Associated Numbers
0001358007 0001358021 0001358050 0001359107 0001362052 101121 20401123 25-0177 260-62112 33723 6853800 800.002.113 8943 8EA737-583-001 CS1121 CST10321 CST10321AS CST10321ES CST10321GS CST10321OS CST10321RS DRS1234 DS2344 EAA-111255 EAA-141541 LRS01031 STB1121 STR50172 UD16573S UNIT BOM 120-561Specifications
Kilowatt | 2.4 kW |
Length (L.1) | 315 mm |
Mount Hole Center - Center (O.1) | 90 mm |
Mount Hole Center - Center (O.2) | 127 mm |
Mount Hole Center - Center (O.3) | 90 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
Mount Hole Diameter (C.3) | 11 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 49 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CLAAS | Consul | [4.236] | 01.1966-12.1978 |
CLAAS | Dominator 48 | [4.236] | 01.1978-12.1988 |
CLAAS | Dominator 56 | [4.248] | 01.1978-12.1982 |
CLAAS | Dominator 66 | [6.354.4] | 01.1979-12.1985 |
CLAAS | Dominator 76 6.1 | [6.372] | 01.1978-12.1985 |
CLAAS | Dominator 80 6.1 | [6.372] | 01.1973-12.1974 |
CLAAS | Dominator 85 6.1 | [6.372] | 01.1974-12.1985 |
CLAAS | Jaguar 60SF | [6.354] | 01.1974-12.1976 |
CLAAS | Mercator 50 | [4.236] | 01.1973-12.1975 |
CLAAS | Mercator 60 | [6.354] | 01.1973-12.1981 |
CLAAS | Mercator 70 | [6.354] | 01.1973-12.1974 |
CLAAS | Mercator 75 | [6.354] | 01.1973-12.1981 |
Reference Information
0001362052 20401123 1362052 331953 STRS296 UD16573S EAA-141541 0001358007 1358007 120-561 CST10321GS 25-0177 8EA737-583-001 STB1121 CST10321ES 1358021 260-62112 CST10321OS 0001358050 8943 STR50172 800.002.113 BOM DS2344 UNIT LRS1031 101121 CST10321AS 1359107 MAV123210 CS1121 0001359107 LRS01031 0001358021 6853800 DRS1234 1358050 CST10321 CST10321RS 33723 EAA-111255Video/Publications
0001358007 0001358021 0001358050 0001359107 0001362052 101121 20401123 25-0177 260-62112 33723 6853800 800.002.113 8943 8EA737-583-001 CS1121 CST10321 CST10321AS CST10321ES CST10321GS CST10321OS CST10321RS DRS1234 DS2344 EAA-111255 EAA-141541 LRS01031 LRS1031 MAV123210 STB1121 STR50172 STRS296 UD16573S UNIT BOM 120-561Add Your Number
