Associated Numbers
0001401012 0001413010 0001418003 05710906 05710993 10956 10956D 10956L 10956M 11.139.092 11.139.530 19024175 20401571 22804 240500 260-46101 33653 51262017008 51262019008 6010175 6643669 72411472 790.101.093 860542 861067 88262016002 8EA737102-001 AZK5444 AZK5569 CS956 CST10175 CST10175AS CST10175ES CST10175GS CST10175OS CST10175RS EAA-121535 EAA-121735 EAA-122651 IS9083 MS578 MS716 REM19024175 SG9090 STR50556 UD16654S UNIT BOM 120-6193BSpecifications
Kilowatt | 3.6 kW |
Length (L.1) | 387 mm |
Mount Hole Center - Center (O.1) | 90 mm |
Mount Hole Center - Center (O.2) | 90 mm |
Mount Hole Center - Center (O.3) | 127 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
Mount Hole Diameter (C.3) | 11 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Oil Sealed | Yes |
Pinion at Rest (B) | 47.5 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
BOMAG | BW 4A 2.8 | [KHD-F3L912] | 01.1973-09.1984 |
BOMAG | BW 6A 2.8 | [KHD-F3L912] | 01.1973- |
VOLVO | B 705 4.7 | [D47B] | 01.1962-04.1964 |
VOLVO | F 84 5.0 | [D50B] | 01.1972-12.1974 |
VOLVO | F 84T 5.0 | [TD50B] | 01.1972-10.1978 |
VOLVO | F 85 5.0 | [D50B] | 01.1972-12.1974 |
VOLVO | F 85T 5.0 | [TD50B] | 01.1972-10.1978 |
VOLVO | F 86 6.7 | [D70B] | 06.1970-12.1974 |
VOLVO | F 86T 6.7 | [TD70B] | 08.1970-09.1974 |
VOLVO | FB 84 5.0 | [D50B] | 01.1972-12.1974 |
VOLVO | FB 84T 5.0 | [TD50B] | 01.1972-10.1978 |
VOLVO | FB 85T 5.0 | [TD50B] | 01.1972-10.1978 |
VOLVO | FB 86 6.7 | [D70B] | 06.1970-12.1974 |
VOLVO | FB 86T 6.7 | [TD70B] | 08.1970-09.1974 |
VOLVO | L 375 Strake 4.7 | [D47A] | 01.1959-12.1961 |
VOLVO | L 465 4.7 | [D47B] | 06.1961-05.1965 |
VOLVO | L 4751 4.7 | [D47B] | 10.1964-12.1965 |
VOLVO | L 4751 4.7 | [TD47B] | 10.1964-12.1965 |
VOLVO | L 475 4.7 | [D47B] | 06.1961-05.1965 |
VOLVO | L 475 4.7 | [TD47B] | 06.1961-05.1965 |
VOLVO | N 7 6.7 | [TD70B] | 09.1973-07.1978 |
VOLVO | N 84 5.0 | [D50B] | 01.1972-08.1973 |
VOLVO | N 86T 6.7 | [TD70B] | 08.1970-08.1973 |
VOLVO | NB 84 5.0 | [D50B] | 01.1972-08.1973 |
VOLVO | NB 86 6.7 | [D70B] | 06.1970-08.1973 |
VOLVO | NB 86T 6.7 | [TD70B] | 08.1970-08.1973 |
VOLVO BM | S950 5.0 | [D50A] | 02.1966-12.1970 |
VOLVO BM | T800 5.0 | [D50A] | 01.1967-12.1975 |
VOLVO BM | T810 5.0 | [TD50A] | 03.1969-12.1975 |
VOLVO BM | T814 5.0 | [TD50A] | 03.1969-06.1979 |
Reference Information
111217 861067 11.139.530 STR10320 240500 51.26201-7008 5010314 240847 UD16654S 240524 0001413010 STR50556 33653 31514401 5710906 EAA-121735 331181 MS716 0001418003 51.26201-9008 790.101.093.380 1304445 41514001 8882 88213065 790.101.093.311 A0041514001 790.101.093.016 1401012 0001401012 A0031514401 STB0151 3109 6643669 6643900 1418003 88.26201-6002 120-6193B STR79525 STR79526 CS956 7240524 1413010 790.101.093.010 5710993Video/Publications
790.101.093.391 790.101.093.010 0001401012 0001401052 0001413010 0001418003 05710906 05710993 10956 10956D 10956L 10956M 11.139.092 11.139.530 19024175 20401571BN 20401571EL 22804 240500 260-46101 33653 51262017008 51262019008 6010175.0 6010175.3 6643669 72411472 860542 861067 88262016002 8EA737102-001 AZK5444 AZK5569 CS956 CST10175AS CST10175ES CST10175GS CST10175OS CST10175RS EAA-121535 EAA-121735 EAA-122651 IS9083 MAV6490 MS578 MS716 REM19024175 SG9090 STR50556 0001401028 UD16654S UNIT BOM 120-6193B 220244 220312Add Your Number
