Associated Numbers
0001108099 0986014950 0986014951 10322 10322R 10332 10332R 11.130.505 11.130.593 110351 11250 1202045 20410001BN 20410001OE 20500657 2103-12VIP54 2108-3708010 2108-3708010-6 22.0332 22.0332M 25-1046 293708 30714N 3555 4243708 4263708 455678 455696 5712.3708 6049100 8014950 8212665 8EA726080-001 943251862 AES7114 AZE2512 AZF3555 B001111273 CS332 CST49100AS CST49100GS DRS3027 EAA-121691 IS0505 IS0593 KAT3K29.3708 LRS00714 S0263 SS310 STR-2023 STR2023 STR50423Specifications
Kilowatt | 1.3 kW |
Length (L.1) | 242 mm |
Mount Hole Center - Center (O.1) | 96 mm |
Mount Hole Center - Center (O.2) | 91 mm |
Mount Hole Center - Center (O.3) | 124 mm |
Mount Hole Diameter (C.1) | 8.5 mm |
Mount Hole Diameter (C.2) | 8.5 mm |
Mount Hole Diameter (C.3) | 8.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
No./Teeth (Replaces) | 11 qty |
Pinion at Rest (B) | 32 mm |
Rotation | ACW |
Spigot Diameter (A) | 82 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
LADA | 110 1.5 | [VAZ-2111] | 01.1996-12.2000 |
LADA | Nova 1.7 1700 | [ECE] | 08.1994-12.2000 |
LADA | Samara 1.1 1100 | [BA321081] | 02.1988-12.1994 |
LADA | Samara 1.1 1100 | [BA321081] | 02.1996- |
LADA | Samara 1.1 1100 Forma | [BA321081] | 07.1991-12.2000 |
LADA | Samara 1.3 1300 | [BA32108] | 01.1986-07.1997 |
LADA | Samara 1.3 1300 | [BA32108] | 01.1986-12.1994 |
LADA | Samara 1.3 1300 | [BA321115] | 01.1986- |
LADA | Samara 1.3 1300 | [BA321115] | 02.1996- |
LADA | Samara 1.3 1300 Forma | [BA32108] | 05.1989-07.1997 |
LADA | Samara 1.5 | [VAZ-2111] | 01.2000- |
LADA | Samara 1.5 1500 | [BA321083] | 01.1988- |
LADA | Samara 1.5 1500 | [BA32111] | 09.1991- |
LADA | Samara 1.5 1500 Forma | [BA321083] | 07.1991- |
LADA | Samara 1.5 1500 Forma | [BA32111] | 11.1994- |
LADA | Samara 1.5 Forma | [VAZ-2111] | 01.2000- |
Reference Information
EAA-121691 10332R CST49100AS 90008257 STR2023 90540586 20410001OE 113 30714N 29370801 2108370606 1.3L2103 93175881 R1040028 2103-12VIP54 571237008 STR-2023 1 IS0593 3L2103 B001111273 210312VVIP54 AZE2512 2108-3708010-06 1108099 29 000B001111273 20500657 000986014950 000986014951 STRS951 5712 2108-3708010 293708-12B STR1806 R1540000 264 8EA726080-001 AES7114 943251862 22.0332 ANM15247X 8212665 90443488 8014950 SS310 330484 1202016 22.0332M KAT3K29.3708 3555 20410001BN 110351 10332 2108-3708010-6 2109 6049100 MS 2108-37060-6 6202046 330475 9.4428E+11 13L2103 2.10837E+12 1202143 CS332 LRS714 5712.3708 MAV501100 S0263 293708 455696 4263708 10322R 0001108099 CST49100GS IS0505 2643708 1202156 11.130.593 25-1046 AZF3555 LRS00714 DRS3027 29370812B 986014950 29.3708-01 986014951 21093708 90511841 90519332 MAV6710 11250 4243708 MAV511000 2109-3708 2.10937E+12 2109.3708010-01 1202045 STR50423 220052 455678 11.130.505 10322Video/Publications
0001108099 0986014950 0986014951 10322 10322R 10332 10332R 11.130.505 11.130.593 110351 11250 1202045 20410001BN 20410001OE 20500657 2103-12VIP54 2108-3708010 2108-3708010-6 22.0332 22.0332M 25-1046 293708 30714N 3555 4243708 4263708 455678 455696 5712.3708 6049100 8014950 8212665 8EA726080-001 943251862 AES7114 AZE2512 AZF3555 B001111273 CS332 CST49100AS CST49100GS DRS3027 EAA-121691 IS0505 IS0593 KAT3K29.3708 LRS00714 LRS714 MAV501100 MAV511000 MAV6710 MS 113 S0263 SS310 STR-2023 STR2023 STR50423 STRS951 220052Add Your Number
