Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 450.64 including GST
NZ$ 391.86 excluding GST
or four payments of $112.66
with
Learn More
each
S0757S
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
0001362011Associated Numbers
0001358013 0001358027 0001362011 0001362059 0001362092 11.130.250 20419001 254767M 260-62119 6021100 AZJ3554 CST21100 CST21100AS CST21100ES CST21100GS CST21100OS CST21100RS GS362059-A IS0250 UD16568S UD16574SSpecifications
| Kilowatt | 2.40 kW |
| Length (L.1) | 293 mm |
| Mount Hole Center - Center (O.1) | 105 mm |
| Mount Hole Diameter (C.1) | 13.50 mm |
| Mount Hole Diameter (C.2) | 13.50 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 11 qty |
| OEM Product | No |
| Pinion at Rest (B) | 22 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 82.50 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| GOLDONI | 1055 1.8 | [VM-RA394] | |
| GOLDONI | 3050 1.8 | [VM-RA394] | 04.1986-06.1991 |
| GOLDONI | 3050 2.1 | [VM-HR394HP] | 06.1991- |
| GOLDONI | 3070 2.0 | [VM-RA394HPT] | 06.1990-06.1991 |
| GOLDONI | 3070 2.1 | [VM-HR394HP] | 06.1991- |
| GOLDONI | 55 2.0 | [VM-HR394HP] | 09.1991- |
| GOLDONI | Cingolato 2.0 | [VM-RA394] | 04.1991- |
| GOLDONI | Transcar 2.0 | [VM-RA394] | 11.1990- |
| VM | 20KVA 1.5 | [HR392A] | 01.1978-01.1986 |
| VM | 392RA 1.8 | 01.1984-06.1985 | |
| VM | HR 294 HP 1.4 | 09.1986-12.1990 | |
| VM | HR 394 H 2.0 | ||
| VM | HR 394 HP 2.0 | ||
| VM | HR 394 HT 2.0 | ||
| VM | HR 492 H9 2.4 | ||
| VM | HR 492 HI9 2.4 | ||
| VM | HR 492 HT9 2.4 | 09.1980- | |
| VM | HR 492 HT9 2.4 | ||
| VM | HR 492 HTA 2.4 | ||
| VM | HR 494 H10 2.1 | ||
| VM | HR 494 H 2.1 | ||
| VM | HR 494HPT 2.1 | 06.1988- | |
| VM | HR 494 HT10 2.1 | ||
| VM | HR 494 HT 2.1 | ||
| VM | HR 588HTT 2.5 | 06.1988-07.1989 | |
| VM | RA 392 1.8 | ||
| VM | RA 394 2.0 | 01.1986- |
Reference Information
| 0001358013 | BOSCH |
| 0001358027 | BOSCH |
| 0001362011 | BOSCH |
| 0001362059 | BOSCH |
| 0001362092 | BOSCH |
| 035530050A | CHRYSLER |
| 0986016200 | BOSCH |
| 11.130.250 | ISKRA / LETRIKA |
| 20419001 | REAL |
| 220186 | ERA |
| 254767M | KUHNER |
| 260-62119 | DIXIE |
| 331704 | LOGISTIK |
| 35530050A | CHRYSLER |
| 6021100 | SANDO |
| 730.008.112.010 | PSH |
| 730.008.112.016 | PSH |
| AZJ3554 | ISKRA / LETRIKA |
| CGB-26200 | AINDE |
| CS1073 | HC PARTS |
| CST21100 | CASCO |
| CST21100AS | CASCO |
| CST21100ES | CASCO |
| CST21100GS | CASCO |
| CST21100OS | CASCO |
| CST21100RS | CASCO |
| GS362059-A | GPARTS |
| IS0250 | ISKRA / LETRIKA |
| MAV231000 | SIOM |
| MS393 | MAHLE |
| PRC5669 | ROVER |
| PRSS057 | 3EFFE |
| S0757S | AS-PL |
| S135.265 | PSH |
| STR79008 | ELECTROLOG |
| STRS057 | 3EFFE |
| UD16568S | AS-PL |
| UD16574S | AS-PL |
Video/Publications
