Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
DELCO
Price:
NZ$ 895.72 including GST
NZ$ 778.89 excluding GST
or four payments of $223.93
with
Learn More
each
S1011
No stock in NZ - Call us for possible procurement options
No stock in NZ - Call us for possible procurement options
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
19011516Associated Numbers
009T70077 10461334 10461753 10461777 113550 113829 19011506 19011516 19011518 19011521 19011530 19524N 20409531BN 254436 254664 254664P 3103304 3103915 428000-1210 428000-1211 428000-1220 428000-1221 6060135 6911N 6911R 6913N 8200033 8200040 8300019 8MJ4298AM 8MJ5439M CST60135AS FL0579 IN0976 M009T70579 M105R2502SE M105R2515SE M105R2518SE M105R3502SE M110R2601SE M110R2603SE2D M110R2604SE M110R2605SE M110R2615SE M110R2615SE2D M110R2616SE-A M125R2001SEP M125R2632SE M9T70379 MIB70579FL MIB970379 MIB970379FL MIB97059 MK0077 STR60204 VV0977Specifications
| Kilowatt | 6.20 kW |
| Length (L.1) | 414 mm |
| Mount Hole Center - Center (O.1) | 127 mm |
| Mount Hole Center - Center (O.2) | 127 mm |
| Mount Hole Center - Center (O.3) | 127 mm |
| Mount Hole Diameter (C.1) | 16 mm |
| Mount Hole Diameter (C.2) | 16 mm |
| Mount Hole Diameter (C.3) | 16 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 11 qty |
| No./Teeth (Replaces) | 11 qty |
| OEM Product | No |
| Pinion at Rest (B) | 47 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 92 mm |
| Unit Type | DELCO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| MACK | CH Series | ||
| MACK | CL Series | ||
| MACK | CV Series | ||
| MACK | DM Series | ||
| MACK | MR Series | ||
| MACK | RB Series | ||
| MACK | RD Series |
Reference Information
| 009T70077 | MITSUBISHI |
| 10461334 | DELCO |
| 10461753 | DELCO |
| 10461777 | DELCO |
| 113550 | CARGO |
| 113829 | CARGO |
| 19011506 | DELCO |
| 19011516 | DELCO |
| 19011518 | DELCO |
| 19011521 | DELCO |
| 19011530 | DELCO |
| 19524N | WAI / TRANSPO |
| 20409531BN | REAL |
| 254436 | KUHNER |
| 3102762 | CUMMINS |
| 3103304 | CUMMINS |
| 3103915 | CUMMINS |
| 428000-1210 | DENSO |
| 428000-1211 | DENSO |
| 428000-1220 | DENSO |
| 428000-1221 | DENSO |
| 6060135 | SANDO |
| 6911N | WAI / TRANSPO |
| 6911R | WAI / TRANSPO |
| 6913N | WAI / TRANSPO |
| 8200033 | DELCO |
| 8200040 | DELCO |
| 8300019 | DELCO |
| 8MJ4298AM | MITSUBISHI |
| 8MJ5439M | MITSUBISHI |
| CST60135AS | CASCO |
| D616002001 | PACCAR |
| F032113550 | CARGO |
| F032113829 | CARGO |
| FL0579 | MITSUBISHI |
| IN0976 | MITSUBISHI |
| M009T70379 | MITSUBISHI |
| M009T70579 | MITSUBISHI |
| M105R2502SE | PRESTOLITE |
| M105R2515SE | PRESTOLITE |
| M105R2518SE | PRESTOLITE |
| M110R2603SE2D | PRESTOLITE |
| M110R2604SE | PRESTOLITE |
| M110R2605SE | PRESTOLITE |
| M110R2615SE | PRESTOLITE |
| M110R2615SE2D | PRESTOLITE |
| M110R2616SE-A | PRESTOLITE |
| M125R2001SEP | PRESTOLITE |
| M125R2632SE | PRESTOLITE |
| M9T70379 | MITSUBISHI |
| MIB70579FL | MITSUBISHI |
| MIB970379 | FREIGHTLINER |
| MIB970379FL | FREIGHTLINER |
| MIB97059 | MITSUBISHI |
| MK0077 | MITSUBISHI |
| STR2623 | ELECTROLOG |
| STR60204 | WOODAUTO |
| STRL868 | 3EFFE |
| STRS473 | 3EFFE |
| STRS830 | 3EFFE |
| VV0977 | MITSUBISHI |
Video/Publications
