Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 744.86 including GST
NZ$ 647.70 excluding GST
or four payments of $186.22
with
Learn More
UOM:
each
Alternative Item:
S0137
Product Code:
S0261
Quantity In Stock Nationally
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
0001261008Associated Numbers
0001241006 0001241015 0001241020 0001261007 0001261008 0986022260 101420 101420B 101420P 101420R 114073 1667425 1688625 1739935 1826121 1843852 1876369 45-4013 CS1420 DRT2260 DRT2260X EAA-121931 LRS02341 M90R3544SE RNL261008 STR50443 STR50515 UD14987SSpecifications
| Kilowatt | 5.50 kW |
| Length (L.1) | 322 mm |
| Mount Hole Center - Center (O.1) | 126 mm |
| Mount Hole Center - Center (O.2) | 126 mm |
| Mount Hole Center - Center (O.3) | 126 mm |
| Mount Hole Diameter (C.1) | 13.50 mm |
| Mount Hole Diameter (C.2) | 13.50 mm |
| Mount Hole Diameter (C.3) | 13.50 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 12 qty |
| No./Teeth (Replaces) | 12 qty |
| OEM Product | No |
| Pinion at Rest (B) | 48 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 110 mm |
| Unit Type | BOSCH |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| BOVA | Magiq MHD 122 | MX300 | 10.2006- |
| BOVA | Magiq MHD 131 Magnum, MHD 139 Magnum, MHD 148 Magnum | MX340 | 07.2007- |
| BOVA | Synergy SDD 130, SDD 141 | MX340 | 07.2007- |
| BOVA | Synergy SDD 130, SSD 141 | MX375 | 07.2007- |
| DAF | CF 85.360 | 01.2006- | |
| DAF | CF 85.410 | 01.2006- | |
| DAF | CF 85.460 | 01.2006- | |
| DAF | CF 85.510 | 01.2006- | |
| DAF | CF 85 FA 85.360 | MX265 | 10.2006-05.2013 |
| DAF | CF 85 FA 85.360 | MX265 | 10.2006-05.2013 |
| DAF | CF 85 FA 85.410 | MX300 | 10.2006-05.2013 |
| DAF | CF 85 FA 85.410 | MX300 | 10.2006-05.2013 |
| DAF | CF 85 FA 85.460 | MX340 | 10.2006-05.2013 |
| DAF | CF 85 FA 85.460 | MX340 | 10.2006-05.2013 |
| DAF | CF 85 FA 85.510 | MX375 | 10.2006-05.2013 |
| DAF | CF 85 FA 85.510 | MX375 | 10.2006-05.2013 |
| DAF | CF 85 FAC 85.360 | MX265 | 10.2006-05.2013 |
| DAF | CF 85 FAC 85.380 | XE280C | 12.2005-05.2013 |
| DAF | CF 85 FAC 85.410 | MX300 | 10.2005-05.2013 |
| DAF | CF 85 FAC 85.460 | MX340 | 10.2005-05.2013 |
| DAF | CF 85 FAC 85.510 | MX375 | 10.2005-05.2013 |
| DAF | CF 85 FAD 85.360 | MX265 | 10.2006-05.2013 |
| DAF | CF 85 FAD 85.360 | MX265 | 10.2006-05.2013 |
| DAF | CF 85 FAD 85.360 | MX265 | 10.2006-05.2013 |
| DAF | CF 85 FAD 85.410 | MX300 | 10.2006-05.2013 |
| DAF | CF 85 FAD 85.410 | MX300 | 10.2006-05.2013 |
| DAF | CF 85 FAD 85.410 | MX300 | 10.2006-05.2013 |
| DAF | CF 85 FAD 85.460 | MX340 | 10.2006-05.2013 |
| DAF | CF 85 FAD 85.460 | MX340 | 10.2006-05.2013 |
| DAF | CF 85 FAD 85.460 | MX340 | 10.2006-05.2013 |
| DAF | CF 85 FAD 85.510 | MX375 | 10.2006-05.2013 |
| DAF | CF 85 FAD 85.510 | MX375 | 10.2006-05.2013 |
| DAF | CF 85 FAD 85.510 | MX375 | 10.2006-05.2013 |
| DAF | CF 85 FAG 85.360, FAN 85.360 | MX265 | 10.2006-05.2013 |
| DAF | CF 85 FAG 85.360, FAN 85.360 | MX265 | 10.2006-05.2013 |
| DAF | CF 85 FAG 85.410, FAN 85.410 | MX300 | 10.2005-05.2013 |
| DAF | CF 85 FAG 85.410, FAN 85.410 | MX300 | 10.2006-05.2013 |
| DAF | CF 85 FAG 85.460, FAN 85.460 | MX340 | 10.2005-05.2013 |
| DAF | CF 85 FAG 85.460, FAN 85.460 | MX340 | 10.2006-05.2013 |
| DAF | CF 85 FAG 85.510, FAN 85.510 | MX375 | 10.2005-05.2013 |
| DAF | CF 85 FAG 85.510, FAN 85.510 | MX375 | 10.2006-05.2013 |
| DAF | CF 85 FAN 85.360 | MX265 | 10.2006-05.2013 |
| DAF | CF 85 FAN 85.410 | MX300 | 10.2006-05.2013 |
| DAF | CF 85 FAN 85.460 | MX340 | 10.2006-05.2013 |
| DAF | CF 85 FAN 85.510 | MX375 | 10.2006-05.2013 |
| DAF | CF 85 FAQ 85.360 | MX265 | 10.2006-05.2013 |
| DAF | CF 85 FAQ 85.410 | MX300 | 10.2006-05.2013 |
| DAF | CF 85 FAQ 85.460 | MX340 | 10.2006-05.2013 |
| DAF | CF 85 FAQ 85.510 | MX375 | 10.2006-05.2013 |
| DAF | CF 85 FAR 85.360 | MX265 | 10.2006-05.2013 |
| DAF | CF 85 FAR 85.360, FAS 85.360 | MX265 | 10.2006-05.2013 |
| DAF | CF 85 FAR 85.360, FAS 85.360 | MX265 | 10.2006-05.2013 |
| DAF | CF 85 FAR 85.410 | MX300 | 10.2005-05.2013 |
| DAF | CF 85 FAR 85.410, FAS 85.410 | MX300 | 10.2005-05.2013 |
| DAF | CF 85 FAR 85.410, FAS 85.410 | MX300 | 10.2005-05.2013 |
| DAF | CF 85 FAR 85.460 | MX340 | 10.2005-05.2013 |
| DAF | CF 85 FAR 85.460, FAS 85.460 | MX340 | 10.2005-05.2013 |
| DAF | CF 85 FAR 85.460, FAS 85.460 | MX340 | 10.2005-05.2013 |
| DAF | CF 85 FAR 85.510 | MX375 | 10.2005-05.2013 |
| DAF | CF 85 FAR 85.510, FAS 85.510 | MX375 | 10.2005-05.2013 |
| DAF | CF 85 FAR 85.510, FAS 85.510 | MX375 | 10.2005-05.2013 |
| DAF | CF 85 FAT 85.360 | MX265 | 10.2006-05.2013 |
| DAF | CF 85 FAT 85.360 | MX265 | 10.2006-05.2013 |
| DAF | CF 85 FAT 85.410 | MX300 | 10.2005-05.2013 |
| DAF | CF 85 FAT 85.410 | MX300 | 10.2005-05.2013 |
| DAF | CF 85 FAT 85.460 | MX340 | 10.2005-05.2013 |
| DAF | CF 85 FAT 85.460 | MX340 | 10.2005-05.2013 |
| DAF | CF 85 FAT 85.510 | MX375 | 10.2005-05.2013 |
| DAF | CF 85 FAT 85.510 | MX375 | 10.2005-05.2013 |
| DAF | CF 85 FAX 85.360 | MX265 | 10.2006-05.2013 |
| DAF | CF 85 FAX 85.410 | MX300 | 10.2005-05.2013 |
| DAF | CF 85 FAX 85.460 | MX340 | 10.2005-05.2013 |
| DAF | CF 85 FAX 85.510 | MX375 | 10.2005-05.2013 |
| DAF | CF 85 FT 85.360 | MX265 | 10.2006-05.2013 |
| DAF | CF 85 FT 85.410 | MX300 | 10.2005-05.2013 |
| DAF | CF 85 FT 85.460 | MX340 | 10.2005-05.2013 |
| DAF | CF 85 FT 85.510 | MX375 | 10.2005-05.2013 |
| DAF | CF 85 FTG 85.360 | MX265 | 10.2006-05.2013 |
| DAF | CF 85 FTG 85.410 | MX300 | 10.2005-05.2013 |
| DAF | CF 85 FTG 85.460 | MX340 | 10.2005-05.2013 |
| DAF | CF 85 FTG 85.510 | MX375 | 10.2005-05.2013 |
| DAF | CF 85 FTG 85.510 | MX375 | 10.2005-05.2013 |
| DAF | CF 85 FTR 85.360, FTS 85.360, FTP 85.360 | MX265 | 10.2006-12.2020 |
| DAF | CF 85 FTR 85.410, FTS 85.410, FTP 85.410 | MX300 | 10.2005-05.2013 |
| DAF | CF 85 FTR 85.460, FTS 85.460, FTP 85.460 | MX340 | 10.2005-05.2013 |
| DAF | CF 85 FTR 85.510, FTS 85.510, FTP 85.510 | MX375 | 10.2005-05.2013 |
| DAF | CF 85 FTT 85.360 | MX265 | 10.2006-05.2013 |
| DAF | CF 85 FTT 85.410 | MX300 | 10.2005-05.2013 |
| DAF | CF 85 FTT 85.460 | MX340 | 10.2005-05.2013 |
| DAF | CF 85 FTT 85.510 | MX375 | 10.2005-05.2013 |
| DAF | XF 105.410 12.9 | [MX300S] | 01.2006- |
| DAF | XF 105.460 12.9 | [MX340S] | 01.2006- |
| DAF | XF 105.510 12.9 | [MX375S] | 01.2006- |
| DAF | XF 105 FA 105.410 | MX300 | 10.2005- |
| DAF | XF 105 FA 105.460 | MX340 | 10.2005- |
| DAF | XF 105 FA 105.510 | MX375 | 10.2005- |
| DAF | XF 105 FAD 105.410 | MX300 | 10.2005- |
| DAF | XF 105 FAD 105.460 | MX340 | 10.2005- |
| DAF | XF 105 FAD 105.510 | MX375 | 10.2005- |
| DAF | XF 105 FAK 105.410 | MX300 | 10.2005- |
| DAF | XF 105 FAK 105.460 | MX340 | 10.2005- |
| DAF | XF 105 FAK 105.510 | MX375 | 10.2005- |
| DAF | XF 105 FAN 105.410 | MX300 | 10.2005- |
| DAF | XF 105 FAN 105.460 | MX340 | 10.2005- |
| DAF | XF 105 FAN 105.510 | MX375 | 10.2005- |
| DAF | XF 105 FAR 105.410 | MX300 | 10.2005- |
| DAF | XF 105 FAR 105.460 | MX340 | 10.2005- |
| DAF | XF 105 FAR 105.510 | MX375 | 10.2005- |
| DAF | XF 105 FAS 105.410, FAR 105.410 | MX300 | 10.2005- |
| DAF | XF 105 FAS 105.460, FAR 105.460 | MX340 | 10.2005- |
| DAF | XF 105 FAS 105.510, FAR 105.510 | MX375 | 10.2005- |
| DAF | XF 105 FAT 105.410 | MX300 | 10.2005- |
| DAF | XF 105 FAT 105.460 | MX340 | 10.2005- |
| DAF | XF 105 FAT 105.510 | MX375 | 10.2005- |
| DAF | XF 105 FT 105.410 | MX300 | 10.2005- |
| DAF | XF 105 FT 105.460 | MX340 | 10.2005- |
| DAF | XF 105 FT 105.510 | MX375 | 10.2005- |
| DAF | XF 105 FTG 105.410 | MX300 | 10.2005- |
| DAF | XF 105 FTG 105.410 | MX300 | 10.2005- |
| DAF | XF 105 FTG 105.460 | MX340 | 10.2005- |
| DAF | XF 105 FTG 105.460 | MX340 | 10.2005- |
| DAF | XF 105 FTG 105.510 | MX375 | 10.2005- |
| DAF | XF 105 FTG 105.510 | MX375 | 10.2005- |
| DAF | XF 105 FTM 105.410 | MX300 | 10.2005- |
| DAF | XF 105 FTM 105.460 | MX340 | 10.2005- |
| DAF | XF 105 FTM 105.510 | MX375 | 10.2005- |
| DAF | XF 105 FTP 105.410 | MX300 | 10.2005- |
| DAF | XF 105 FTP 105.460 | MX340 | 10.2005- |
| DAF | XF 105 FTP 105.510 | MX375 | 09.2013- |
| DAF | XF 105 FTS 105.410, FTR 105.410 | MX300 | 10.2005- |
| DAF | XF 105 FTS 105.460, FTR 105.460 | MX340 | 10.2005- |
| DAF | XF 105 FTS 105.510, FTR 105.510 | MX375 | 10.2005- |
| DAF | XF 105 FTT 105.410 | MX300 | 10.2005- |
| DAF | XF 105 FTT 105.460 | MX340 | 10.2005- |
| DAF | XF 105 FTT 105.510 | MX375 | 10.2005- |
| DAF | XF 95.530 12.6 | 01.2002- | |
| DAF | XF 95 FA 95.530 | XE390C | 09.2002-12.2006 |
| DAF | XF 95 FAD 95.530 | XE390C | 09.2002-03.2006 |
| DAF | XF 95 FAK 95.530 | XE390C | 09.2002-03.2006 |
| DAF | XF 95 FAN 95.530 | XE390C | 09.2002-03.2006 |
| DAF | XF 95 FAR 95.530 | XE390C | 09.2002-12.2006 |
| DAF | XF 95 FAS 95.530 | XE390C | 09.2002-03.2006 |
| DAF | XF 95 FAT 95.530 | XE390C | 09.2002-03.2006 |
| DAF | XF 95 FT 95.530 | XE390C | 09.2002-12.2006 |
| DAF | XF 95 FTG 95.430 | XE315C | 12.2005-12.2006 |
| DAF | XF 95 FTG 95.530 | XE390C | 09.2002-12.2006 |
| DAF | XF 95 FTM 95.380 | XE280C | 12.2005-12.2006 |
| DAF | XF 95 FTM 95.530 | XE390C | 09.2002-12.2006 |
| DAF | XF 95 FTP 95.530 | XE390C | 09.2002-03.2006 |
| DAF | XF 95 FTR 95.530 | XE390C | 09.2002-03.2006 |
| DAF | XF 95 FTS 95.530 | XE390C | 09.2002-03.2006 |
| DAF | XF 95 FTT 95.530 | XE390C | 09.2002-03.2006 |
| MINELLI | TF 1800 | 18K4F | 01.1998-08.2011 |
| SOLARIS | VACANZA Vacanza 12 | MX300 | 10.2005- |
| SOLARIS | VACANZA Vacanza 13 | MX300 | 10.2005- |
| TEMSA | SAFARI SAFARI 12 HD, SAFARI 13 HD | MX300 | 10.2010- |
| TEMSA | SAFIR PLUS SAFIR PLUS, SAFIR PLUS VIP | MX300 | 10.2009- |
| TEMSA | SAFIR SAFIR, SAFIR VIP | MX300 | 10.2009- |
Reference Information
| 0001241006 | BOSCH |
| 0001241015 | BOSCH |
| 0001241020 | BOSCH |
| 0001261007 | BOSCH |
| 0001261008 | BOSCH |
| 0986022260 | BOSCH |
| 101420 | KUHNER |
| 101420B | KUHNER |
| 101420P | KUHNER |
| 101420R | KUHNER |
| 114073 | CARGO |
| 1667425 | DAF |
| 1688625 | DAF |
| 1739935 | DAF |
| 1826121 | DAF |
| 1843852 | DAF |
| 1876369 | DAF |
| 1956090 | DAF |
| 1956090 | OTOMARSAN |
| 2015153 | DAF |
| 2015153 | OTOMARSAN |
| 2134698 | DAF |
| 220821 | ERA |
| 45-4013 | ELSTOCK |
| 5110076 | MEAT & DORIA |
| AM-2015 | AUTO MAGNETO |
| CGB-22260 | AINDE |
| CS1420 | HC PARTS |
| DRT2260 | DELCO |
| DRT2260X | DELCO |
| F032114073 | CARGO |
| LRS02341 | LUCAS |
| LRS2341 | LUCAS |
| M90R3544SE | PRESTOLITE |
| MAV127140 | SIOM |
| RNL261008 | RNL |
| S0261 | AS-PL |
| S24BH0116 | SIDAT |
| S24BH0116A2 | SIDAT |
| STD1418R | DAF |
| STR1436 | ELECTROLOG |
| STR50443 | WOODAUTO |
| STR50515 | WOODAUTO |
| STRL730 | 3EFFE |
| UD14987S | AS-PL |
| UD19707S | AS-PL |
Video/Publications
