Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
DELCO
Price:
NZ$ 1,081.68 including GST
NZ$ 940.59 excluding GST
or four payments of $270.42
with
Learn More
each
S1029
No stock in NZ - Call us for possible procurement options
No stock in NZ - Call us for possible procurement options
Associated Numbers
141735 6857 8200436 M105R3524SE RNL8200436Specifications
| Kilowatt | 7.20 kW |
| Length (L.1) | 418 mm |
| Mount Hole Center - Center (O.1) | 126.50 mm |
| Mount Hole Center - Center (O.2) | 126.50 mm |
| Mount Hole Center - Center (O.3) | 126.50 mm |
| Mount Hole Diameter (C.1) | 16.50 mm |
| Mount Hole Diameter (C.2) | 16.50 mm |
| Mount Hole Diameter (C.3) | 16.50 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 12 qty |
| No./Teeth (Replaces) | 12 qty |
| OEM Product | No |
| Pinion at Rest (B) | 47.50 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 92 mm |
| Unit Type | DELCO |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| DETROIT | Engine | [DD13] | |
| DETROIT | Engine | [DD15] | |
| MCI | Engine 12.8 | [DD13] | 01.2012-12.2016 |
| MCI | J4500 12.8 | [DD13] | 01.2014-12.2016 |
| MERCEDES BENZ TRUCKS & BUSES | 2035 12.0 | [OM457LA] | 01.2005-12.2013 |
| MERCEDES BENZ TRUCKS & BUSES | 2040 12.0 | [OM457LA] | 01.2005-12.2013 |
| MERCEDES BENZ TRUCKS & BUSES | 2044 12.0 | [OM457LA] | 01.2005-12.2013 |
| MERCEDES BENZ TRUCKS & BUSES | 2540 12.0 | [OM457LA] | 01.2005-12.2013 |
| MERCEDES BENZ TRUCKS & BUSES | 2544 12.0 | [OM457LA] | 01.2005-12.2013 |
| MERCEDES BENZ TRUCKS & BUSES | 2640 12.0 | [OM457LA] | 01.2005-12.2013 |
| MERCEDES BENZ TRUCKS & BUSES | 2644 12.0 | [OM457LA] | 01.2005-12.2013 |
| MERCEDES BENZ TRUCKS & BUSES | 3340 12.0 | [OM457LA] | 01.2005-12.2013 |
| MERCEDES BENZ TRUCKS & BUSES | 3344 12.0 | [OM457LA] | 01.2005-12.2013 |
| MERCEDES BENZ TRUCKS & BUSES | Actros 12.0 | [OM541] | 01.2005-12.2013 |
| MERCEDES BENZ TRUCKS & BUSES | Actros 16.0 | [OM542] | 01.2003-12.2008 |
| MERCEDES BENZ TRUCKS & BUSES | Engine | [4000] | |
| MERCEDES BENZ TRUCKS & BUSES | LS1634 12.0 | [OM457LA] | 01.2006-12.2013 |
| MERCEDES BENZ TRUCKS & BUSES | O 345G 12.0 | [OM457LA] | 01.2001-12.2013 |
| MERCEDES BENZ TRUCKS & BUSES | O 500MA 12.0 | [OM457LA] | 01.2006-12.2013 |
| MERCEDES BENZ TRUCKS & BUSES | O 500RS-RSD 12.0 | [OM457LA] | 01.2001-12.2005 |
| MERCEDES BENZ TRUCKS & BUSES | O 530GN3 12.0 | [OM457LA] | 01.1999-12.2005 |
| MERCEDES BENZ TRUCKS & BUSES | O 530GNUE3 12.0 | [OM457LA] | 01.1999-12.2004 |
| MERCEDES BENZ TRUCKS & BUSES | O 530N3 12.0 | [OM457LA] | 01.1998-12.2004 |
| MERCEDES BENZ TRUCKS & BUSES | O 530N3 Lang 12.0 | [OM457LA] | 01.1999-12.2004 |
| MERCEDES BENZ TRUCKS & BUSES | O 580 RHD-15 12.0 | [OM457LA] | 01.1999-12.2006 |
| MERCEDES BENZ TRUCKS & BUSES | O 580 RHD-17 12.0 | [OM457LA] | 01.1999-12.2006 |
| MERCEDES BENZ TRUCKS & BUSES | Tourismo 12.0 | [OM457LA] | 01.1999-12.2006 |
| PREVOST | Engine 12.8 | [DD13] | 01.2010-12.2015 |
Reference Information
| 140-39160 | ROBERT'S |
| 551.563.123.038 | PSH |
| 6857N | WAI / TRANSPO |
| 8200436 | DELCO |
| 8200436-12B1 | DELCO |
| 91-01-4803 | WILSON |
| 91-01-4803N | WILSON |
| M105R3524SE | PRESTOLITE |
| REM8200436 | WOODAUTO |
| RNL8200436 | RNL |
Video/Publications
