Associated Numbers
0001109405 063720039010 116369 120-10239 20401984 220914 254981 254981B 500.533.093 5801441816 6010489 88214909 BOS0001109405 CST10489 CST10489AS CST10489ES CST10489GS CST10489OS CST10489RS MQS039 STB9405 UD15242S UNIT BOM 120-3004Specifications
Kilowatt | 2.6 kW |
Length (L.1) | 246.4 mm |
Mount Hole Center - Center (O.1) | 103.3 mm |
Mount Hole Center - Center (O.2) | 146 mm |
Mount Hole Center - Center (O.3) | 103.3 mm |
Mount Hole Diameter (C.1) | 12 mm |
Mount Hole Diameter (C.2) | 12 mm |
Mount Hole Diameter (C.3) | 12 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 26.5 mm |
Rotation | CW |
Spigot Diameter (A) | 110 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
NEW HOLLAND | TN60DA 3.0 | 01.2004-12.2008 | |
NEW HOLLAND | TN60SA 3.0 | 01.2004-12.2008 | |
NEW HOLLAND | TN70DA 3.0 | 01.2004-12.2008 | |
NEW HOLLAND | TN75DA 3.0 | 01.2004-12.2008 |
Reference Information
0001109405 CST10489GS 20401984 220914 500.533.093 MQS039 116369 CST10489OS 1986S10035 254981 5801441816 STB9405 63720039010 1109405 UD15242S BOM STR1521 UNIT BOS0001109405 CST10489 STRF969 120-10239 S12BH0263A2 CST10489RS 88214909 RNL109405 120-3004 CST10489AS S0698S 500.533.093.212 CST10489ES 0001986S10035 6010489 254981BVideo/Publications
0001109405 063720039010 116369 120-10239 20401984 220914 254981 254981B 500.533.093 5801441816 6010489 88214909 BOS0001109405 CST10489 CST10489AS CST10489ES CST10489GS CST10489OS CST10489RS MQS039 RNL109405 STB9405 STRF969 UD15242S UNIT BOM 120-3004Add Your Number
