Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 429.70 including GST
NZ$ 373.65 excluding GST
or four payments of $107.43
with
Learn More
each
S0262
No stock in NZ - Call us for possible procurement options
No stock in NZ - Call us for possible procurement options
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
0001362305Associated Numbers
0001359012 0001359027 0001359049 0001359073 0001359078 0001362016 0001362034 0001362305 0001362313 0001367004 0001367010 0001367052 01161384 01163669 01164994 01173240 10103 101130 101130B 101130M 10114 10605 11.130.117 110536 1113286 116139 14100 19024235 19024252 20500762 25-0037 25-0155 6000102270 6000102394 6005003155 6005003156 6005016395 81382305 861093 9142802 9142803 9142805 943216818 943217407 943252204 AES7162 AZJ0402 AZJ3128 AZJ3170 AZJ3508 CS103 CS114 DRS1140 EAA-121207 LRS00762 LRS01978 M100R2014SE MT74G R11K RNL1114 STR50591Specifications
| Kilowatt | 2.70 kW |
| Length (L.1) | 294 mm |
| Mount Hole Center - Center (O.1) | 127 mm |
| Mount Hole Center - Center (O.2) | 90 mm |
| Mount Hole Center - Center (O.3) | 90 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| Mount Hole Diameter (C.3) | 11 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| No./Teeth (Replaces) | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 29 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| ATLAS COPCO | ST 35 2.8 | [F3L912] | 01.1982-12.1986 |
| ATLAS COPCO | ST 48 3.8 | [F4L912] | 01.1982-12.1986 |
| ATLAS COPCO | STS 35 2.8 | [F3L912] | 01.1982-12.1986 |
| ATLAS COPCO | STS 48 3.8 | [F4L912] | 01.1982-12.1986 |
| CLAAS | Mercator 75 | [F6L912] | 01.1982- |
| DEUTZ-FAHR | D 10006 | [F6L912] | 01.1970-12.1978 |
| DEUTZ-FAHR | D 13006 | [BF6L912] | 01.1972-12.1978 |
| DEUTZ-FAHR | D 6006 | 01.1972-12.1982 | |
| DEUTZ-FAHR | D 6206 | [F4L912] | 01.1978- |
| DEUTZ-FAHR | D 6807 | [F4L912] | 01.1986-12.1991 |
| DEUTZ-FAHR | D 7006 | 01.1972-12.1974 | |
| DEUTZ-FAHR | D 7007 | [F4L912] | 01.1986-12.1991 |
| DEUTZ-FAHR | D 7206 | [F4L912] | 01.1978- |
| DEUTZ-FAHR | D 7207 | [F4L912.51] | 01.1980-12.1981 |
| DEUTZ-FAHR | D 7807 | [F4L913] | 01.1980-12.1984 |
| DEUTZ-FAHR | D 7807 | [F4L913.55] | 01.1980-12.1984 |
| DEUTZ-FAHR | DX 110 | [F6L912] | 01.1982-12.1985 |
| DEUTZ-FAHR | DX 120 | [F6L913] | 01.1980-12.1985 |
| DEUTZ-FAHR | DX 3.10 | [F3L912] | 01.1986-12.1991 |
| DEUTZ-FAHR | DX 3.30 | [F3L912] | 01.1986-12.1991 |
| DEUTZ-FAHR | DX 3.50 | [F3L913] | 01.1986-12.1991 |
| DEUTZ-FAHR | DX 3.60 | [F4L912] | 01.1986-12.1991 |
| DEUTZ-FAHR | DX 3.70 | [F4L912] | 01.1986-12.1991 |
| DEUTZ-FAHR | DX 3.80 | [F4L913] | 01.1986-12.1991 |
| DEUTZ-FAHR | DX 3.90 | [F4L913] | 01.1986-12.1991 |
| DEUTZ-FAHR | DX 4.10 | [F4L912] | 01.1986-12.1991 |
| DEUTZ-FAHR | DX 4.30 | [F4L913] | 01.1986-12.1991 |
| DEUTZ-FAHR | DX 4.31 | [F4L913] | 01.1991- |
| DEUTZ-FAHR | DX 4.50 | [BF4L913T] | 01.1986-12.1991 |
| DEUTZ-FAHR | DX 4.51 | [BF4L913T] | 01.1990-12.1991 |
| DEUTZ-FAHR | DX 4.70 | [BF4L913] | 01.1986-12.1991 |
| DEUTZ-FAHR | DX 6.10 | [F6L912] | 01.1986-12.1991 |
| DEUTZ-FAHR | DX 6.30 | [F6L913] | 01.1986-12.1991 |
| DEUTZ-FAHR | DX 6.31 | [BF6L913T] | 01.1986-12.1991 |
| DEUTZ-FAHR | DX 6.50 | [BF6L913] | 01.1986-12.1991 |
| DEUTZ-FAHR | DX 6.60 | [BF6L913] | 01.1986-12.1991 |
| DEUTZ-FAHR | DX 7.10 | [BF6L913] | 01.1986-12.1991 |
| DEUTZ-FAHR | DX 80 | [F4L913] | 01.1982-12.1985 |
| DEUTZ-FAHR | DX 85 | [F5L912] | 01.1982-12.1985 |
| DEUTZ-FAHR | DX 86 | [BF4L913T] | 01.1982-12.1985 |
| DEUTZ-FAHR | DX 90 | [F5L912] | 01.1982-12.1985 |
| DEUTZ-FAHR | DX 92 | [BF4L913] | 01.1982-12.1985 |
| DEUTZ-FAHR | DX 92 | [BF4L913T] | 01.1982-12.1985 |
| DEUTZ-FAHR | Intrac 2004 | [F4L912] | 01.1982-12.1984 |
| DEUTZ-FAHR | Intrac 6.30 | [F6L913] | 01.1988- |
| DEUTZ-FAHR | Intrac 6.30 Turbo | [BF6L913T] | 01.1989-12.1991 |
| DEUTZ-FAHR | M 1080 4.7 Diesel | [F5L912] | 01.1981-12.1991 |
| DEUTZ-FAHR | M 1202 5.7 Diesel | [F6L912] | 01.1980-12.1991 |
| DEUTZ-FAHR | M 2385 5.7 Diesel | [F6L912] | 01.1982-12.1991 |
| DEUTZ-FAHR | M 3660 3.8 | [F4L912] | 01.1987-12.1991 |
| DEUTZ-FAHR | M 980 3.8 Diesel | [F4L912] | 01.1982-12.1991 |
| FAHR | 1320 | [F6L913] | 01.1983-12.1987 |
| FAHR | 2480 | [F6L912] | 01.1982-12.1987 |
| FAHR | 2580 | [F6L913] | 01.1982-12.1987 |
| FAHR | 2680 | [F6L913] | 01.1982-12.1987 |
| FAHR | M770 | [F4L.912] | 01.1980-12.1987 |
| FAHR | M980 | [F4L912] | 01.1982-12.1987 |
| FENDT | F 275GT | [F4L912] | 01.1986-12.1991 |
| FENDT | Farmer 204P | [F4L912] | 01.1986-12.1991 |
| IVECO | 110-13 | [BF6L913T] | 01.1983-12.1986 |
| IVECO | 75-9A | [F4L913] | 01.1985-12.1986 |
| IVECO | 80-13A | [BF6L913T] | 01.1983-12.1985 |
| IVECO | 80-9A | [F4L913] | 01.1983-12.1986 |
| IVECO | 90-13A | [BF6L913T] | 01.1983-12.1985 |
| IVECO | 90-9A | [F4L913] | 01.1985-12.1986 |
| KHD | Engine | [F3L912] | 01.1986-12.1991 |
| KHD | Engine | [F3L912F] | 01.1989-12.1992 |
| KHD | Engine | [F4L912] | 01.1986-12.1991 |
| KHD | Engine | [F6L612F] | 01.1989-12.1991 |
| KHD | Engine | [F6L912] | 01.1989-12.1991 |
| LINDE | H20 | [F3L913G] | 01.1984-12.1991 |
| LINDE | H25 | [F3L913G] | 01.1984-12.1991 |
| LINDE | H30 | [F3L913G] | 01.1984-12.1991 |
| LINDE | H35 | [F4L912] | 01.1981-12.1991 |
| LINDE | H40 | [F4L912] | 01.1981-12.1991 |
| LINDE | H70 | [F6L912] | 01.1981-12.1991 |
| SCHAEFF | SKL700 | [F3L912] | 01.1982-12.1986 |
Reference Information
| 0001358046 | BOSCH |
| 0001359003 | BOSCH |
| 0001362305 | BOSCH |
| 0001362313 | BOSCH |
| 0001367004 | BOSCH |
| 01161384 | KHD |
| 01163669 | KHD |
| 01164995 | KHD |
| 01174166 | KHD |
| 01178026 | DEUTZ |
| 017769 | STEINBOCK |
| 05710901 | BOMAG |
| 05710905 | BOMAG |
| 05710923 | BOMAG |
| 05710927 | BOMAG |
| 0986011140 | BOSCH |
| 10114 | KUHNER |
| 10114B | KUHNER |
| 10114K | KUHNER |
| 10114M | KUHNER |
| 11.130.551 | ISKRA / LETRIKA |
| 1161384 | DEUTZ |
| 116312 | CARGO |
| 1163994 | KHD |
| 1164995 | KHD |
| 1170051 | KHD |
| 1170052 | KHD |
| 1174166 | KHD |
| 1174166 | IVECO |
| 1178026 | DEUTZ |
| 1178686 | KHD |
| 120-30108 | ROBERT'S |
| 1516667R | DAF |
| 17075N | WAI / TRANSPO |
| 19024252 | DELCO |
| 20401321BN | REAL |
| 20401321EL | REAL |
| 20401321OE | REAL |
| 220011 | ERA |
| 220227 | ERA |
| 25-0155 | ELSTOCK |
| 260-62104 | DIXIE |
| 33334 | EAI |
| 42522733 | IVECO |
| 42522733 | FIAT |
| 560.001.093.010 | PSH |
| 6005030686 | CLARK |
| 6010123.0 | SANDO |
| 6010123.1 | SANDO |
| 6010123.3 | SANDO |
| 605720100084 | MWM |
| 6104024 | LIEBHERR |
| 70756112 | ZETTELMEYER |
| 72735905 | MAHLE |
| 8650 | CEVAM |
| 88212956 | POWERMAX |
| 8EA011610-941 | HELLA |
| 8EA725967-001 | HELLA |
| 91-15-6896 | WILSON |
| 91-15-6896N | WILSON |
| AES7162 | AUTOELECTRO |
| AZJ3169 | ISKRA / LETRIKA |
| B5R12X4H7622 | KHD |
| CGB-21143 | AINDE |
| CS114 | HC PARTS |
| CST10123AS | CASCO |
| CST10123ES | CASCO |
| CST10123GS | CASCO |
| DRS1143 | DELCO |
| DS2253 | DELCO |
| F032116312 | CARGO |
| G380900060010 | FENDT |
| IS0551 | ISKRA / LETRIKA |
| LRS00762 | LUCAS |
| LRS762 | LUCAS |
| MAV3320 | SIOM |
| MS277 | MAHLE |
| MT74G | MAGNETI MARELLI |
| PRSL095 | 3EFFE |
| S0262 | AS-PL |
| S12BH0277A2 | SIDAT |
| S12BH0362A2 | SIDAT |
| SG0050 | GHIBAUDI |
| STB0114 | KRAUF |
| STM706 | ROLLCO |
| STR1020 | ELECTROLOG |
| STR50590 | WOODAUTO |
| STR7992 | ELECTROLOG |
| STRL095 | 3EFFE |
| TS-6022 | DIXIE |
| V941501 | CASE |
| V941501EX | CASE |
| X830100007 | FENDT |
Video/Publications
