Associated Numbers
0001410062 0001415011 0001416003 0986011580 0986011583 10565 10650 110533 17168N 19024011 20401407EL 22603 28.0565 28.3008 33376 5000804191 51.26201-7042 6010704 860654 8685 8811580 8EA726190-001 AES8165 CS565 CST10704ES DRS1580 IM323 IM503 LRS00865 R23.09 STR22042Specifications
Kilowatt | 5.4 kW |
Length (L.1) | 386 mm |
Mount Hole Center - Center (O.1) | 91 mm |
Mount Hole Center - Center (O.2) | 91 mm |
Mount Hole Center - Center (O.3) | 128 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
Mount Hole Diameter (C.3) | 11 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
No./Teeth (Replaces) | 11 qty |
Oil Sealed | Yes |
Pinion at Rest (B) | 47 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | BOSCH |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
STEYR | 1491.280 9.7 | [WD615.65] | |
STEYR | 1491.280 9.7 | [WD615.67] | |
STEYR | 1491.280 9.7 | [WD615.69] | |
STEYR | 1491.280 9.7 | [WD615.75] | |
STEYR | 1491.280 9.7 | [WD615.77] | |
STEYR | 19 S 24 9.7 | [WD 615..] | 01.1988- |
STEYR | 19 S 24 9.7 | [WD615..] | 01.1988- |
STEYR | 19 S 28 9.7 | [WD 615..] | 01.1988- |
STEYR | 19 S 28 9.7 | [WD615..] | 01.1988- |
STEYR | 19 S 31 9.7 | [WD 615..] | 10.1987- |
STEYR | 19 S 31 9.7 | [WD615..] | 10.1987- |
STEYR | 22 S 28 9.7 | [WD 615..] | 01.1988- |
STEYR | 22 S 28 9.7 | [WD615..] | 01.1988- |
STEYR | 22 S 31 9.7 | [WD 615..] | 10.1987- |
STEYR | 22 S 31 9.7 | [WD615..] | 10.1987- |
STEYR | 26 S 28 9.7 | [WD 615..] | 01.1988- |
STEYR | 26 S 28 9.7 | [WD615..] | 01.1988- |
STEYR | 26 S 31 9.7 | [WD 615..] | 10.1987- |
STEYR | 26 S 31 9.7 | [WD615..] | 10.1987- |
STEYR | 32 S 28 9.7 | [WD 615..] | 01.1988- |
STEYR | 32 S 28 9.7 | [WD615..] | 01.1988- |
STEYR | 32 S 31 9.7 | [WD 615..] | 10.1987- |
STEYR | 32 S 31 9.7 | [WD615..] | 10.1987- |
STEYR | 33 S 31 9.7 | [WD 615..] | 10.1987- |
STEYR | 33 S 31 9.7 | [WD615..] | 10.1987- |
STEYR | 40 S 31 9.7 | [WD 615..] | 01.1988- |
STEYR | 40 S 31 9.7 | [WD615..] | 01.1988- |
Reference Information
R23.09 28.0565 4600831111 4630831110 51.26201-7042 LRS865 0001416003 000986011583 CS565 1516775R 0001410062 000986011580 33376 986011580 986011583 17168N 10650 DRS1580 1326431 S0279 22603 110533 CST10704ES STR22042 1416003 IM323 1410062 860654 STRL735 6010704 678627 7701003914 5000804191 0001415011 61500090029 19024011 51262019042 61560090001 51.26201-9042 8685 STR1643 28.3008 8EA726190-001 20401407EL 1415011 5710918 8811580 AES8165 61500090012 10565 IM503 LRS00865Video/Publications
0001410062 0001415011 0001416003 0986011580 0986011583 10565 10650 110533 17168N 19024011 20401407EL 22603 28.0565 28.3008 33376 5000804191 51.26201-7042 6010704 860654 8685 8811580 8EA726190-001 AES8165 CS565 CST10704ES DRS1580 IM323 IM503 LRS00865 LRS865 R23.09 STR22042 STRL735Add Your Number
