Associated Numbers
0001312001 0001315002 10957 113705 120-30205 25-0203 260-21105 5417601 810.015.112 833081 833669 8EA737-103-001 BOS0001315002 CS957 LRS01032 S0694S STB8722 STR50692 UD15199SSpecifications
Kilowatt | 2 kW |
Length (L.1) | 255 mm |
Mount Hole Center - Center (O.1) | 105 mm |
Mount Hole Diameter (C.1) | 12.5 mm |
Mount Hole Diameter (C.2) | 12.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 21 mm |
Rotation | ACW |
Spigot Diameter (A) | 82 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
NSU | RO 80 1.0 | [KKM] | 07.1977- |
VOLVO PENTA | Engine 1.7 | [MD3B] | 05.1971-10.1975 |
Reference Information
833031 331759 810.015.112 8EA737-103-001 0001315002 3803073 1315002 5.1217E+12 STRS733 10957 838060 833669 BOS0001315002 STR50692 UD15199S 260-21105 5417601 833081 LRS1032 0001312001 1312001 113705 120-30205 LRS01032 25-0203 STB8722 CS957 S0694SVideo/Publications
0001312001 0001315002 10957 113705 120-30205 25-0203 260-21105 5417601 810.015.112 833081 833669 8EA737-103-001 BOS0001315002 CS957 LRS01032 LRS1032 S0694S STB8722 STR50692 STRS733 UD15199SAdd Your Number
