Associated Numbers
0001416001 10198 10198B 10198P 11.139.043 19024009 20401967BN 513210050000 519510150000 6010769 860661 9125210 AZK5403 CST10769AS IS9037 UD00201S UNIT BOM 904-310Specifications
Insulated Earth | Yes |
Kilowatt | 5.4 kW |
Length (L.1) | 385 mm |
Mount Hole Center - Center (O.1) | 127 mm |
Mount Hole Center - Center (O.2) | 127 mm |
Mount Hole Center - Center (O.3) | 127 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
Mount Hole Diameter (C.3) | 11 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
No./Teeth (Replaces) | 9 qty |
Oil Sealed | Yes |
Pinion at Rest (B) | 36.5 mm |
Rotation | CW |
Spigot Diameter (A) | 92 mm |
Unit Type | BOSCH |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
STEYR | SFL 11 HUA 280 11.0 | [9FUA] | 10.1987- |
STEYR | SG 18 HUA 280 11.0 | [9FUA] | 07.1987- |
STEYR | SL 11 HU 250 11.0 | [9FUA] | 01.1984- |
STEYR | SL 11 HUA 280 11.0 | [9FUA] | 12.1986- |
STEYR | SS 11 HU 200 11.0 | [9FUA] | 06.1984- |
STEYR | SS 11 HUA 280 11.0 | [9FUA] | 06.1984- |
Reference Information
20401967BN 88214020 6010769 STR79480 8895 10198P 10198B 18113N S0435 0001416001 AZK5403 10198 IS9037 STRF100 33657 UD00201S 904-310 860661 BOM 5.1951E+11 UNIT 11.139.043 1410024 MS 0001410024 9125210 CST10769AS PRSF100 STR1823 1416001 19024009 581.201.093.010 504 5.1321E+11Video/Publications
0001416001 10198 10198B 10198P 11.139.043 19024009 20401967BN 513210050000 519510150000 6010769 860661 9125210 AZK5403 CST10769AS IS9037 MS 504 STRF100 UD00201S UNIT BOM 904-310 S0435Add Your Number
