Associated Numbers
0001230003 0001230005 11.131.374 120-20132 18359N 20401922BN 20401922OE 220820 25-4139 254242 254242I 260-23105 6010229 630.511.112 91-15-7088 AL110598 AZF4240 AZF4596 BOS0001230003 CST10229AS CST10229GS DRS0152 DS1262 EAA-121552 LRS02467 LRS2467 M100R2017SE RE500819 RE506589 RE519975 RE71505 S0298 SE501854 STR50454 TS-6174Specifications
Kilowatt | 3 kW |
Length (L.1) | 315 mm |
Mount Hole Center - Center (O.1) | 105 mm |
Mount Hole Diameter (C.1) | 10.5 mm |
Mount Hole Diameter (C.2) | 10.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
No./Teeth (Replaces) | 11 qty |
Pinion at Rest (B) | 35 mm |
Rotation | CW |
Spigot Diameter (A) | 82 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
JOHN DEERE | 5070M 4.5 | [4045/T] | 01.2009-12.2013 |
JOHN DEERE | 5080M 4.5 | [4045/T] | 01.2009-12.2013 |
JOHN DEERE | 5090M 4.5 | [4045/T] | 01.2009-12.2013 |
JOHN DEERE | 5100M 4.5 | [4045/T] | 01.2009-12.2013 |
JOHN DEERE | 5510 4.5 | [4045HF..] | 01.1997-12.2006 |
JOHN DEERE | 5520 4.5 | [4045HF] | 01.1997-12.2006 |
JOHN DEERE | 5620 4.5 | [4045/T] | 01.2003-12.2009 |
JOHN DEERE | 5720 4.5 | [4045HF..] | 01.2005-12.2006 |
JOHN DEERE | 5720 4.5 | [4045/T] | 01.2003-12.2009 |
JOHN DEERE | 5820 4.5 | [4045/T] | 01.2003-12.2009 |
JOHN DEERE | 6020 4.5 | [4045HF..] | 01.1997-12.2006 |
JOHN DEERE | 6120 4.5 | [4045HF..] | 01.2001-12.2006 |
JOHN DEERE | 6215 4.5 | [4045HF..] | 01.2001-12.2006 |
JOHN DEERE | 6220 4.5 | [4045HF..] | 01.2001-12.2006 |
JOHN DEERE | 6320 4.5 | [4045HF..] | 01.2001-12.2006 |
JOHN DEERE | 6420 4.5 | [4045HF..] | 01.2001-12.2006 |
Reference Information
6010229 20401922BN AL110598 STR1410 STR1671 SE501854 8EA015642-391 MAV123600 STR79280 ANM12372 630.511.112.010 RE506589 20401922OE CST10229AS RE71505 25-4139 CST10360GS 120-20118 20401063OE S0298 STR50454 0001230005 DRS0152 0001230003 CST10229GS LRS2467 RE519975 RE500819 254242 CGB-54139 RE501689 220820 LRS02467 BOS0001230003 220820A 91-15-7088 18359N 630.511.112.018 R500819 6010229.1 CGB-21187 1230003 6010360.1 1230005Video/Publications
11.131.883 116379 120-20132 20401063OE 220820 25-4139 254242 254242I 260-23105 6010360.1 630.511.112.010 630.511.112.311 72736047 8687R 91-15-7088 AZF4240 BOS0001230003 CGB-21187 CST10360GS DRS0152 DS1262 EAA-121552 IS1300 LRS02467 LRS2467 MAV123600 MS419 PRSL258 PRSL258B RE506589 RE71505 S0298 STB3478 STR50454 STRL258 STRL258X TS-6174Add Your Number
