Associated Numbers
0001360019 0001360031 0001368008 01173560 11.130.741 11.131.868 1173560 120-30124 19070148 19083004 20401116 254769 254769M 260-67252 551.016.093 6010611 72735699 72735990 88212349 AZF4233 AZJ3262 BOS0001368008 CST10611 CST10611AS CST10611ES CST10611GS CST10611OS CST10611RS DRS0265 DS1375 EAA-121337 IS0741 IS1246 MAHMS362 MAHMS71 MS362 MS71 SG0056 STB0530 STR22008 UD16597S UNIT BOM 120-6093Specifications
Insulated Earth | Yes |
Kilowatt | 4 kW |
Length (L.1) | 350 mm |
Mount Hole Center - Center (O.1) | 127 mm |
Mount Hole Center - Center (O.2) | 90 mm |
Mount Hole Center - Center (O.3) | 90 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
Mount Hole Diameter (C.3) | 11 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 28 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | BOSCH |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
IVECO | MK 110-13A 6.1 | [BF6L913T] | 01.1983-12.1991 |
IVECO | MK 110-13A 6.1 | [F6L913] | 01.1983-12.1991 |
IVECO | MK 110-13AH 6.1 | [BF6L913T] | 01.1983-12.1985 |
IVECO | MK 110-16A 6.1 | [BF6L913T] | 01.1983-12.1991 |
IVECO | MK 110-16A 6.1 | [F6L913] | 01.1983-12.1991 |
IVECO | MK 110-16AH 6.1 | [BF6L913T] | 01.1983-12.1991 |
IVECO | MK 110-16AT 6.1 | [BF6L913T] | 01.1983-12.1985 |
IVECO | MK 110-16AT 6.1 | [F6L913] | 01.1983-12.1985 |
IVECO | MK 130-13A 6.1 | [BF6L913T] | 01.1983-12.1991 |
IVECO | MK 130-13A 6.1 | [F6L913] | 01.1983-12.1991 |
IVECO | MK 130-13AH 6.1 | [BF6L913T] | 01.1983-12.1991 |
IVECO | MK 130-13AH 6.1 | [F6L913] | 01.1983-12.1991 |
IVECO | MK 130-16A 6.1 | [BF6L913] | 01.1983-12.1991 |
IVECO | MK 130-16AH 6.1 | [BF6L913] | 01.1983-12.1991 |
IVECO | MK 75-9A 4.1 | [BF4L913T] | 01.1983-12.1989 |
IVECO | MK 75-9A 4.1 | [F4L913] | 01.1983-12.1989 |
IVECO | MK 75-9H 4.1 | [BF6L913T] | 01.1983-12.1985 |
IVECO | MK 75-9H 4.1 | [F6L913] | 01.1983-12.1985 |
IVECO | MK 80-13A 6.1 | [BF6L913] | 01.1983-12.1991 |
IVECO | MK 80-13AH 6.1 | [BF6L913T] | 01.1983-12.1991 |
IVECO | MK 80-13AH 6.1 | [F6L913] | 01.1983-12.1991 |
IVECO | MK 80-13AT 6.1 | [BF6L913T] | 01.1983-12.1991 |
IVECO | MK 80-13AT 6.1 | [F6L913] | 01.1983-12.1991 |
IVECO | MK 80-13AW 6.1 | [BF6L913] | 01.1983-12.1989 |
IVECO | MK 80-13AW 6.1 | [BF6L913] | 01.1983-12.1991 |
IVECO | MK 80-16A 6.1 | [BF6L913T] | 01.1983-12.1991 |
IVECO | MK 80-16A 6.1 | [F6L913] | 01.1983-12.1991 |
IVECO | MK 80-16AW 6.1 | [BF6L913] | 01.1986-12.1989 |
IVECO | MK 90-13A 6.1 | [BF6L913] | 01.1983-12.1991 |
IVECO | MK 90-13AH 6.1 | [BF6L913] | 01.1983-12.1991 |
IVECO | P/PA 120-13ANW 6.1 | [BF6L913T] | 01.1983-12.1990 |
IVECO | P/PA 120-13ANW 6.1 | [F6L913] | 01.1983-12.1990 |
Reference Information
6209190 1161422 EAA-121337 E0041565 11.132.141 UD16597S 19070148 STB0530 1360031 ANM12485X 254769 PRSS083 6010611 CST10611RS BOM 42522641 19083004 UNIT MS71 3047129 1182933 MS 551.016.093 72735990 260-67252 MS362 6200662 362 STRS083 CST10611AS CST10611ES 551.016.093.010 551.016.093.210 0001360019 IS1246 1164995 1172099 AZF4173 551.016.093.016 DS1375 AZJ3262 120-6093 CST10611OS CST10611 CST10611GS STR7976 330385 1701065 6010611.3 1360019 IS0741 SG0056 STR22008 5710903 71 0001368008 STR1070 1183720 20401116 72735699 1183246 1183685 MAHMS362 1183243 MAHMS71 AZF4313 11.131.868 5710912 11.131.667 11.130.741 120-30124 1516768R AZF4233 BOS0001368008 6107017 551.016.093.311 0001360031 254769M DRS0265 1173560 88212349 1173241 1368008 STR78017Video/Publications
6209190 0001360019 0001360031 0001368008 01173560 11.130.741 11.131.868 120-30124 19070148 19083004 20401116 254769 254769M 260-67252 551.016.093 6010611 72735699 72735990 88212349 AZF4233 AZJ3262 BOS0001368008 CST10611 CST10611AS CST10611ES CST10611GS CST10611OS CST10611RS DRS0265 DS1375 EAA-121337 IS0741 IS1246 MAHMS362 MAHMS71 MS 362 MS 71 SG0056 STB0530 STR22008 UD16597S UNIT BOM 120-6093Add Your Number
