Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
DELCO
Price:
NZ$ 869.29 including GST
NZ$ 755.90 excluding GST
or four payments of $217.32
with
Learn More
each
S1041
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Associated Numbers
114326 19026032 1993954 254389 254389P 255022 255022C 255022D 255542 255542D 255542P 3965282 3965282RX 428000-5220 6832N 8147 8200024 8300023 M105R3510SE S1041 STR80030 UD01303SSpecifications
| Kilowatt | 7.50 kW |
| Length (L.1) | 407 mm |
| Mount Hole Center - Center (O.1) | 90 mm |
| Mount Hole Center - Center (O.2) | 127 mm |
| Mount Hole Center - Center (O.3) | 90 mm |
| Mount Hole Diameter (C.1) | 10.50 mm |
| Mount Hole Diameter (C.2) | 10.50 mm |
| Mount Hole Diameter (C.3) | 10.50 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| No./Teeth (Replaces) | 10 qty |
| OEM Product | No |
| Pinion at Rest (B) | 47.50 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Unit Type | DELCO |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CUMMINS | Various Models | 01.1987- |
Reference Information
| 114326 | CARGO |
| 19026032 | DELCO |
| 1993954 | DELCO |
| 20409516BN | REAL |
| 20409516OE | REAL |
| 254389 | KUHNER |
| 254389P | KUHNER |
| 255542 | KUHNER |
| 255542D | KUHNER |
| 255542P | KUHNER |
| 3908594 | CUMMINS |
| 3908598 | CUMMINS |
| 3965282 | CUMMINS |
| 3965282RX | CUMMINS |
| 45-5041 | ELSTOCK |
| 4934036 | CUMMINS |
| 4N957 | CATERPILLAR |
| 6060615.0 | SANDO |
| 6060615.1 | SANDO |
| 641.509.103.390 | PSH |
| 6832N | WAI / TRANSPO |
| 8147 | CEVAM |
| 8200024 | DELCO |
| 8200078 | DELCO |
| 8300023 | DELCO |
| 9011707113 | VOLVO |
| CST60615AS | CASCO |
| CST60615GS | CASCO |
| F032114326 | CARGO |
| LRS03878 | LUCAS |
| LRS3878 | LUCAS |
| M105R3510SE | PRESTOLITE |
| S1041 | AS-PL |
| S24DR0095 | SIDAT |
| S24DR0095A2 | SIDAT |
| ST1009 | CUMMINS |
| ST9016 | CUMMINS |
| ST9101 | CUMMINS |
| ST9204 | CUMMINS |
| ST9224 | CUMMINS |
| ST9225 | CUMMINS |
| STD4326 | KRAUF |
| STR2661 | ELECTROLOG |
| STR80030 | WOODAUTO |
| STRL915 | 3EFFE |
| STX201301 | STARDAX |
| UD01303S | AS-PL |
| VOE9011707113 | VOLVO |
Video/Publications
