Associated Numbers
0001120400 0001120401 02T911023D 02T911023G 02T911023GX 063521204000 101197 101197B 101197V 101282 113515 20401831 220544 25-3131 300.559.102 32613N 32613R 3345 42020780 438261 458421 6010138 88212172 944280207800 CS1282 CST10138 CST10138AS CST10138ES CST10138GS CST10138OS CST10138RS D7ES6 DRT0780 DT1890 EAA-121233 LRS01610 MRS20780 RAS41891 STB1282 STR50250Specifications
Kilowatt | 0.9 kW |
Length (L.1) | 194 mm |
Mount Hole Center - Center (O.1) | 151 mm |
Mount Hole Diameter (C.1) | 12.5 mm |
Mount Hole Diameter (C.2) | 12.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 52 mm |
Rotation | ACW |
Spigot Diameter (A) | 76.5 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
AUDI | A2 1.4 | [AUA] | 02.2000-08.2005 |
AUDI | A2 1.4 | [BBY] | 02.2000-08.2005 |
AUDI | A2 1.6 FSi | [BAD] | 05.2002-08.2005 |
SEAT | Cordoba 1.2 | [AZQ] | 10.2002-06.2006 |
SEAT | Cordoba 1.2 | [BME] | 10.2002-06.2006 |
SEAT | Cordoba 1.4 16V | [AUB] | 10.2002-11.2009 |
SEAT | Cordoba 1.4 16V | [BBY] | 09.2002-12.2007 |
SEAT | Cordoba 1.4 16V | [BBZ] | 10.2002-11.2009 |
SEAT | Cordoba 1.4 16V | [BKY] | 09.2002-12.2007 |
SEAT | Cordoba 1.6 | [BAH] | 04.2003-11.2009 |
SEAT | Ibiza 1.2 | [AZQ] | 02.2002-06.2006 |
SEAT | Ibiza 1.2 | [BME] | 02.2002-06.2006 |
SEAT | Ibiza 1.4 16V | [AUB] | 02.2002-11.2009 |
SEAT | Ibiza 1.4 16V | [BBY] | 02.2002-12.2007 |
SEAT | Ibiza 1.4 16V | [BBZ] | 02.2002-11.2009 |
SEAT | Ibiza 1.4 16V | [BKY] | 02.2002-12.2007 |
SEAT | Ibiza 1.6 | [BAH] | 02.2003-11.2009 |
SKODA | Fabia 1.2 | [AWY] | 07.2001-04.2007 |
SKODA | Fabia 1.2 | [AWY] | 07.2001-12.2007 |
SKODA | Fabia 1.2 | [AZQ] | 01.2003-03.2008 |
SKODA | Fabia 1.2 | [AZQ] | 01.2003-12.2007 |
SKODA | Fabia 1.2 | [BMD] | 07.2001-04.2007 |
SKODA | Fabia 1.2 | [BMD] | 07.2001-12.2007 |
SKODA | Fabia 1.2 | [BME] | 01.2003-03.2008 |
SKODA | Fabia 1.2 | [BME] | 01.2003-12.2007 |
SKODA | Fabia 1.4 16V | [AUA] | 05.2000-12.2007 |
SKODA | Fabia 1.4 16V | [AUA] | 10.1999-12.2007 |
SKODA | Fabia 1.4 16V | [AUA] | 12.1999-03.2008 |
SKODA | Fabia 1.4 16V | [AUB] | 04.2000-12.2007 |
SKODA | Fabia 1.4 16V | [AUB] | 12.1999-03.2008 |
SKODA | Fabia 1.4 16V | [AUB] | 12.1999-12.2007 |
SKODA | Fabia 1.4 16V | [BBY] | 05.2000-12.2007 |
SKODA | Fabia 1.4 16V | [BBY] | 10.1999-12.2007 |
SKODA | Fabia 1.4 16V | [BBY] | 12.1999-03.2008 |
SKODA | Fabia 1.4 16V | [BBZ] | 04.2000-12.2007 |
SKODA | Fabia 1.4 16V | [BBZ] | 12.1999-03.2008 |
SKODA | Fabia 1.4 16V | [BBZ] | 12.1999-12.2007 |
SKODA | Fabia 1.4 16V | [BKY] | 05.2000-12.2007 |
SKODA | Fabia 1.4 16V | [BKY] | 10.1999-12.2007 |
SKODA | Fabia 1.4 16V | [BKY] | 12.1999-03.2008 |
VW | Bora 1.6 FSi | [BAD] | 01.2002-05.2005 |
VW | Fox 1.2 | [BMD] | 04.2005-07.2011 |
VW | Fox 1.2 | [CHFA] | 09.2010-12.2011 |
VW | Fox 1.2 | [CHFB] | 04.2005-07.2011 |
VW | Fox 1.4 | [BKR] | 04.2005-12.2009 |
VW | Golf IV 1.6 FSi | [BAD] | 01.2002-06.2005 |
VW | Golf IV 1.6 FSi | [BAD] | 01.2002-06.2006 |
VW | Lupo 1.6 GTi | [AVY] | 09.2000-07.2005 |
VW | New Beetle 1.4 | [BCA] | 01.2003-09.2010 |
VW | New Beetle 1.4 | [BCA] | 11.2001-09.2010 |
VW | Polo 1.2 | [AWY] | 01.2002-05.2007 |
VW | Polo 1.2 | [BMD] | 01.2002-05.2007 |
VW | Polo 1.2 12V | [AZQ] | 10.2001-07.2007 |
VW | Polo 1.2 12V | [BME] | 10.2001-07.2007 |
VW | Polo 1.4 | [BBY] | 11.2002-04.2012 |
VW | Polo 1.4 | [BBZ] | 11.2003- |
VW | Polo 1.4 | [BKY] | 11.2002-04.2012 |
VW | Polo 1.4 16V | [AUA] | 10.2001-05.2008 |
VW | Polo 1.4 16V | [AUB] | 10.2001-05.2008 |
VW | Polo 1.4 16V | [BBY] | 10.2001-05.2008 |
VW | Polo 1.4 16V | [BBZ] | 10.2001-05.2008 |
VW | Polo 1.4 16V | [BKY] | 10.2001-05.2008 |
VW | Polo 1.4 Fsi | [AXU] | 02.2002-07.2006 |
Reference Information
02T911023GX 2T911023D 113515 STR1235 2T911023G 220530 42020780 6010138.1 101282B DRT0780 DT1890 EAA-121233 438261 1120400 CST10138GS 1120401 MRS20780 02T911023G PRSW165 20401831BN 6352120400 02T911023D 2T911023Q 6010138 300.559.102.210 STM1037 5010026 101282 88212172 STRW165 02T911023Q STB1282 CST10138AS 220544 D7ES6 9.4428E+11 LRS01610 32613N S12BH0176 3345 CS1282 32613R 25-3131 458421 LRS1610 S12BH0176A2 0001120400 0001120401Video/Publications
0001120400 0001120401 02T911023D 02T911023G 02T911023GX 063521204000 101282 101282B 11020780 113515 20401831BN 220544 25-3131 300.559.102 32613N 32613R 3345 42020780 438261 458421 6010138.0 6010138.1 8020780 88212172 944280207800 CS1282 CST10138AS CST10138GS D7ES6 DRT0780 DT1890 EAA-121233 LRS01610 LRS1610 MAV121380 MRS20780 RAS41891 STB1282 STM1037 STR50250 STRW165 220530Add Your Number
