Associated Numbers
0001367040 UD16591S 0986023190 110565 CST21138GS CST25103GS CST25103AS 8719 19083015 19083052 DRS3287 DS4397 260-69100 TS-6076 220739 SG0152 SG9006 SG9079 S13-73 S13-74 11.130.509 AZJ3144 IS0509 11.132.159 AZE4244 IS1378 STL0201 STG0201 STB0201 STI0201 10201L 10201P 063227602010 MSN199 63227602 MT68S MS345 72735973 MS395 72736023 3542185M92 8212679 88212679 650.001.103 20405301BN 20405301OE 20419831OE 182-30456 120-30321 6021138.1 6025103.0 6025103.1 17072N 17072R MAHMS395 MAHMS345Specifications
Kilowatt | 3 kW |
Length (L.1) | 340 mm |
Mount Hole Center - Center (O.1) | 127 mm |
Mount Hole Center - Center (O.2) | 90 mm |
Mount Hole Center - Center (O.3) | 90 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
Mount Hole Diameter (C.3) | 11 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 30 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
MASSEY FERGUSON | 1080 | 01.1970-12.1975 | |
MASSEY FERGUSON | 1100 | 01.1966-12.1969 | |
MASSEY FERGUSON | 1104 | [A4.236] | 01.1976-12.1978 |
MASSEY FERGUSON | 175 | [A4.248] | 01.1965-12.1972 |
MASSEY FERGUSON | 178 | [A4.236] | 01.1968-12.1971 |
MASSEY FERGUSON | 275 | [A4.248] | 01.1977-12.1981 |
MASSEY FERGUSON | 290 | [A4.318] | 01.1983-12.1986 |
MASSEY FERGUSON | 298 | 01.1983-12.1988 | |
MASSEY FERGUSON | 4270 | [A4.318] | 01.1997-12.2000 |
MASSEY FERGUSON | 595 | [A4.236] | 01.1976-12.1982 |
MASSEY FERGUSON | 675 | [A4.248] | 01.1982-12.1986 |
MASSEY FERGUSON | 690 | [AA318.2] | 01.1982-12.1986 |
MASSEY FERGUSON | 698 | [A6.354.4] | 01.1982-12.1984 |
MASSEY FERGUSON | 699 | 01.1984-12.1986 |
Reference Information
19083015 6025103 MAHMS395 234987A1 STR79080 20405301BN SG0152 SG9006 7701031686 3597372M2 DRS3287 1447731R1 20419831OE CST25103AS SG9079 MAV271220 2873D001 2873D002 2873D003 AZJ3144 3763362M91 ALTS698 UD16591S 1367040 3546391M91 AZE4244 260-69100 6005021272 MS395 26414 26358A 706022A1 STL0201 1871434M1 3519400M92 1860093M2 88212679 3516094M1 DS4397 27519 8212679 CST25103GS STR7909 TS-6076 3519400M1 17072N STG0201 17072R S0802S 323319A1 3930506R1 1447698M1 8719 986023190 650.001.103 6025103.1 20405301OE 3539390M92 26358 336503 3539390M91 395 3542185M93 3542185M92 CS201 IS1378 2873006T 19083052 S13-73 S13-74 3542185M91 6005700081 STI0201 1868287T 11.132.159 1691806R1 54265233 MS 6005003154 3597372R2 MAHMS345 MT68S STB0201 MSN199 3930509R1 1868285M3 000986023190 MAV3630 63227602010 909971R2 1868285M2 1868285M1 26410R 10201L 110565 IS0509 220739 0001367040 10201P 6021138.1 1447834M91 1868285R3 CST21138GS 63227602 11.130.509 STRL825 72736023 S13-73B STR7941 1447731 72735973 MS345 2873B057 2873006 7700011850 182-30456 345 2873003 2873004 388187A1 120-30321 S12-73 CGB-23287 388187A2Video/Publications
0001367040 063227602010 0986023190 10201L 10201P 11.130.509 11.132.159 110565 120-30321 17072N 17072R 182-30456 19083015 19083052 20405301BN 20405301OE 20419831OE 220739 260-69100 3542185M92 54265233 6021138.1 6025103.0 6025103.1 650.001.103 72735973 72736023 8212679 8719 88212679 ALTS698 AZE4244 AZJ3144 CGB-23287 CS201 CST21138GS CST25103AS CST25103GS DRS3287 DS4397 IS0509 IS1378 MAHMS345 MAHMS395 MAV271220 MAV3630 MS 345 MS 395 MSN199 MT68S S13-73 S13-74 SG0152 SG9006 SG9079 STB0201 STG0201 STI0201 STL0201 STRL825 TS-6076 UD16591SAdd Your Number
