Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 723.09 including GST
NZ$ 628.77 excluding GST
or four payments of $180.77
with
Learn More
each
S0328
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
0001416013Associated Numbers
0001402043 0001402059 0001410029 0001410030 0001414017 0001415010 0001416013 0001416213 10.130.121 10955 10955P 11.130.005 11.139.034 110601 111248 1178720 18032N 19024578 20401426BN 20401426EL 20401426OE 254021D 254021K 254021L 254021M 256019 28.3054 45-0331 6010624 6130000 615000090030 860657GB 8916 9124340 9125290 AZK5113 AZK5117 AZK5193 CST10624AS CST10624ES CST10624GS LRS01820 R23.13 STR50138 UNIT BOM 120-6175BSpecifications
| Kilowatt | 5.40 kW |
| Length (L.1) | 386 mm |
| Mount Hole Center - Center (O.1) | 90 mm |
| Mount Hole Center - Center (O.2) | 127 mm |
| Mount Hole Center - Center (O.3) | 90 mm |
| Mount Hole Diameter (C.1) | 11.50 mm |
| Mount Hole Diameter (C.2) | 11.50 mm |
| Mount Hole Diameter (C.3) | 11.50 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| No./Teeth (Replaces) | 9 qty |
| OEM Product | No |
| Oil Sealed | Yes |
| Pinion at Rest (B) | 47 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Unit Type | BOSCH |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| STEYR | 1291.260 9.7 | [WD615..] | 05.1978- |
| STEYR | 1291.260 9.7 | [WD615.60] | |
| STEYR | 1291.260 9.7 | [WD615.61] | |
| STEYR | 1291.260 9.7 | [WD615.70] | |
| STEYR | 1291.260 9.7 | [WD615.71] | |
| STEYR | 1491.260 9.7 | [WD615..] | 05.1978- |
| STEYR | 1491.260 9.7 | [WD615.61] | |
| STEYR | 1491.260 9.7 | [WD615.70] | |
| STEYR | 1491.260 9.7 | [WD615.71] | |
| STEYR | 8300 9.7 | [WD615..] | 02.1982- |
| STEYR | 990.180 8.1 | [WD614.01] | 01.1968-12.1978 |
| STEYR | 990.180 8.1 | [WD614.01] | 01.1969-12.1978 |
| STEYR | 990.180 8.1 | [WD614.20] | 01.1968-12.1978 |
| STEYR | 990.180 8.1 | [WD614.20] | 01.1969-12.1978 |
| STEYR | 991.200 9.7 | [WD615..] | 05.1978- |
| STEYR | 991.200 9.7 | [WD615.00] | |
| STEYR | 991.200 9.7 | [WD615.20] |
Reference Information
| 0001402011 | BOSCH |
| 0001402056 | BOSCH |
| 0001414017 | BOSCH |
| 0001414018 | BOSCH |
| 0001416013 | BOSCH |
| 0001416017 | BOSCH |
| 0001416027 | BOSCH |
| 0001416213 | BOSCH |
| 05710926 | BOMAG |
| 10010839AV | ITAB AUTOMOTIVE |
| 103806 | FARCOM |
| 10440223 | ALANKO |
| 10440468 | ALANKO |
| 10955 | KUHNER |
| 10955P | KUHNER |
| 110601 | CARGO |
| 11090165 | EUROTEC |
| 11.139.538 | ISKRA / LETRIKA |
| 1178720 | KHD |
| 161500090030 | CASE |
| 20401938BN | REAL |
| 220253 | ERA |
| 22609 | ERA |
| 2-7101-1W | WAI / TRANSPO |
| 33449 | EAI |
| 449ST33 | STARTCAR |
| 45-0331 | ELSTOCK |
| 4.65040 | DT SPARE PARTS |
| 51262017014 | MAN |
| 6010839.0 | SANDO |
| 60520796 | CASE |
| 61500090030 | STEYR |
| 688018094 | DRI |
| 72492698 | MAHLE |
| 781.201.093.010 | PSH |
| 781.201.093.016 | PSH |
| 82224044 | FIAT |
| 860657GB | PRESTOLITE |
| 8802 | CEVAM |
| 90801105110 | MAN |
| A72200 | ATL AUTOTECHNIK |
| AC-CBS5015 | ACAUTO |
| AZK5579 | ISKRA / LETRIKA |
| CST10839AS | CASCO |
| F032110601 | CARGO |
| IS9051 | ISKRA / LETRIKA |
| LRS01820 | LUCAS |
| LRS1820 | LUCAS |
| MS536 | MAHLE |
| PL9112 | SNRA |
| S0328 | AS-PL |
| S-50138 | DTS |
| S511172 | BTS TURBO |
| SBO839A | AUTOTEAM |
| SG0506 | GHIBAUDI |
| ST02467 | TMI |
| STB2249 | KRAUF |
Video/Publications
