Associated Numbers
0001410037 UD16611S 260-46220 45-0114 STB0098 1098 LRS00878 943252197010 MSR693 943252197 911.201.113 279932 163394 455534 91-15-6945Specifications
Insulated Earth | Yes |
Kilowatt | 5.5 kW |
Length (L.1) | 388 mm |
Mount Hole Center - Center (O.1) | 127 mm |
Mount Hole Center - Center (O.2) | 127 mm |
Mount Hole Center - Center (O.3) | 127 mm |
Mount Hole Diameter (C.1) | 17 mm |
Mount Hole Diameter (C.2) | 17 mm |
Mount Hole Diameter (C.3) | 17 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
Oil Sealed | Yes |
Pinion at Rest (B) | 37.5 mm |
Rotation | CW |
Spigot Diameter (A) | 92 mm |
Unit Type | BOSCH |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
SCANIA | 110 | [D11] | 01.1968-12.1974 |
SCANIA | 110 | [DS11] | 01.1968-12.1974 |
SCANIA | 111 | [D11] | 01.1975-12.1980 |
SCANIA | 111 | [DS11] | 01.1975-12.1980 |
SCANIA | 112 | [D11] | 01.1978-12.1990 |
SCANIA | 112 | [DN11] | 01.1978-12.1990 |
SCANIA | 112 | [DS11] | 01.1978-12.1990 |
SCANIA | 112 | [DSC11] | 01.1978-12.1990 |
SCANIA | B110 | [D11] | 01.1968-12.1973 |
SCANIA | B110 Super | [DS11] | 01.1969-12.1976 |
SCANIA | BF110 | [D11] | 01.1968-12.1973 |
SCANIA | BF110 Super | [DS11] | 01.1969-12.1976 |
SCANIA | BK112 | [DS11] | 01.1982-12.1983 |
SCANIA | BK112 | [DS11.15B] | 01.1982-12.1983 |
SCANIA | CF110L | [D11] | 01.1968-12.1970 |
Reference Information
220239 1410037 260-46220 91-15-6945 9.43252E+11 0001410037 22710 163394 1516832R STB0098 1516654R LRS00878 349576 110214 1098 UD16611S 571454 279932 911.201.113 943252197 45-0114 LRS878 MAV1213 MSR693 455534Video/Publications
0001410037 1098 110214 163394 260-46220 279932 45-0114 455534 91-15-6945 911.201.113 943252197 943252197010 LRS00878 LRS878 MAV1213 MSR693 STB0098 UD16611S 220239Add Your Number
