Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 252.51 including GST
NZ$ 219.57 excluding GST
or four payments of $63.13
with
Learn More
each
S0723S
1
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
0001110071Associated Numbers
0001110071 0986017170 10792 10793B 12411729982 12411736922 17497N 20401005 210.529.092 26-3040 31234R 458473 6010500 88212704 AES2227 BOS0001110071 CST10500 CST10500AS CST10500ES CST10500GS CST10500OS CST10500RS DRS3685 DS4795 EAA-121769 LRT00227 S1050B STB0793 STR50341 UD20349S
50-516
Specifications
For opposite mount check: S0394
| Kilowatt | 1.70 kW |
| Length (L.1) | 267 mm |
| Mount Hole Center - Center (O.1) | 105 mm |
| Mount Hole Diameter (C.1) | M10x1.5 mm |
| Mount Hole Diameter (C.2) | M10x1.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 22 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 76 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| BMW | 530 3.0 i | (E34)[M60B30(308S1)] | 09.1992-07.1996 |
| BMW | 530 3.0 i V8 | (E34)[M60B30(308S1)] | 09.1992-12.1995 |
| BMW | 535 3.5 i | (E39)[M62B35(358S1)] | 06.1996-08.1998 |
| BMW | 535 3.5 i | (E39)[M62B35(358S2)] | 09.1998-06.2003 |
| BMW | 540 4.0 i | (E34)[M60B40(408S1)] | 09.1993-07.1996 |
| BMW | 540 4.0 i V8 | (E34)[M60B40(408S1)] | 09.1992-12.1995 |
| BMW | 540 4.4 i | (E39)[M62B44(448S1)] | 03.1996-06.2003 |
| BMW | 540 4.4 i | (E39)[M62B44(448S1)] | 04.1997-12.2003 |
| BMW | 540 4.4 i | (E39)[M62B44(448S2)] | 03.1996-06.2003 |
| BMW | 540 4.4 i | (E39)[M62B44(448S2)] | 04.1997-12.2003 |
| BMW | 730 3.0 i | (E38)[M60B30(308S1)] | 03.1994-02.1996 |
| BMW | 730 3.0 i | (E38)[M60B30(308S1)] | 10.1994-11.2001 |
| BMW | 730 3.0 iL | (E38)[M60B30(308S1)] | 03.1994-02.1996 |
| BMW | 730 3.0 iL | (E38)[M60B30(308S1)] | 10.1994-11.2001 |
| BMW | 730 3.0 iL V8 | (E32)[M60B30(308S1)] | 04.1992-09.1994 |
| BMW | 730 3.0 i V8 | (E32)[M60B30(308S1)] | 04.1992-09.1994 |
| BMW | 735 3.5 i | (E38)[M62B35(358S1)] | 03.1996-08.1998 |
| BMW | 735 3.5 i | (E38)[M62B35(358S2)] | 09.1998-07.2001 |
| BMW | 735 3.5 iL | (E38)[M62B35(358S1)] | 03.1996-08.1998 |
| BMW | 735 3.5 iL | (E38)[M62B35(358S2)] | 09.1998-07.2001 |
| BMW | 740 4.0 i | (E38)[M60B40(408S1)] | 03.1994-02.1996 |
| BMW | 740 4.0 iL | (E38)[M60B40(408S1)] | 03.1994-02.1996 |
| BMW | 740 4.0 iL V8 | (E32)[M60B40(408S1)] | 05.1992-03.1994 |
| BMW | 740 4.0 i V8 | (E32)[M60B40(408S1)] | 05.1992-03.1994 |
| BMW | 740 4.4 i | (E38)[M62B44(448S1)] | 02.1996-07.2001 |
| BMW | 740 4.4 i | (E38)[M62B44(448S2)] | 02.1996-07.2001 |
| BMW | 740 4.4 iL | (E38)[M62B44(448S1)] | 02.1996-07.2001 |
| BMW | 740 4.4 iL | (E38)[M62B44(448S2)] | 02.1996-07.2001 |
| BMW | 840 4.0 i | (E31)[M60B40(408S1)] | 03.1993-02.1996 |
| BMW | 840 4.4 Ci | (E31)[M62B44(448S1)] | 03.1996-06.1999 |
| BMW | M5 5.0 | (E39)[S62B50(508S1)] | 10.1998-06.2003 |
Reference Information
| 0001110071 | BOSCH |
| 0986017170 | BOSCH |
| 10792 | KUHNER |
| 10793B | KUHNER |
| 12411729981 | BMW |
| 12411729982 | BMW |
| 12411736921 | BMW |
| 12411736922 | BMW |
| 17497N | WAI / TRANSPO |
| 20401005 | REAL |
| 210.529.092 | PSH |
| 220332 | ERA |
| 26-3040 | ELSTOCK |
| 31234R | WAI / TRANSPO |
| 330416 | LOGISTIK |
| 458473 | VALEO |
| 6010500 | SANDO |
| 88212704 | POWERMAX |
| AES2227 | AUTOELECTRO |
| ANM15905X | ANDEL |
| BOS0001110071 | WOODAUTO |
| CST10500 | CASCO |
| CST10500AS | CASCO |
| CST10500ES | CASCO |
| CST10500GS | CASCO |
| CST10500OS | CASCO |
| CST10500RS | CASCO |
| DRS3685 | DELCO |
| DS4795 | DELCO |
| LRT00227 | LUCAS |
| S1050B | PRESTOLITE |
| S131.935 | PSH |
| STB0793 | KRAUF |
| STR1165 | ELECTROLOG |
| STR50341 | WOODAUTO |
| STRF116 | 3EFFE |
| STX200548 | STARDAX |
| STX200548R | STARDAX |
| STX200549 | STARDAX |
| UD20349S | AS-PL |
Video/Publications
