Associated Numbers
0001109330 0001109331 11.131.556 11.131.750 113900 120-6114 18954N 2-3005-BO 20401184OE 254489 254489B 6004AA3014 6010481 8214287 AZE6544 CST10481GS EAA-121480 F000AL0114 F000AL0115 IS1154 RE508922 RE540304 SE501844 STR50452Specifications
Kilowatt | 2.2 kW |
Length (L.1) | 239 mm |
Mount Hole Center - Center (O.1) | 105 mm |
Mount Hole Diameter (C.1) | 10.5 mm |
Mount Hole Diameter (C.2) | 10.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
No./Teeth (Replaces) | 9 qty |
Pinion at Rest (B) | 26 mm |
Rotation | CW |
Spigot Diameter (A) | 82 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
JOHN DEERE | 244J | [4024T] | |
JOHN DEERE | 304J | [4024T] | |
JOHN DEERE | 317 | [4024T] | |
JOHN DEERE | 320 | [4024T] | |
JOHN DEERE | 325 | [5030T] | |
JOHN DEERE | 328 | [5030T] | |
JOHN DEERE | 332 | [5030T] | |
JOHN DEERE | 4120 | [4024T] | |
JOHN DEERE | 4320 | [4024T] | |
JOHN DEERE | 4520 | [4024T] | |
JOHN DEERE | 4720 | [4024T] | |
JOHN DEERE | 5225 | ||
JOHN DEERE | 5325 |
Reference Information
RM100034 F000AL0114 F000AL0115 CST10481GS S12BH0483A2 2-3005-BO STRS472 RE540304 8214287 18954N 254489 S0259 RE508922 20401184OE 000F000AL0115 000F000AL0114 11.131.556 S12BH0483 0001109330 STR78005 0001109331 R540304 STR50452 EAA-121480 254489B 1109331 0006004AA3014 1109330 113900 STR1526 SE501844 120-6114 6010481 6004AA3014Video/Publications
0001109330 0001109331 11.131.556 11.131.750 113900 120-6114 18954N 2-3005-BO 20401184OE 254489 254489B 6004AA3014 6010481 8214287 AZE6544 CST10481GS EAA-121480 F000AL0114 F000AL0115 IS1154 MS 221 RE508922 RE540304 SE501844 STR50452 STRS472Add Your Number
