Associated Numbers
0001107093 160.553.082 201315 20417111 23300-1F705 25-3299 6045111 8EA738180-001 9569 CST45111 CST45111AS CST45111ES CST45111GS CST45111OS CST45111RS DRS0682 DS1792 JS1315 LRS01740 RAS31793 STB7793 UD20333SSpecifications
Kilowatt | 1.1 kW |
Length (L.1) | 210.5 mm |
Mount Hole Center - Center (O.1) | 106 mm |
Mount Hole Diameter (C.1) | 10.5 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 8 qty |
Pinion at Rest (B) | 7 mm |
Rotation | CW |
Spigot Diameter (A) | 70 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
NISSAN | Micra 1.0 i 16V | [CG10DE] | 08.1992-09.2000 |
NISSAN | Micra 1.0 i 16V | [CG10DE] | 09.2000-02.2003 |
NISSAN | Micra 1.4 i 16V | [CGA3DE] | 09.2000-02.2003 |
Reference Information
LRS1740 160.553.082 23300-1F705 STB7793 CST45111RS 9569 STR10169 201315 LRS01740 UD20333S 6045111 20417111 JS1315 8EA738180-001 ANM12902X CST45111 0001107093 1107093 CST45111GS RAS31793 STRS226 25-3299 CST45111ES CST45111AS MAV471110 DRS0682 CST45111OS DS1792Video/Publications
0001107093 160.553.082 201315 20417111 23300-1F705 25-3299 6045111 8EA738180-001 9569 CST45111 CST45111AS CST45111ES CST45111GS CST45111OS CST45111RS DRS0682 DS1792 JS1315 LRS01740 LRS1740 MAV471110 RAS31793 STB7793 STRS226 UD20333SAdd Your Number
