Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 229.68 including GST
NZ$ 199.72 excluding GST
or four payments of $57.42
with
Learn More
each
S0554
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
0001107009Associated Numbers
0001107009 0001113004 0001208233 0986015560 100.002.092 100.504.092 10131 10687 20401791RC 220153 25-2016 3605 547199 6010197 60537529 60562974 605629740 60875800 8EA725983-001 8EA730203-001 943251273010 944280155600 AES2133 CST10197 CST10197AS CST10197ES CST10197GS CST10197OS CST10197RS DRS4880 DRS5560 EAA-141257 EAA-151027 LRS00233 MSR901 SS506 UD12324SSpecifications
| Kilowatt | 1.10 kW |
| Length (L.1) | 220 mm |
| Mount Hole Center - Center (O.1) | 105 mm |
| Mount Hole Diameter (C.1) | 10.50 mm |
| Mount Hole Diameter (C.2) | 10.50 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 28 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 76 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| ALFA ROMEO | 145 1.6 | [AR33201] | 01.1994-12.1996 |
| ALFA ROMEO | 145 1.7 16V | [AR33401] | 01.1994-12.1996 |
| ALFA ROMEO | 146 1.6 | [AR33201] | 01.1995-12.1996 |
| ALFA ROMEO | 146 1.7 16V | [AR33401] | 01.1994-12.1996 |
| ALFA ROMEO | 33 1.2 | [AR30585] | 06.1983-12.1989 |
| ALFA ROMEO | 33 1.3 i.e. | [AR30753] | 01.1991-12.1994 |
| ALFA ROMEO | 33 1.5 | [AR30734] | 01.1990-04.1993 |
| ALFA ROMEO | 33 1.7 i.e. 16V | [AR30746] | 01.1990-12.1994 |
| ALFA ROMEO | 33 1.7 i.e. 16V | [AR30747] | 01.1990-12.1994 |
| ALFA ROMEO | 33 1.8 TD | [VM96A] | 07.1990-09.1994 |
| ALFA ROMEO | Alfasud Giardinetta 1.3 | [AR30180] | 01.1978-07.1979 |
| ALFA ROMEO | Alfasud Sprint 1.3 | [AR30184] | 09.1976-12.1981 |
| ALFA ROMEO | Alfasud Sprint 1.4 | [AR30164] | 05.1978-02.1980 |
| ALFA ROMEO | Alfasud Sprint 1.4 | [AR30168] | 07.1979-12.1989 |
| ALFA ROMEO | Alfasud Sprint 1.5 Veloce | [AR30146] | 01.1980-12.1987 |
| ALFA ROMEO | Alfasud Sprint 1.7 | [AR30550] | 03.1987-12.1989 |
| ALFA ROMEO | Alfasud Sprint 1.7 i.e. | [AR30558] | 10.1987-12.1989 |
| ALFA ROMEO | Arna 1.2 | [AR30500] | 01.1985-12.1986 |
| ALFA ROMEO | Arna 1.2 | [AR31000] | 01.1985-12.1986 |
| ALFA ROMEO | Arna 1.2 | [AR31002] | 03.1986-12.1986 |
| ALFA ROMEO | Arna 1.3 TI | [AR30168] | 03.1983-12.1986 |
| ALFA ROMEO | Arna 1.3 TI | [AR31010] | 01.1985-12.1986 |
| ALFA ROMEO | Arna 1.5 | [AR30182] |
Reference Information
| 0001107009 | BOSCH |
| 0001113004 | BOSCH |
| 0001208233 | BOSCH |
| 0986015560 | BOSCH |
| 100.002.092 | PSH |
| 100.504.092 | PSH |
| 10131 | KUHNER |
| 10687 | KUHNER |
| 20401791RC | REAL |
| 220153 | ERA |
| 25-2016 | ELSTOCK |
| 330283 | LOGISTIK |
| 330839 | LOGISTIK |
| 3605 | CEVAM |
| 547199 | ALFA ROMEO |
| 6010197 | SANDO |
| 60537529 | ALFA ROMEO |
| 60562974 | FIAT |
| 605629740 | ALFA ROMEO |
| 60875800 | FIAT |
| 8EA725983-001 | HELLA |
| 8EA730203-001 | HELLA |
| 943251273010 | MAGNETI MARELLI |
| 944280155600 | MAGNETI MARELLI |
| AES2133 | AUTOELECTRO |
| ALT136060 | SIOM |
| ANM17780X | ANDEL |
| CST10197 | CASCO |
| CST10197AS | CASCO |
| CST10197ES | CASCO |
| CST10197GS | CASCO |
| CST10197OS | CASCO |
| CST10197RS | CASCO |
| DRS4880 | DELCO |
| DRS5560 | DELCO |
| LRS00233 | LUCAS |
| LRS233 | LUCAS |
| MAV121970 | SIOM |
| MAV321300 | SIOM |
| MSR901 | MAGNETI MARELLI |
| S129.652 | PSH |
| S148.482 | PSH |
| SS506 | SOVEREIGN |
| STR10175 | ELECTROLOG |
| STR1467 | ELECTROLOG |
| STRS172 | 3EFFE |
| STRS702 | 3EFFE |
| UD12324S | AS-PL |
Video/Publications
