Associated Numbers
0001510002 01510002 20401257BN 6010752 861099 920-1402 B001510274 CST10752AS STR50501 254493 254493PSpecifications
Kilowatt | 9 kW |
Length (L.1) | 459 mm |
Mount Hole Center - Center (O.1) | 127 mm |
Mount Hole Center - Center (O.2) | 127 mm |
Mount Hole Center - Center (O.3) | 127 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
Mount Hole Diameter (C.3) | 11 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 46 mm |
Rotation | CW |
Spigot Diameter (A) | 92 mm |
Unit Type | BOSCH |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
DEUTZ | Engine | [F6L613] |
Reference Information
BOM 0001510274 861099 891.201.113 0001510002 UNIT 1510002 STR1882 20401257BN CST10752AS 1510274 000B0001510274 254493 STB5102 B0001510274 254493P 920-1402 STR50501 35530035A UD16939S 6010752 035530035A STRL205Video/Publications
0001510002 0001510274 035530035A 20401257BN 254493 254493P 6010752.0 861099 891.201.113 B0001510274 CST10752AS STB5102 STR50501 STRL205 UD16939S UNIT BOM 920-1402Add Your Number
