Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 743.52 including GST
NZ$ 646.54 excluding GST
or four payments of $185.88
with
Learn More
each
S0348
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
0001416045Associated Numbers
0001416045 19024152 20401927EL 367022 6010729 622621 9125440 CST10729ES DRS4550 IS9024 UNIT BOM 120-6069B UD16623SSpecifications
| Insulated Earth | Yes |
| Kilowatt | 5.40 kW |
| Length (L.1) | 387 mm |
| Mount Hole Center - Center (O.1) | 90 mm |
| Mount Hole Center - Center (O.2) | 90 mm |
| Mount Hole Center - Center (O.3) | 126 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| Mount Hole Diameter (C.3) | 11 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 11 qty |
| OEM Product | No |
| Oil Sealed | Yes |
| Pinion at Rest (B) | 46 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Unit Type | BOSCH |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| DAF | 1200DD 5.8 | [DD575] | 01.1969-12.1976 |
| DAF | 1300DD 5.8 | [DD575] | 01.1970-10.1973 |
| DAF | 1400DF 6.2 | [DF615] | 01.1970-11.1981 |
| DAF | 1400DT 6.2 | [DT615] | 05.1972-10.1973 |
| DAF | 1600DD 5.8 | [DD575] | 01.1970-10.1973 |
| DAF | 1600DD 5.8 | [DD575] | 02.1972-10.1973 |
| DAF | 1600DF 6.2 | [DF615] | 01.1970-10.1973 |
| DAF | 1600DF 6.2 | [DF615] | 02.1972-10.1973 |
| DAF | 1600DF 6.2 | [DT615] | 01.1970-10.1973 |
| DAF | 1600DT 6.2 | [DT615] | 01.1973-10.1973 |
| DAF | 1600DT 6.2 | [DT615] | 02.1972-03.1973 |
| DAF | 1600DT 6.2 | [DT615] | 02.1972-10.1973 |
| DAF | 1600DTD 6.2 | [DTD615] | 01.1971-10.1973 |
| DAF | 1602DF 6.2 | [DF615] | 01.1970-10.1973 |
| DAF | 1602DT 6.2 | [DT615] | 02.1972-10.1973 |
| DAF | 160DF 6.2 | [DF615] | 01.1970-10.1973 |
| DAF | 160DT 6.2 | [DT615] | 02.1972-10.1973 |
| DAF | 163DF 6.2 | [DF615] | 01.1970-10.1973 |
| DAF | 163DT 6.2 | [DT615] | 02.1972-10.1973 |
| DAF | 1800DT 6.2 | [DT615] | 01.1970-10.1973 |
| DAF | 1902DT 6.2 | [DT615] | 01.1970-10.1973 |
| DAF | 900DD 5.8 | [DD575] | 01.1975-12.1981 |
Reference Information
| 0001402021 | BOSCH |
| 0001402046 | BOSCH |
| 0001402067 | BOSCH |
| 0001402069 | BOSCH |
| 0001416045 | BOSCH |
| 11.130.606 | ISKRA / LETRIKA |
| 11.139.024 | ISKRA / LETRIKA |
| 20401927BN | REAL |
| 20401927EL | REAL |
| 239858 | DAF |
| 260-46250 | DIXIE |
| 367022 | DAF |
| 5110036 | MEAT & DORIA |
| 6010729.0 | SANDO |
| 6010729.3 | SANDO |
| 622621 | DAF |
| 72736201 | MAHLE |
| 8715 | CEVAM |
| 901.201.113 | PSH |
| 943252253010 | MAGNETI MARELLI |
| AZK5183 | ISKRA / LETRIKA |
| CST10729AS | CASCO |
| CST10729ES | CASCO |
| IS9024 | ISKRA / LETRIKA |
| MAV126300 | SIOM |
| MS573 | MAHLE |
| MS 573 | MAHLE |
| MSR731 | MAGNETI MARELLI |
| S24BH0024A2 | SIDAT |
| SG0465 | GHIBAUDI |
| STB6045 | KRAUF |
| STR10287 | ELECTROLOG |
| STR50564 | WOODAUTO |
| STR79461 | ELECTROLOG |
| UD16623S | AS-PL |
| UNIT BOM 120-6069B | WAI / TRANSPO |
Video/Publications
