Associated Numbers
0001367077 0001367081 0986024000 101205 101205K 101205M 101376 11.130.739 112442 116130 19655N 19655R 20401822BN 20401822OE 22.1205 25-2226 25-3148 260-67143 6010228 630.009.103 7700045291 8679 88212819 8EA737878-001 91-15-7151 9142745 AL70852 AL81154 AZJ3261 CS1205 CST10228 CST10228AS CST10228ES CST10228GS CST10228OS CST10228RS DRS3818 EAA-111216 LRS01622 RE501157 RE504807 SE501856 STB1205 STR22096Specifications
Kilowatt | 3 kW |
Length (L.1) | 340 mm |
Mount Hole Center - Center (O.1) | 127 mm |
Mount Hole Center - Center (O.2) | 90 mm |
Mount Hole Center - Center (O.3) | 90 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
Mount Hole Diameter (C.3) | 11 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
No./Teeth (Replaces) | 10 qty |
Oil Sealed | No |
Pinion at Rest (B) | 48 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
JOHN DEERE | 6205 | 01.1994- | |
JOHN DEERE | 6505 | 01.1994- | |
JOHN DEERE | 6506 | ||
JOHN DEERE | 6510 | 01.1994- | |
JOHN DEERE | 6520 | 01.1994- | |
JOHN DEERE | 6610 | 01.1994- | |
JOHN DEERE | 6620 | 01.1994- | |
JOHN DEERE | 6810 10.0 | 08.1991- | |
JOHN DEERE | 6820 | 01.1994- | |
JOHN DEERE | 6910 | 01.1994- | |
JOHN DEERE | 6920 | 01.1994- |
Reference Information
RE504807 112442 331357 RE501157 260-67143 STR10228 0001367081 1367081 STR22096 SE501856 AL70852 STB1205 STRS677 91-15-7151 MAV122280 25-3148 S0250 CST10228AS CST10228GS LRS1622 LRS01622 ANM16038X 0001367077 7700045291 1367077 20401822OE 630.009.103.010 DS4928 RE503226 CS1205 PRSS677 DRS3818 20401822BN 9142745 EAA-111216 8679 19655N 6010228.1 6010228 AL81154Video/Publications
STR22096 91-15-7151 19655N MAV122280 6010228.1 6010228.0 7700045291 20401822OE 20401822BN 630.009.103.010 9142745 LRS1622 LRS01622 STB1205 RE501157 AL81154 AL70852 CS1205 25-3148 EAA-111216 260-67143 DS4928 DRS3818 8679 CST10228GS CST10228AS 112442 0001367081 0001367077 STRS677 PRSS677 S0250Add Your Number
