Associated Numbers
46521786 465217860 46521787 50008582 9000081009 F000AL0300 F000AL0305 F010AL0301 STB2009 UD20356SSpecifications
Kilowatt | 0.8 kW |
Length (L.1) | 218 mm |
Mount Hole Center - Center (O.1) | 56.5 mm |
Mount Hole Center - Center (O.2) | 87.5 mm |
Mount Hole Center - Center (O.3) | 56.5 mm |
Mount Hole Diameter (C.1) | M8x1.25 mm |
Mount Hole Diameter (C.2) | 8.5 mm |
Mount Hole Diameter (C.3) | M8x1.25 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 13 mm |
Rotation | CW |
Spigot Diameter (A) | 67 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
FIAT | Elba 1.0 D | ||
FIAT | Fiorino 1.0 | ||
FIAT | Fiorino 1.5 | ||
FIAT | Mille 1.0 MPi | ||
FIAT | Palio 1.5 MPi 8V | ||
FIAT | Siena 1.5 | ||
FIAT | Strada 1.5 MPi 8V | ||
FIAT | Uno 1.0 Spi | ||
FIAT | Uno 1.5 Spi | ||
FIAT | Weekend 1.5 MP |
Reference Information
9000081009 F000AL0305 50008582 465217860 F000AL0300 F010AL0301 000F010AL0301 46521787 000F000AL0305 46521786 UD20356S 000F000AL0300 STB2009 0009000081009Video/Publications
46521786 465217860 46521787 50008582 9000081009 F000AL0300 F000AL0305 F010AL0301 STB2009 UD20356SAdd Your Number
