981-08.1990 |
| PEUGEOT | J5 Van (280L) 2.5 DT | CRD93L | 09.1981-08.1990 |
| PEUGEOT | J5 Van (280L) 2.5 DT | CRD93LS(U25/673) | 09.1981-08.1990 |
| PEUGEOT | J5 Van (290L) 2.5 D | CRD93 | 09.1990-01.1994 |
| PEUGEOT | J5 Van (290L) 2.5 D 4x4 | CRD93(PSA) | 10.1990-03.1994 |
| PEUGEOT | J5 Van (290L) 2.5 DT | CRD93L | 09.1990-01.1994 |
| PEUGEOT | J5 Van (290L) 2.5 TD 4x4 | CRD93LS(U25/673) | 10.1990-03.1994 |
| TALBOT | Express 2.5 Diesel | [CRD93] | 09.1981-12.1993 |
| TALBOT | Express 2.5 Diesel | CRD93 | 09.1981-10.1994 |
| TALBOT | Express 2.5 Diesel 4x4 | [CRD93] | 09.1981-12.1993 |
| TALBOT | Express 2.5 Diesel 4x4 | CRD93 | 09.1981-10.1994 |
| TALBOT | Express 2.5 TD | [CRD93LS] | 06.1987-12.1993 |
| TALBOT | Express 2.5 TD | CRD93LS | 06.1987-10.1994 |
| TALBOT | Express 2.5 TD 4x4 | [CRD93LS] | 11.1988-12.1993 |
| TALBOT | Express 2.5 TD 4x4 | CRD93LS | 11.1988-10.1994 |
Reference Information
| 0001218003 | BOSCH |
| 0001218020 | BOSCH |
| 0001218620 | BOSCH |
| 0986010600 | BOSCH |
| 0986010601 | BOSCH |
| 10155 | KUHNER |
| 10361 | KUHNER |
| 111115 | CARGO |
| 11165 | EAI |
| 11534 | EAI |
| 1516750R | DAF |
| 20401681BN | REAL |
| 20401681RC | REAL |
| 20479741RC | REAL |
| 220127 | ERA |
| 22.0361 | LAUBER |
| 220.501.123.010 | WAI |
| 220.501.123.460 | WAI |
| 25-1065 | ELSTOCK |
| 30650R | WAI |
| 330513 | LOGISTIK |
| 3433 | CEVAM |
| 42001195 | HERTH+BUSS |
| 433215 | VALEO |
| 433326 | VALEO |
| 555832 | PEUGEOT |
| 5802-49 | PEUGEOT |
| 580249 | PEUGEOT |
| 5802-71 | PEUGEOT |
| 580271 | PEUGEOT |
| 580285 | PEUGEOT |
| 5802-93 | PEUGEOT |
| 580293 | PEUGEOT |
| 5802-EJ | PEUGEOT |
| 5802EJ | PEUGEOT |
| 5802-EN | PEUGEOT |
| 5802EN | PEUGEOT |
| 5802-K6 | PEUGEOT |
| 5802K6 | PEUGEOT |
| 5802-L5 | PEUGEOT |
| 5802L5 | PEUGEOT |
| 5802-P7 | PEUGEOT |
| 5802P7 | PEUGEOT |
| 5802-S2 | PEUGEOT |
| 5802S2 | PEUGEOT |
| 6010186 | SANDO |
| 6015147 | SANDO |
| 8010600 | FRIESEN |
| 8EA726109-001 | HELLA |
| 91535770 | FIAT |
| 91535771 | PEUGEOT |
| 95495849 | PEUGEOT |
| 95580180 | PEUGEOT |
| 95580180R | PEUGEOT |
| 95580181 | PEUGEOT |
| 95580181R | PEUGEOT |
| 95583854 | PEUGEOT |
| 9558385480 | PEUGEOT |
| 95619197 | PEUGEOT |
| 95619197R | PEUGEOT |
| AES6150 | AUTOELECTRO |
| ALT131010 | SIOM |
| ALT131100 | SIOM |
| ANM15298X | ANDEL |
| CS361 | HC PARTS |
| CST10186AS | CASCO |
| CST10186RS | CASCO |
| CST15147RS | CASCO |
| D9R90 | VALEO |
| DRS3078 | DELCO |
| F032111115 | CARGO |
| LRS00650 | LUCAS |
| LRS650 | LUCAS |
| MAV121860 | SIOM |
| MAV171470 | SIOM |
| ND055 | VALEO |
| PRSF429 | 3EFFE |
| RNL1060 | RNL |
| S0236 | AS-PL |
| S12BH0343A2 | SIDAT |
| S131.601 | WAI |
| SS117 | SOVEREIGN |
| SS306 | SOVEREIGN |
| STA0365R | BOVEZ |
| STR1987 | ELECTROLOG |
| STR50108 | WOODAUTO |
| STRS238 | 3EFFE |
| STX200356 | STARDAX |
| STX200356R | STARDAX |
| STX200666 | STARDAX |
| VS281 | VALEO |
Video/Publications
S0236View your shopping basket or Browse other items in Starter Motors.
