Associated Numbers
0001147408 UD20329S 0001147409 0986023290 115339 CST10005GS DRS0869 3197 25-4275 STB7408 254908B 254908 LRS02602 2719060200 A2719060200 550.553.132 6010005.1 UNIT BOM 120-6534 BOS0001147408Specifications
Kilowatt | 2 kW |
Length (L.1) | 229.5 mm |
Mount Hole Center - Center (O.1) | 106 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 13 qty |
Pinion at Rest (B) | 28.5 mm |
Rotation | CW |
Spigot Diameter (A) | 70 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
MERCEDES BENZ | C 180 1.8 CGi | [M271.820] | 01.2007- |
MERCEDES BENZ | C 200 1.8 CGi | [M271.820] | 01.2011- |
MERCEDES BENZ | C 200 2.0 CGi | [M271.820] | 01.2007- |
MERCEDES BENZ | C 250 1.8 CGi | [M271.860] | 01.2009- |
MERCEDES BENZ | E 200 1.8 CGi | [M271.820] | 01.2009- |
MERCEDES BENZ | E 200 1.8 CGi | [M271.820] | 01.2010- |
MERCEDES BENZ | E 200 1.8 CGi | [M271.860] | 01.2009- |
MERCEDES BENZ | E 200 1.8 CGi | [M271.860] | 01.2010- |
MERCEDES BENZ | E 200 1.8 NGT | [M271.958] | 01.2011- |
MERCEDES BENZ | E 250 1.8 CGi | [M271.860] | 01.2009- |
MERCEDES BENZ | SLK 200 1.8 | [M271.860] | 01.2011- |
MERCEDES BENZ | SLK 200 1.8 | [M271.861] | 01.2011- |
MERCEDES BENZ | SLK 250 1.8 | [M271.860] | 01.2011- |
MERCEDES BENZ | SLK 250 1.8 | [M271.861] | 01.2011- |
Reference Information
550.553.132 20401500OE 42023290 A2719060200 STRF977 254908 RNL2329 332127 115339 A27190602000080 2719060200 BOS0001147408 1147408 25-4275 UD20329S STB7408 1147409 STR1842 BOM 6010005.1 LRS2602 UNIT 3197 254908B DRS0869 MAV120050 120-6534 11023290 000986023290 0001147409 CST10005GS 2.71906E+13 0001147408 986023290 LRS02602Video/Publications
0001147408 0001147409 0986023290 11023290 115339 25-4275 254908 254908B 2719060200 3197 42023290 550.553.132 6010005.1 A2719060200 BOS0001147408 CST10005GS DRS0869 LRS02602 LRS2602 RNL2329 STB7408 STRF977 UD20329S UNIT BOM 120-6534Add Your Number
