Associated Numbers
0001121032 0001121033 001911023B 0986022510 115542 25-4018 300.576.093 3136 42022510 6010419 88214363 AEY2346 BOS0001121032 CS1576 CST10419 CST10419AS CST10419ES CST10419GS CST10419OS CST10419RS DRT2510 LRS02346 STB2103 STB2103BA UD13765S UNIT BOM 120-6508Specifications
Kilowatt | 1.1 kW |
Length (L.1) | 211 mm |
Mount Hole Center - Center (O.1) | 74 mm |
Mount Hole Center - Center (O.2) | 105 mm |
Mount Hole Center - Center (O.3) | 74 mm |
Mount Hole Diameter (C.1) | 8.5 mm |
Mount Hole Diameter (C.2) | 8.5 mm |
Mount Hole Diameter (C.3) | M8x1.25 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 3.5 mm |
Rotation | CW |
Spigot Diameter (A) | 82.5 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
SEAT | Ibiza 1.4 | [BKY] | 01.2004-12.2007 |
SKODA | Fabia 1.4 16V | [BKY] | 01.2004-12.2007 |
VW | Polo 1.4 16V | [BKY] | 01.2005-12.2007 |
VW | Polo 1.6 | [BAH] | 01.2005- |
Reference Information
88214363 ANM24730X CST10419RS STR1553 300.576.093 AEY2346 STB2103BA CST10419 CS1576 CST10419AS 986022510 3136 115542 1121032 1121033 42022510 25-4018 CST10419GS BOS0001121032 CST10419ES 5010489 LRS2346 6010419 BOM UNIT 001911023B CST10419OS DRT2510 120-6508 000986022510 LRS02346 332061 S12BH0631A2 STB2103 0001121032 STRL753 0001121033 UD13765SVideo/Publications
0001121032 0001121033 001911023B 0986022510 115542 25-4018 300.576.093 3136 42022510 6010419 88214363 AEY2346 BOS0001121032 CS1576 CST10419 CST10419AS CST10419ES CST10419GS CST10419OS CST10419RS DRT2510 LRS02346 LRS2346 STB2103 STB2103BA STRL753 UD13765S UNIT BOM 120-6508Add Your Number
