Associated Numbers
0001359118 0001367026 0001367073 0986012750 11.130.688 19024289 20401091 25-0461 255701 260-67118 420717 455545 465482 465603 5001836 6010190 72735897 810.005.093 8696 91-15-7123 943252232010 AZJ3232 CST10190 CST10190AS CST10190ES CST10190GS CST10190OS CST10190RS IS0688 LRS00763 MAHMS269 MS269 MSR714 STB2519 STG2519 STM1180 STR50154 UD16589SSpecifications
Kilowatt | 3 kW |
Length (L.1) | 340 mm |
Mount Hole Center - Center (O.1) | 90 mm |
Mount Hole Center - Center (O.2) | 127 mm |
Mount Hole Center - Center (O.3) | 90 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
Mount Hole Diameter (C.3) | 11 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 48 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
VOLVO | F609 | [D60A] | 01.1977-12.1980 |
VOLVO | F610 | [TD60C] | 01.1980- |
VOLVO | F611 | [D60A] | 01.1975-12.1980 |
VOLVO | F613 | [TD60..] | 01.1975-12.1980 |
VOLVO | F614 | [TD60B] | 01.1978-12.1980 |
VOLVO | F615S | [TD60B] | 01.1978-12.1981 |
VOLVO | F616S | [TD60B] | 01.1978-12.1981 |
VOLVO | F617S | [TD60B] | 01.1978-12.1981 |
VOLVO | F7 | [TD70..] | 01.1978-12.1981 |
Reference Information
8696 CST10190ES CST10190AS MAV121900 9.43252E+11 IS0688 UD16589S 1359118 810.005.093 CST10190 0001359118 4737758 465482 986012750 STB2519 1367026 AZJ3232 455545 000986012750 MS 465603 MAHMS269 20401091 331762 255701 LRS00763 MSR714 CST10190RS 19024289 11.130.688 STR10061 STR79049 STRF457 CST10190GS 6010190 STG2519 CST10190OS LRS763 STR50154 1367073 72735897 0001367073 MS269 25-0461 5001836 91-15-7123 260-67118 STM1180 269 420717 0001367026Video/Publications
0001359118 0001367026 0001367073 0986012750 11.130.688 19024289 20401091 25-0461 255701 260-67118 420717 455545 465482 465603 5001836 6010190 72735897 810.005.093 8696 91-15-7123 943252232010 AZJ3232 CST10190 CST10190AS CST10190ES CST10190GS CST10190OS CST10190RS IS0688 LRS00763 LRS763 MAHMS269 MAV121900 MS 269 MSR714 STB2519 STG2519 STM1180 STR50154 STRF457 UD16589SAdd Your Number
