Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 447.58 including GST
NZ$ 389.20 excluding GST
or four payments of $111.90
with
Learn More
each
S0254
No stock in NZ - Call us for possible procurement options
No stock in NZ - Call us for possible procurement options
Associated Numbers
0001360056 0001368028 0021515601 0031511301 0986012940 0986012943 10120 10120K 10120P 10718 10718B 11.130.660 11130660 116040 18250N 19024214 19024258 20401696BN 220337 254150 260-67217 31511301 33470 35261450 439811 45-1227 45-1249 455617 551.010.093 553784RIV 6010696 7431027000 861036 8698 88214012 91-15-7063 943252201 943252234 A0031511301 AZJ3213 B001816204 BOS0001368028 CST10696 CST10696AS CST10696ES CST10696GS CST10696OS CST10696RS DRS2940 EAA-111122 IS0660 LRS01853 MS270 MSR716 STR50168Specifications
| Kilowatt | 4 kW |
| Length (L.1) | 340 mm |
| Mount Hole Center - Center (O.1) | 127 mm |
| Mount Hole Center - Center (O.2) | 89 mm |
| Mount Hole Center - Center (O.3) | 89 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| Mount Hole Diameter (C.3) | 11 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 48 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Unit Type | BOSCH |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| KASSBOHRER | S208H | [OM352.900] | 01.1979-12.1983 |
| MERCEDES BENZ TRUCKS & BUSES | Unimog U1100T | OM353.940 | 01.1989-12.2001 |
| MERCEDES BENZ TRUCKS & BUSES | Unimog U1150L | 01.1988- | |
| MERCEDES BENZ TRUCKS & BUSES | Unimog U1150U | 01.1988- | |
| MERCEDES BENZ TRUCKS & BUSES | Unimog U1650L | 01.1991- | |
| MERCEDES BENZ TRUCKS & BUSES | Unimog U1650U | 01.1991- | |
| MERCEDES BENZ TRUCKS & BUSES | Unimog U2400TG | 01.1993- | |
| MERCEDES BENZ TRUCKS & BUSES | Unimog U800 | 01.1988-12.1990 |
Reference Information
| 0001360056 | BOSCH |
| 0001368028 | BOSCH |
| 0021515601 | MERCEDES |
| 0031511301 | MERCEDES |
| 003151130180 | MERCEDES |
| 003151135680 | MERCEDES |
| 0986012940 | BOSCH |
| 0986012943 | BOSCH |
| 10120 | KUHNER |
| 10120K | KUHNER |
| 10120P | KUHNER |
| 10718 | KUHNER |
| 10718B | KUHNER |
| 11130660 | ISKRA / LETRIKA |
| 11.130.660 | ISKRA / LETRIKA |
| 116040 | CARGO |
| 18250N | WAI / TRANSPO |
| 19024214 | DELCO |
| 19024258 | DELCO |
| 20401696BN | REAL |
| 220232 | ERA |
| 220337 | ERA |
| 254150 | KUHNER |
| 260-67217 | DIXIE |
| 31511301 | MERCEDES |
| 331764 | LOGISTIK |
| 33470 | EAI |
| 35261450 | PRESTOLITE |
| 45-1227 | ELSTOCK |
| 45-1249 | ELSTOCK |
| 455617 | VALEO |
| 551.010.093 | PSH |
| 551.010.093.460 | PSH |
| 6010696 | SANDO |
| 7431027000 | KASSBOHRER |
| 8010301 | ZM |
| 861036 | PRESTOLITE |
| 8698 | CEVAM |
| 88214012 | POWERMAX |
| 9000083064 | BOSCH |
| 91-15-7063 | WILSON |
| 943252201 | MAGNETI MARELLI |
| 943252234 | MAGNETI MARELLI |
| A0021515601 | MERCEDES |
| A0031511301 | MERCEDES |
| A003151130180 | MERCEDES |
| A003151135680 | MERCEDES |
| ANM15160X | ANDEL |
| AZJ3213 | ISKRA / LETRIKA |
| B001816204 | BOSCH |
| BOS0001368028 | WOODAUTO |
| CST10696 | CASCO |
| CST10696AS | CASCO |
| CST10696ES | CASCO |
| CST10696GS | CASCO |
| CST10696OS | CASCO |
| CST10696RS | CASCO |
| DRS2940 | DELCO |
| F032116040 | CARGO |
| IS0660 | ISKRA / LETRIKA |
| LRS01853 | LUCAS |
| LRS1853 | LUCAS |
| MAV126120 | SIOM |
| MAV126960 | SIOM |
| MS270 | MAHLE |
| MS 270 | MAHLE |
| MSR716 | MAGNETI MARELLI |
| STR1632 | ELECTROLOG |
| STR50168 | WOODAUTO |
| STR7994 | ELECTROLOG |
| STRW475 | 3EFFE |
| ZM8010301 | ZM |
Video/Publications
