Associated Numbers
0001402038 0001410058 0001416020 0001416055 5000499961 51262019116 860653 UD16609S UNIT BOM 920-1287Specifications
Kilowatt | 5.4 kW |
Length (L.1) | 387 mm |
Mount Hole Center - Center (O.1) | 128 mm |
Mount Hole Center - Center (O.2) | 90 mm |
Mount Hole Center - Center (O.3) | 90 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
No./Teeth (Replaces) | 9 qty |
Oil Sealed | Yes |
Pinion at Rest (B) | 47 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | BOSCH |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
IKARUS | 250 | [D.2...] | 01.1977- |
IKARUS | 260 | [D.2...] | 01.1977- |
IKARUS | 280 | [D.2...] | 01.1977- |
Reference Information
BOM 51262019116 920-1287 UNIT 1410058 0001410058 STR1646 1416055 0001416055 1402038 0001402038 860653 5000499961 0001416020 1416020Video/Publications
0001402038 0001410058 0001416020 0001416055 5000499961 51262019116 860653 UNIT BOM 920-1287Add Your Number
