Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 420.81 including GST
NZ$ 365.92 excluding GST
or four payments of $105.20
with
Learn More
UOM:
each
Product Code:
S0422
Quantity In Stock Nationally
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
0001218141Associated Numbers
0001218141 0001218741 10554 111421 11643 20401433OE 20404711RC 22.0554 25-1192 30743R 35258970 35260920 3800 42015930 46231644 6010334 6030117 63222034 63222138 7589005 7589151 75891510 7726946 77679430 8015930 AES7143 CS554 CST10334GS CST30117RS DRS5930 EAA-121497 GS218741-A LRS00743 SS170 STR52004 UNIT BOM 120-5055Specifications
| Kilowatt | 2.20 kW |
| Length (L.1) | 272 mm |
| Mount Hole Center - Center (O.1) | 120 mm |
| Mount Hole Center - Center (O.2) | 85 mm |
| Mount Hole Center - Center (O.3) | 85 mm |
| Mount Hole Diameter (C.1) | M10x1.5 mm |
| Mount Hole Diameter (C.2) | M10x1.5 mm |
| Mount Hole Diameter (C.3) | M10x1.5 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 3 qty |
| No./Teeth | 9 qty |
| No./Teeth (Replaces) | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 29 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 82 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| ALFA ROMEO | AR 6 Bus (280_) 1.9 D (280) | 160D100 | 04.1985-12.1989 |
| ALFA ROMEO | AR 6 Van (280_) 1.9 D (280) | 160D100 | 04.1985-12.1989 |
| CITROËN | C25 Bus (280_, 290_) 1.9 TD | M705 | 04.1992-02.1994 |
| CITROËN | C25 Platform/Chassis (280_, 290_) 1.9 DT | M705 | 10.1991-01.1994 |
| FIAT | Ducato 1.9 Diesel | [149B1.000] | 01.1988-08.1990 |
| FIAT | Ducato 1.9 Diesel | [149B1.000] | 07.1990-03.1994 |
| FIAT | Ducato 1.9 Diesel | [230A2.000] | 03.1994-04.2002 |
| FIAT | Ducato 1.9 Diesel Combinato | [230A2.000] | 06.1995-04.2002 |
| FIAT | Ducato 1.9 Diesel Panorama | [149B1.000] | 02.1987-08.1990 |
| FIAT | Ducato 1.9 Diesel Panorama | [149B1.000] | 07.1990-03.1994 |
| FIAT | Ducato 1.9 TD | [230A3.000] | 03.1994-04.2002 |
| FIAT | Ducato 1.9 TD | [230A4.000] | 08.1994-04.2002 |
| FIAT | Ducato 1.9 TD | [280A1.000] | 03.1989-03.1994 |
| FIAT | Ducato 1.9 TD | [280A1.000] | 03.1989-08.1990 |
| FIAT | Ducato 1.9 TD Panorama | [280A1.000] | 03.1989-08.1990 |
| FIAT | Ducato 1.9 TD Panorama | [280A1.000] | 07.1990-03.1994 |
| FIAT | DUCATO Bus (230_) 1.9 D Combinato | 230A2.000 | 06.1995-04.2002 |
| FIAT | DUCATO Bus (230_) 1.9 TD Combinato | 230A4.000 | 08.1994-04.2002 |
| FIAT | DUCATO Bus (230_) 1.9 TD Panorama/Combinato | 230A3.000 | 03.1994-04.2002 |
| FIAT | DUCATO Panorama (280_) 1.9 D | 149B1.000 | 02.1987-08.1990 |
| FIAT | DUCATO Panorama (280_) 1.9 TD | 280A1.000 | 03.1989-08.1990 |
| FIAT | DUCATO Panorama (290_) 1.9 D | 149B1.000 | 07.1990-03.1994 |
| FIAT | DUCATO Panorama (290_) 1.9 TD | 280A1.000 | 07.1990-03.1994 |
| FIAT | DUCATO Platform/Chassis (230_) 1.9 D | 230A2.000 | 03.1994-04.2002 |
| FIAT | DUCATO Platform/Chassis (230_) 1.9 TD | 230A3.000 | 03.1994-04.2002 |
| FIAT | DUCATO Platform/Chassis (230_) 1.9 TD CAT | 230A4.000 | 08.1994-04.2002 |
| FIAT | DUCATO Platform/Chassis (280_) 1.9 D | 149B1.000 | 01.1988-08.1990 |
| FIAT | DUCATO Platform/Chassis (280_) 1.9 TD | 280A1.000 | 03.1989-08.1990 |
| FIAT | DUCATO Platform/Chassis (290_) 1.9 D | 149B1.000 | 06.1990-05.1994 |
| FIAT | DUCATO Platform/Chassis (290_) 1.9 TD | 280A1.000 | 03.1989-03.1994 |
| FIAT | DUCATO Van (230_) 1.9 D | 230A2.000 | 03.1994-04.2002 |
| FIAT | DUCATO Van (230_) 1.9 TD | 230A3.000 | 03.1994-04.2002 |
| FIAT | DUCATO Van (230_) 1.9 TD CAT | 230A4.000 | 08.1994-04.2002 |
| FIAT | DUCATO Van (280_) 1.9 D | 149B1.000 | 01.1988-08.1990 |
| FIAT | DUCATO Van (280_) 1.9 TD | 280A1.000 | 03.1989-08.1990 |
| FIAT | DUCATO Van (290_) 1.9 D | 149B1.000 | 07.1990-03.1994 |
| FIAT | DUCATO Van (290_) 1.9 TD | 280A1.000 | 03.1989-03.1994 |
| FIAT | Talento 1.9 Diesel | [149B1.000] | 03.1989-03.1994 |
| FIAT | TALENTO Bus (290_) 1.9 D (290UEHK) | 149B1.000 | 03.1989-03.1994 |
| FIAT | TALENTO Platform/Chassis (290_) 1.9 D (290UAK, 290UTK) | 149B1.000 | 03.1989-03.1994 |
| FIAT | TALENTO Van (290_) 1.9 D (290UK) | 149B1.000 | 03.1989-03.1994 |
Reference Information
| 0001218141 | BOSCH |
| 0001218741 | BOSCH |
| 0986015930 | BOSCH |
| 10554 | KUHNER |
| 111421 | CARGO |
| 11643 | EAI |
| 20401433OE | REAL |
| 20404711RC | REAL |
| 220183 | ERA |
| 22.0554 | LAUBER |
| 25-1192 | ELSTOCK |
| 30743R | WAI |
| 330706 | LOGISTIK |
| 35258970 | PRESTOLITE |
| 35260920 | PRESTOLITE |
| 3800 | CEVAM |
| 42015930 | HERTH+BUSS |
| 46231644 | FIAT |
| 5010165 | MEAT & DORIA |
| 5802000 | PEUGEOT |
| 6010334 | SANDO |
| 6030117 | SANDO |
| 63222034 | MAGNETI MARELLI |
| 63222138 | MAGNETI MARELLI |
| 71721282 | FIAT |
| 71721296 | FIAT |
| 7589005 | FIAT |
| 7589151 | FIAT |
| 75891510 | FIAT |
| 7726946 | FIAT |
| 77679430 | FIAT |
| 8015930 | FRIESEN |
| AES7143 | AUTOELECTRO |
| ANM18150X | ANDEL |
| CS554 | HC PARTS |
| CST10334GS | CASCO |
| CST30117RS | CASCO |
| DRS5930 | DELCO |
| F032111421 | CARGO |
| GS218741-A | GPARTS |
| LRS00743 | LUCAS |
| LRS743 | LUCAS |
| MAV123340 | SIOM |
| MAV2150 | SIOM |
| RNL1593 | RNL |
| S0422 | AS-PL |
| S12BH0083A2 | SIDAT |
| SS170 | SOVEREIGN |
| STA0219R | BOVEZ |
| STR10166 | ELECTROLOG |
| STR1994 | ELECTROLOG |
| STR52004 | WOODAUTO |
| STRL149 | 3EFFE |
| STX200527 | STARDAX |
| UD102786S | AS-PL |
| UNIT BOM 120-5055 | WAI |
Video/Publications
